Summary of Contents for HIKVISION DS-9000HFI-ST Series
-
Page 1: Quick Start Guide
First Choice For Security Professionals Quick Start Guide Hybrid DVR DS-9000HFI-ST Series Hybrid DVR DS-9600NI-ST Series NVR NOTE: For more detailed information, refer to the User’s Manual on the CD-ROM. You must use your PC or MAC to access the files. -
Page 2: Quick Start
9. Network Connection 10. Configure IP Cameras (Only for DS-9000HFI-ST Series Hybrid DVR and DS-9600NI-ST Series NVR) NOTE: For more detailed information, refer to the User’s Manual on the CD-ROM. You must use your PC or MAC to access the files. -
Page 3: Front Panel Description
HYBRID DVR/NVR/ANALOG 1. Overview BEFORE STARTING: Connect VGA monitor and mouse (mouse supplied). Check that your package includes the following: Hybrid/Analog DVR Mouse IR Remote Power Cord Screws Hard Drive (PreInstalled) HDD Cables Rack Mount Ears Quick Start Guide Manual/Software CD Front Panel Description: 1. -
Page 4: Startup And Shutdown
Analog Dome Analog Camera IP Dome IP Camera NOTE: DS-9000HFI-ST Series Hybrid DVR support both Analog and IP cameras. DS-9600NI-ST Series NVR support only IP cameras. 3. Startup and Shutdown To startup your DVR: 1. Plug power cord into DVR and electrical outlet. It is HIGHLY recommended to use a surge protector. -
Page 5: Formatting A Disk
First Choice For Security Professionals 3. Startup and Shutdown (cont.) To shut down your DVR: OPTION 1: Standard Shutdown 1. Enter the Shutdown menu by going to Main Menu > Maintenance. 2. Click Shutdown button to access the Shutdown menu. 3. -
Page 6: Setting Date And Time
HYBRID DVR/NVR 4. Formatting a Disk (cont.) 3. Click the Init button. 4. A confirmation message will appear on the screen. Click the OK button to continue formatting process. 5. The status column will show the Initialization progress. After the disk has been formatted, the status of the disk will change to Normal. - Page 7 7. Select the Apply button to save the schedule settings and click to return to the previous menu. Clicking without clicking Apply will go out of the menu without saving settings. NOTE: Event recordings are recordings that are triggered from motion detection and/or from an external alarm. www.hikvision.com...
- Page 8 First Choice For Security Professionals 7. Playback Playback from Search: 1. Enter the Playback menu by going to Main Menu > Playback. 2. Select the camera and date you want to search. 3. The search results will be shown on the timeline with blue bars designating recorded files.
- Page 9 HYBRID DVR/NVR 8. Backup Backup recorded files (Export): 1. Enter the File Management menu by going to Main Menu > File Management 2. Place a check next to the cameras you want to search files for backup. Select the recording type, date and time range you want to backup.
-
Page 10: Network Connection
Network Connection Using Web Browsers All Hikvision products use the default IP address of 192.0.0.64 1. Connect a CAT5 or CAT6 cable from the DVR to a PC or Laptop computer. Note your laptop or PC computers existing address, such as: 192.0.0.62... -
Page 11: Adding Ip Cameras
HYBRID DVR/NVR/ANALOG 10. Adding IP Cameras Adding IP Cameras Directly on the Hybrid DVR and NVR’s Menu: 1. Enter the Add/Remove Cameras menu by going to Main Menu > Cameras Setup > Cameras. 2. Select the IP Camera tab. 3. Click the Search button to automatically detect connected IP cameras on the network. 4. - Page 12 First Choice For Security Professionals 908 Canada Court City of Industry, CA 91748 U.S.A. www.hikvision.com...
