SPECIAL FEATURES - TODDLER USE
To be used only in a forward-facing position for a child approximately 6 months of age up to
approximately 4 years of age using the in-built harness.
15
14
13
12
11
10
9
8
1. AHR Easy Adjust Headrest Lever
2. Headrest slots
3. Fully adjustable 6 point harness
4. Armrests (if fitted)
5. Red seatbelt path labels (Booster
Seat)(1 each side)
6. Recline Foot in upright position
7. Cup Holder 1 each side (if fitted)
8. Harness Adjustment Strap
9. Harness Adjustment Button
10 Instructions for Installation & Use - Series No. 8100/A/2010
Harness Tongues
10. Padded cover for comfort
11. Quick release harness
Buckle (Red button)
12. Padded insert (if fitted)
13. Shoulder Pads (if fitted)
14. Shoulder Height Markers
15. Adjustable Headrest
1
2
3
4
5
16
6
7
16. Car's lap-sash seat belt or lap belt
17. Car's Anchor Fitting
3
18. Upper Anchorage Strap Adjuster
Harness
19. Upper Anchorage Storage Band
Buckle
20. Adjustable Upper Anchorage Strap
21. Attachment Clip
NOTE: Not all features are supplied on some models. "If fitted" is used to indicate some of the
features that may not be on the seat supplied.
SPECIAL FEATURES - TODDLER USE
18
6
Instructions for Installation & Use - Series No. 8100/A/2010
21
20
19
17
11
