Alarm SAF PS5-M Installation Manual

Power supply/battery charger with fire alarm input module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PS5-M Power Supply/Battery Charger with
Fire Alarm Input Module Installation Manual
This Installation manual is made up of the following separate Installation Instructions for the Power Supply
and Fire Alarm Input Module.
52-375 - Installation Instructions for PS5-M Power Supply - pp. 2-19
52-382 - Installation Instructions for FAI Module - p. 20-36
AlarmSaf
65A Industrial Way, Wilmington, MA 01887-3499, USA, Toll Free: 800-987-1050, Voice: 978-658-6717, Fax: 978-658-8638, www.alarmsaf.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS5-M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alarm SAF PS5-M

Summary of Contents for Alarm SAF PS5-M

  • Page 1 This Installation manual is made up of the following separate Installation Instructions for the Power Supply and Fire Alarm Input Module. 52-375 - Installation Instructions for PS5-M Power Supply - pp. 2-19 52-382 - Installation Instructions for FAI Module - p. 20-36 AlarmSaf 65A Industrial Way, Wilmington, MA 01887-3499, USA, Toll Free: 800-987-1050, Voice: 978-658-6717, Fax: 978-658-8638, www.alarmsaf.com...
  • Page 2 BATTERY FUSE AC ON AC FLT J4 ABC BUSS 2 BUSS 1 Model PS5-M Power Supply / Battery Charger Operating and Installation Instructions 52-375 Rev A.03...

  • Page 3: Symbol Definitions

    PS5-M Installation Instructions February 23, 2012 I. Warnings and Notices  WARNING - Do not touch the heat sinks on the PC board while the unit is powered as there is a possibility of electric shock  WARNING - To reduce the risk of fire or electric shock, do not expose this product to rain or moisture ...

  • Page 4: Table Of Contents

    3.5 Output Terminals 3.6 Battery Terminals 3.7 Fault Reporting Terminals 3.8 Fusing 4 Installation 4.1 Mounting 4.2 Wiring 5 Operating the PS5-M 5.1 Output Voltage Selection 5.2 Jumper Settings 5.3 Visual Indicators 5.4 Troubleshooting 6 Specifications 6.1 Electrical Specifications 6.2 Temperature Specifications 6.3 Mechanical Specifications...

  • Page 5: Introduction

    Section 1 Introduction The PS5-M is an off-line switching (OLS) power supply designed for use in the access control, fire industry, and related industries by the systems integrator. It accepts a variety of accessory boards designed to increase the functionality of the basic power supply.

  • Page 6: Applicable Standards / Documents

    PS5-M Installation Instructions February 23, 2012 Section 2 Applicable Standards / Documents NFPA Standards NFPA 72 National Fire Alarm Code NFPA 70 National Electrical Code NFPA 731 Standard for the Installation of Electronic Premises Security Systems US Standards UL 294 Access Control System Units...

  • Page 7: System Overview

    80 AH (48 hour charge), 40 AH (24 hour charge) Product Use When installed in accordance with all standards listed in Section 2 of this document, the PS5-M provides power for use with typical 12 or 24 VDC as used in the access control, fire, CCTV, or security industries such as, but not limited to, mag locks, door strikes, door holders, smoke dampers, four wire smoke detectors, card readers, keypads, etc.

  • Page 8: Connector Descriptions And Electrical Ratings

    PS5-M Installation Instructions February 23, 2012 3.2 PS5-M Connector Descriptions and Electrical Ratings Terminal / Connector Description Rating 120 VAC or 230 VAC Nominal @ 50-60 Hz 5-Pin AC Line connector Must be configured for 230 VAC prior to use. See Fig.3.3.1...

  • Page 9: Ac Input Connection

    3.3 AC Input Connection The AC input for the PS5-M is made through a fully shrouded pluggable cable which plugs into the AC Power input connector plug (J1). Connection to the harness should be made via wire nut to an appropriate AC source.

  • Page 10: Abc Connectors And Harnesses

    The voltage is carried by either pins 5 and 6 or pins 7 and 8 of the ABC connector (J4). By appropriate positioning of the fuse associated with JP5, JP6, and JP7, the PS5-M output can be connected to other accessory boards in the system for distribution by either Buss 1 or Buss 2. See Section 5.2 for additional information on selection of Buss 1 or Buss 2.

  • Page 11: Output Terminals

    Note - When there are no batteries on the PS5-M, it is normal for there to be no voltage on the battery terminals. The charger does not enable until it senses a battery on the terminals.

  • Page 12: Fault Reporting Terminals

    PS5-M Installation Instructions February 23, 2012 3.7 Fault Reporting Terminals The fault reporting relay connections are made through removable terminal strip, J3. Separate Form C relays are provided for AC Fault and Common Fault. Six fault terminals are available: 1. AC FLT Common (COM) 2.

  • Page 13: Fusing

    February 23, 2012 3.8 Fusing The PS5-M contains two replaceable fuses - the Battery Fuse and the ABC Buss Fuse. When replacing these fuses, only the equivalent type and rating are to be used. The PS5-M utilizes commonly available Automotive Miniature fuses (Type ATM). Both fuses are rated at 15A (ATM-15).

  • Page 14: Installation

    Installation 4.1 Mounting 4.1.1 Wall Mounting If the PS5-M is provided in a wall mount enclosure, use #8 hardware minimum in four locations. Use an appropriate fastening system for the mounting surface. Cabinet Mounting: 1. Mark and pre-drill two holes for the top keyhole mounting screws 2.

  • Page 15: Wiring

    Locate the battery terminals. These terminals are non-removable and accept wire sizes between #12 and #22 AWG. Polarity is notated on the PCB. If the PS5-M is set for 12 VDC, connect a single 12V battery to the terminals. If the PS5-M is set for 24 VDC, connect two 12V batteries in series to the terminals.

  • Page 16: Operating The Ps5-M

    Operating the PS5-M 5.1 Output Voltage Selection Before powering a system containing a PS5-M, the output voltage switch (SW1 - Voltage Select) must be set for the proper output voltage or damage to the system could occur. Do not change the switch setting while the unit is powered or damage to the system may occur.

  • Page 17: Visual Indicators

    5.2.3 JP5, JP6, JP7 (Buss 1 / Buss 2) The fuse associated with JP5, JP6, and JP7 determines whether the output of the PS5-M connects to Buss 1 or Buss 2 of the ABC connector. See Figure 3.7.1 ...

  • Page 18: Troubleshooting

    Verify presence of AC voltage Verify that a good battery set of the Bad / Incorrect Battery Set proper voltage is connected to the The output voltage of the PS5-M is PS5-M incorrect or missing If the PS5-M experiences an over...

  • Page 19: Specifications

    PS5-M Installation Instructions February 23, 2012 Section 6 Specifications 6.1 Electrical Specifications 6.1.1 Input Voltage 120 VAC or 230 VAC Nominal @ 50-60 Hz 6.1.2 Input Power 170W Maximum 6.1.3 Standby Load 80 mA Maximum (plus output load including accessory boards 6.1.3 Output Voltage...
  • Page 20 REPLACE FUSES ONLY WITH SAME TYPE AND RATING UTILISER UN FUSIBLE DE RECHANGE DE MEME AlarmSaf c 2006 MODE +DC1- -DC2+ 38-137 Rev B01 PWR LTD ATM-15 FAI INPUT Model FAIM Fire Alarm Input Module Operating and Installation Instructions 52-382 Rev A.01...
  • Page 21 FAIM Installation Instructions 2009/10/30 16:12:34 I. Warnings and Notices  WARNING - To reduce the risk of fire or electric shock, do not expose this product to rain or moisture  WARNING - This installation and all servicing should be made by qualified service personnel and should conform to all local codes ...
  • Page 22 FAIM Installation Instructions 2009/10/30 16:12:34 Table of Contents Section Page I. Warnings and Notices 1 Introduction 2 Applicable Standards / Documents 3 System Overview 3.1 Electrical Ratings and Specifications 3.2 FAIM Terminal and Connector Descriptions and Electrical Ratings 3.3 ABC Connectors and Harnesses 3.4 Output Terminals 3.5 Input Terminals 4 Installation...

  • Page 23: Introduction

    FAIM Installation Instructions 2009/10/30 16:12:34 Section 1 Introduction The FAIM (Fire Alarm Input Module) provides a Fire Alarm Input to AlarmSaf power supplies which employ an ABC connector. It accepts a DC voltage, NO or NC contact, open collector, or reverse polarity input and includes an optional latching function.

  • Page 24: Applicable Standards / Documents

    CAN/CSA-C22.2 No. 107.1-01 General Use Power Supplies Other Applicable Local and State Building Codes Requirements of the Local Authority Having Jurisdiction (LAHJ) Other AlarmSaf Documents 52-375: PS5-M Instruction Manual 52-376: RMDC Instruction Manual 52-382 Rev A.01 Page 5 of 15 AlarmSaf...

  • Page 25: System Overview

    FAIM Installation Instructions 2009/10/30 16:12:34 Section 3 System Overview 3.1 Electrical Ratings and Specifications Manufactured By AlarmSaf 65A Industrial Way Wilmington, MA 01887 Tel: 978 658 6717 800 987 1050 www.alarmsaf.com Model Number FAIM Electrical Ratings Inputs Power Input: 12-24VDC Nominal @ 14 Amps maximum Control Input: 9-33VDC @ 3.3mA Maximum Outputs DC1 - 1.6A Maximum - Power Limited...

  • Page 26: Faim Terminal And Connector Descriptions And Electrical Ratings

    FAIM Installation Instructions 2009/10/30 16:12:34 3.2 FAIM Terminal and Connector Descriptions and Electrical Ratings Terminal / Connector Description Rating ABC Input or Output 12-24V Nominal at 14A per Buss (controlled by base supply(s) ABC Input or Output TB1 - Fire Alarm Input Voltage Output - Input Terminal A Input Terminal B...

  • Page 27: Abc Connectors And Harnesses

    FAIM Installation Instructions 2009/10/30 16:12:34 3.3 ABC Connectors and Harnesses 3.3.1 The ABC buss supplies the voltages (B1 and B2) and FAI control to compatible accessory boards. B1 is supplied through pins 5 and 6 while B2, if used, is supplied through pins 7 and 8 of each connector. By using the appropriate cables, one or two independent voltage sources can be connected to the FAIM.

  • Page 28: Output Terminals

    FAIM Installation Instructions 2009/10/30 16:12:34 3.4 Output Terminals The FAIM’s output terminals (TB2) provide the controlled output from the FAIM. Output DC1 is a power limited output protected by a 1.6A PTC. Output DC2 is a non-power limited output protected by a 10A fuse. If the DC1 output PTC is tripped, remove the output load by removing the output wiring for 30 seconds.

  • Page 29: Installation

    FAIM Installation Instructions 2009/10/30 16:12:34 Section 4 Installation 4.1 Mounting The FAIM mounts to the back of a metal enclosure or onto the accessory board space on a listed AlarmSaf power supply. 4.1.1 Mounting to the back of an enclosure 1.

  • Page 30: Wiring

    FAIM Installation Instructions 2009/10/30 16:12:34 4.2 Wiring 4.2.1 Wire Routing All wiring must be installed in accordance with NFPA70 [NEC760], NFPA72, and all local code requirements. Power Limited wiring requires that power limited and non-power limited wiring remain physically separated. Any power limited circuit entering the enclosure must remain at least one quarter inch (¼”) away from any non-power limited circuit wiring.

  • Page 31: Operating The Faim

    FAIM Installation Instructions 2009/10/30 16:12:34 Section 5 Operating the FAIM 5.1 Jumper Configuration Before powering a system containing an FAIM, the jumpers must be set for proper operation. Failure to do so before applying power could damage the system. Jumper Description Settings Factory Default...

  • Page 32: Visual Indicators

    FAIM Installation Instructions 2009/10/30 16:12:34 5.2 Visual Indicators The FAIM has five LEDs to indicate it’s status.  Buss Voltage 1 (D1) - Indicates that voltage is present on the B1 buss when lit  Buss Voltage 2 (D2) - Indicates that voltage is present on the B2 buss when lit ...

  • Page 33: Troubleshooting

    FAIM Installation Instructions 2009/10/30 16:12:34 5.3 Troubleshooting Condition Possible Cause Solution Missing or incorrectly set Verify jumpers present and in jumper the correct position No voltage supply Verify the power supply Check output wiring and Blown output fuse (DC2 output) replace fuse No voltage on output Check output wiring and...

  • Page 34: Specifications

    FAIM Installation Instructions 2009/10/30 16:12:34 Section 6 Specifications 6.1 Electrical Specifications 6.1.1 Input Voltage (B1 and B2) 12-24VDC Nominal Note: B1 MUST be 12V or higher. 6.1.2 Input Current (B1 and B2) 14A maximum per buss 6.2 Temperature Specifications 6.2.1 Ambient Temperature Range 0ºC to 49ºC (32ºF to 120ºF) 6.2.2 Ambient Humidity 93% at 32ºC (90ºF) Maximum...
  • Page 35 APPENDIX A: FAI Input Wiring Applications March 25, 2013 The FAI input may be wired to latch if required by local codes, and accepts a 9-30V DC voltage, NO/NC contact, or open collector for activation. The diagrams below show various wiring methods. Verify all jumpers are set properly. Remote normally open, dry contact trip using the internal voltage source of the FAIM.
  • Page 36 APPENDIX A: FAI Input Wiring Applications March 25, 2013 Remote normally open, dry contact or open collector trip using the internal voltage source of the FAIM. Internal FAI Mode jumper (J1) must be set to the right. Remote normally closed, dry contact trip using the internal voltage source of the FAIM.
