To the Installer:
Please attach these instructions
next to the water heater.
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause serious
injury or property damage. Refer to this
manual. For assistance or additional
information, consult a qualified installer or
service agency.
CAUTION
The recommended temperature for normal
residential use is 120°F. The dial on the
aquastat does not always reflect the out-
coming water temperature, which could
occasionally exceed 120°F. The variation in
out-coming temperature could be based on
factors including but not limited to usage
patterns and type of installation. Test your
water at the tap nearest to the water heater.
WARNING
Hotter water increases the risk of scald injury.
Before adjusting the water temperature setting,
read this instruction manual. Temperatures at
which injury occurs vary with the person's age
and the length of exposure.
The slower reaction time of children, elderly,
and physically or mentally challenged persons
increases the scalding hazard to them. It is
recommended that lower water temperatures
be used where these exposure hazards exist.
Such households may require a temperature
setting less than 120°F to prevent accidental
contact with hot water.
To lower water temperature use point-of-use
temperature limiting devices.
WARNING
Water heater blankets are not recommended
and will void the warranty.
THIS MANUAL HAS BEEN PREPARED
TO ACQUAINT YOU WITH THE INSTALLATION,
OPERATION, AND MAINTENANCE OF
YOUR WATER HEATER AND TO PROVIDE
IMPORTANT SAFETY INFORMATION.
#23680
To the Consumer:
Please read these and all component
instructions and keep for future reference.
Techtanium™ Solar
Indirect Water Heater
Instruction Manual
Warranty, Registration Card and Parts List are included.
Homeowner: Please remember to return the Registration Card!
INSTALLER RESPONSIBILITIES
Please read all instructions thoroughly before
installing or placing the heater into service.
This unit must be installed by licensed or
authorized installers, or technical personnel
that service water heating equipment. The
heater must be installed in accordance with all
local codes and ordinances.
These instructions are a guide for the
correct installation of the water heater. The
manufacturer will not be liable for damages
caused by failure to comply with the installation
and operating instructions outlined on the
following pages.
The recommended water temperature setting
for normal residential use is 120°F/49°C.
HANDLING
Before uncrating, check for shipping damage.
Report any damage to your carrier. Note damage
on bill of lading or delivery receipt and file a
claim.
Read all instructions thoroughly before
attempting installation or operation of your
water heater. Keep these instructions for future
reference.
Local plumbing and electrical codes must
be followed in the installation of this water
heater. In the absence of a local code use the
UNIFORM PLUMBING CODE and the NFPA
Code. Local codes may supersede instructions
in this installation manual.
These instructions are a guide for the
correct installation of the water heater.
The manufacturer will not be liable for
damages caused by failure to comply with
the installation and operating instructions
outlined on the following pages.
CAUTION
FAILURE TO FOLLOW THESE INSTRUCTIONS
OR ALL APPLICABLE BUILDING CODES AND
REGULATIONS VOIDS THE WARRANTY
ON THIS WATER HEATER.
Rev 1 2/10
Advertisement
Table of Contents
Related Manuals for Heat Transfer Solar
Summary of Contents for Heat Transfer Solar
-
Page 1: Instruction Manual
Please attach these instructions Please read these and all component next to the water heater. instructions and keep for future reference. Techtanium™ Solar Indirect Water Heater Instruction Manual Warranty, Registration Card and Parts List are included. Homeowner: Please remember to return the Registration Card! - Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNING When using electrical appliances, basic safety precautions to reduce the risk of fire, electric shock, or injury to persons should be followed, including: 1. READ ALL INSTRUCTIONS BEFORE USING THIS WATER HEATER. 2. This water heater must be grounded. Connect only to properly grounded outlet.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section I: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Section II: General Information . -
Page 4: Section I: Specifications
Top Sensor T&P RELIEF Immersion Well VALVE 3/4 NPT Port FROM BOILER (1" NPT) Immersion Well Electric Heating Assembly TO BOILER (1" NPT) FROM SOLAR (1" NPT) Bottom Bottom Sensor FROM SOLAR Sensor Immersion Well (1" NPT) Immersion Well TO SOLAR (1"... -
Page 5: Section Ii: General Information
(by a diptube or bottom inlet). If the hot water demand should exceed the solar heat output or there is an insufficient temperature difference between the heating medium and stored water, the heating element thermostat will activate the electrical heating element for backup heat. - Page 6 SECTION II: GENERAL INFORMATION (cont .) TEmpERATURE CONTROL A solar controller (not provided) shall be used in conjunction with the solar water heater to run all solar components in the heating system. The solar controller will be connected to two thermistors that monitor lower and upper tank temperature. In some cases, only one thermistor (near the bottom of the tank) will be used.
- Page 7 SECTION II: GENERAL INFORMATION (cont .) ANOdE ROdS The anode rod is used as a sacrificial element within the volume of the storage tank. The purpose of the magnesium anode rod is to protect the inside of the tank against corrosion. Anode rods should be inspected twice in the first year and at least yearly once a time interval for inspection has been developed.
-
Page 8: Section Iii: Pre-Installation
The entire solar heating system should be located as close as possible to points of hot water use for the fastest delivery of hot water. This water heater may be installed on combustible flooring. -
Page 9: Section Iv: Installation
Temperature of the primary heat source medium (from solar collector or boiler) shall not exceed 200°F. The outlet of the solar collector should be connected to the water heater at the “FROM SOLAR” fitting. The fitting labeled “TO SOLAR” should be connected to the solar return piping. -
Page 10: Piping Diagrams
SECTION IV: INSTALLATION (cont .) PIPINg dIAgRAmS A piping diagram for a typical solar domestic water heating system based on an indirect water heater with electric heating backup is shown in Figure 3. air vent w/ shut o valve cold water... - Page 11 Figure 4: Two tank system with existing heater Page 11...
- Page 12 SECTION IV: INSTALLATION (cont .) Figure 5 shows an example of a domestic solar heating system based on an indirect water heater with two coils. The domestic water can be heated by the solar system as well as the boiler.
- Page 13 SOLAR CONTROLLER ANd THERmISTORS Two locations for potable water temperature measurement have been provided. The factory installed immersion wells are designed to accommodate insertion of a thermistor. The solar system controller and thermistors are not supplied with this water heater.
-
Page 14: Section V: Operation
Condition 1: The minimum temperature difference (for heat transfer) between the potable water at the bottom of the tank and the solar collector is sensed by the solar controller. In addition, the tank temperature is below the maximum tank temperature setpoint (on solar control). -
Page 15: Section Vi: Maintenance
SECTION V: OPERATION (cont .) CAUTION Hot water in excess of 120°F can cause scalding! The temperature at which injury occurs varies with the person’s age and the time of exposure. The slower response time of disabled persons increases the hazards to them. NEVER allow small children to use a hot water tap. -
Page 16: Section Vii: Troubleshooting
SECTION VI: MAINTENANCE (cont .) FLUSH THE TANk The solar indirect water heater is glass lined. Elements in the water such as lime, iron and other minerals may accumulate in the heater. It is recommended that the tank be drained and flushed thoroughly once a year to prevent buildup in the tank. -
Page 17: Section Viii: Parts List
SECTION VIII: PARTS LIST 14 15 16 17 Table 7: TT-80SCE & TT-119SCE Parts (Single Coil with Electric backup) Part Description Sensor Immersion Well (solar) T&P Relief Valve Leak Detector Drain Valve J-Box Cover Access Cover J-Box Cover (w/ conduit hole) - Page 18 SECTION VIII: PARTS LIST (cont .) Table 8: TT-80DC & TT-119DC Parts (Dual Coil) Part Description Sensor Immersion Well (solar) Leak Detector Anode Rod Cap ("ANODE") Finish Ring Cap (blank) Pipe Nipple (plastic-lined) T&P Relief Valve Drain Valve Immersion Well (for aquastat)
-
Page 19: Section Ix: Warranty
SECTION IX: WARRANTY LImITEd WARRANTy FOR SOLAR WATER HEATER Diversified Heat Transfer Inc. 1710 Flushing Ave, Ridgewood, NY 11385 Phone: 718-386-6666 • Fax: 718-386-7809 What Does This Limited Warranty Cover? This limited warranty applies only to the original consumer purchaser. - Page 20 How Do You Get Service Under the Limited Warranty? In order to be eligible for service under this warranty you MUST return the warranty registration card attached below within 30 days of purchasing the water heater. You may also fill the register form and send it by fax to the Technical department at the following number: 718-386-7809.
- Page 21 What Will Void the Limited Warranty? If you do any of the following, you will void this limited warranty: Fail to return the warranty registration card within 30 days. Fail to retain an original copy of your sales receipt. Fail to retain the actual rating plate from the water heater. Alter or remove the serial number.
