FIGURE 19 – WALL MOUNT REMOTE RECEIVER - REAR VIEW
!!! WARNING !!!
Failure to position the parts in accordance with all included
pictures, diagrams, and drawings, or failure to use only parts
specifically approved with this heater may result in property
damage or personal injury.
USE ANY MATERIAL NOT FURNISHED WITH THIS
APPLIANCE!
Refer to the log set up instructions, packaged with your
Decorative Gas Logs, ( Box Two ), before continuing with
" FINAL SET UP ", step 2.
2- Remove all contents from the Decorative Gas Log
shipping container. ( Box Two )
3- Check the contents of the shipping container against the
shipping and packing list, or the parts list in this manual.
Report any missing or damaged gas logs to your retailer.
4- Remove any and all protective wrapping from the gas
logs.
DO NOT
FINAL SET UP continued
STOP!
FIGURE 20 – WALL MOUNT REMOTE RECEIVER - TOP VIEW
TERMINAL BLOCK CONNECTIONS, FOR WALL MOUNT
TRANSMITTER, REMOTE RECEIVERS, USE THE INSIDE
TERMINAL BLOCK RECEPTACLES. ( SEE FIGURE 19 & 20 )
FINAL SET UP
5- Arrange the decorative gas logs, on the burner base,
according to the instructions, packaged with the gas logs.
6- Place the Lava Rock ( cinders ) around the Grate / Burner
assembly. ( SEE FIGURE 24, 25, & 26 )
DO NOT PLACE THE CINDERS ON THE BURNER
BASE; THIS WILL CAUSE SOOTING!
7- DO NOT pack cinders around the valve. The valve will
overheat! You must allow air flow around the valve.
8- When you have completed setting up the logs, proceed to
the " OPERATION " section, on page 14.
11
IMPORTANT
