Toshiba Strata DK/CTX System
LinkPlus Interface Guide
SpectraLink 6000 System
SpectraLink 8000 System
January 2008 Edition
1725-36145-001
Version D

Advertisement

loading

  Also See for Toshiba Strata DK

  Related Manuals for Toshiba Strata DK

  Summary of Contents for Toshiba Strata DK

  • Page 1 Toshiba Strata DK/CTX System LinkPlus Interface Guide SpectraLink 6000 System SpectraLink 8000 System January 2008 Edition 1725-36145-001 Version D...
  • Page 2 LinkPlus Interface Guide: Toshiba Strata DK/CTX System Trademark Information Notice Polycom® and the logo designs Polycom, Inc. has prepared this document for SpectraLink® use by Polycom personnel and customers. The LinkPlus drawings and specifications contained herein Link are the property of Polycom and shall be neither...
  • Page 3: About This Guide

    About this Guide Polycom is the market leader in multi-cellular wireless telephone systems for the workplace. We manufacture a range of products to suit any size installation. All Polycom products use our LinkPlus digital integration technology to integrate with various digital switch platforms.
  • Page 4: Related Documents

    LinkPlus Interface Guide: Toshiba Strata DK/CTX System Related Documents SpectraLink 6300 MCU : Operator’s Console (1725-36125-001) SpectraLink 6100 MCU: Installation and Operation (1725-36097-001) SpectraLink 8000 Telephony Gateway: Administration Guide for SRP (1725-36028-001) SpectraLink e340/h340/i640 Wireless Telephone: Configuration and Administration (72-1065-09)
  • Page 5: Icons And Conventions

    About this Guide Icons and Conventions This manual uses the following icons and conventions. Caution! Follow these instructions carefully to avoid danger. Note these instructions carefully. Label This typeface indicates a key, label, or button on SpectraLink hardware. 1725-36145-001_D.doc...
  • Page 7: Plan The Interface

    Plan the Interface The system administrator programs the telephone system for use with the Wireless Telephone System using the normal administration terminal or procedures. Programming can be done after the handsets are registered. Recommended programming includes assigning extension numbers to the handsets and programming features on the telephone system so they are easily accessible from the handsets.
  • Page 8 LinkPlus Interface Guide: Toshiba Strata DK/CTX System “model” handsets then use the model as a template to program the other handsets. • All handsets are different: All handsets are programmed differently, so each handset will be programmed individually. Before installation, verify the features assigned to the wired telephones to plan the system and extension programming required for the handsets.
  • Page 9: Assign Extension Numbers

    Plan the Interface on the handsets. These assignments should emulate assignments on the user's wired set. Assign Extension Numbers The wire contractor should inform the system administrator which port numbers have been designated for the handsets. The system administrator may use the Extension Assignments Worksheet at the end of this document to track the port numbers, extensions, users, and features assigned to handsets.
  • Page 10: Feature Programming Requirements

    LinkPlus Interface Guide: Toshiba Strata DK/CTX System Feature Programming Requirements When planning the interface, the following information must be taken into account: Line sequences The handset uses two types of key sequences to access PBX features and multiple lines. Line sequences are those where the user presses key and then a number key.
  • Page 11 Plan the Interface SpectraLink 6100 MCU For the SpectraLink 6100 MCU, the handset function menu text can only be changed via remote configuration through the services of Polycom’s Customer Support. SpectraLink 8000 Telephony Gateways Function menu text options can be changed in the Administration Console of the SpectraLink 8000 Telephony Gateways.
  • Page 12 LinkPlus Interface Guide: Toshiba Strata DK/CTX System follow the cadence provided by the system switch. Call progress tones provided by the host system will be passed through to the handset. PN: 1725-36145-001_D.doc...
  • Page 13: Interface Implementation

    Interface Implementation This section describes the recommended programming to use the Wireless Telephone System with a Toshiba Strata DK/CTX key telephone system. The procedures assume: • The Toshiba system is installed and operational in an approved configuration. See the Telephone Switch Interface Matrix document for tested configurations.
  • Page 14: Key-Mapping The Handset To Emulate 2020-Sd Functionality

    LinkPlus Interface Guide: Toshiba Strata DK/CTX System Configuration. Scroll to Telephone Switch Type and press enter to change this field, from the Submenu of PBX types, select Toshiba. Refer to SpectraLink 8000 Telephony Gateway: Administration Guide for SRP for details on configuring the Telephone Switch Type.
  • Page 15: Program Toshiba

    PICK PAGE FCN + 9 EXIT MENUS Program Toshiba Station features Perform the necessary system programming using a 20-button LCD digital or electronic telephone connected to Port 005. All or a group of handsets can be programmed at one time by entering a range of ports.
  • Page 16 LinkPlus Interface Guide: Toshiba Strata DK/CTX System • Use Program 41 to restrict outgoing calls on this handset, if desired. • Use Program 48 to assign a class of restriction to the handset. Use Program 58-5 to assign one or more of the handsets to receive •...
  • Page 17: Extension Assignments Worksheet

    Extension Assignments Worksheet Shelf: _______ Interface Module: _______ Interface Handset Handset # Ext. # Name Module Comment Serial # Circuit # Handset 1 Handset 2 Handset 3 Handset 4 Handset 5 Handset 6 Handset 7 Handset 8 Handset 9 Handset 10 Handset 11 Handset 12 Handset 13...
