Wireless Network Setup

1. Select Connection > Settings > Configuration > Interface, press ◄/► to select Wierless to connect to a WiFi
wireless network.
2. Select Connection > Settings > Configuration > Wireless Setting, press OK/► to enter.
3. Connection Methods: you can setup the wireless network connection three ways.
- Scan
• Select Wireless setting > Scan, then press OK/►, the TV will scan all available wireless networks within
range. The networks found by the TV will be displayed.
• Select an available access point, then press OK/► to connect the TV to it.
Notes:
- If you select a secure wireless network, you will have to enter the corresponding password to access it.
- This TV will remember the password even if you switch on TV after power off.
- Manual
Select Wireless setting > Manual, then press OK/►, you will be prompted to enter the correct SSID of an
available wireless router to setup the connection.
- Auto
If your wireless networks supports WPS (Wi-Fi Protected Setup), you can connect to the network via PIN
(Personal Identification Number) or PBC (Push Button Configuration). WPS will automatically configure
the SSID and WPA key in either mode.
Select Wireless setting > Auto, then press OK/►to enter.
• PIN: select PIN, then press OK/► to enter. Generate a random PIN code and make sure this code is installed
to the AP (for the procedures, refer to your router manual), then press OK/► again to setup the connection.
• PBC: If your router has a PBC push button, select PBC, then press OK/► to enter. Press PBC push button on
your router within 2 minutes after you press OK/► again. Your TV will automatically acquire all the network
setting values it needs and connect to your network.
Information
Select Connection > Settings > Configuration > Information, press OK/► to display the information on current
connection, such as Interface, Address type, IP address, etc..
IP setting
Select Connection > Settings > Configuration > IP Setting, then press OK/► to enter the IP setting menu.
- Set Address type to Auto, it will acquire and enter the needed IP address automatically.
- You can follow below steps to enter your IP address manually if needed.
• Set Address type to Manual, then press ▼ to go to the first entry field.
• Enter the IP address, Subnet mask, Default gateway, Primary DNS and Secondary DNS values. Use the
digit buttons on your remote control to enter numbers and the arrow buttons to move from one entry field to
another.
- After setting, select Connection > Configuration > Connection Test to check the Internet connectivity again.
Connection Test
Select Connection > Settings > Configuration > Connection Test, then press OK/► to check the Internet
connectivity. If it doesn't work, follow above steps to ensure the connectivity or refer to your Internet Service Provider.
