- Page 1 It is available to download contents of this user manual and programs provided by software CD from M3 Mobile homepage. Please be sure to read the “Warnings and Safety Precautions” in order to use the product safely and correctly.
-
Page 2: Notice
Notice • All contents of this user manual are protected by the copyright laws, and M3 Mobile owns all rights related to them. • Any part of this document cannot be copied, reproduced, modified, or translated to other languages without the prior written consent of M3 Mobile. -
Page 3: Copyright And Agreement On Usage
• M3 Mobile does not guarantee the quality of the programs produced by third party software companies installed after the release from the factory of M3 mobile. •... -
Page 4: Warnings And Cautions For Safety
The product was designed to be suitable for work environments, but avoid impacts or dropping the product. This may cause fatal damage to the product. • Fully charge the battery before using the product for the first time. M3 Orange User Manual... - Page 5 Computer Program. • Using the lost or stolen mobile phone is the act of receiving stolen goods. • Holding a found mobile phone as turing off the power is a larcenous act or embezzlement of deserted articles. M3 Orange User Manual...
-
Page 6: Table Of Contents
Warnings and Cautions for Safety ....4 Inserting and Removing Micro SD Card ..28 Table of Contents ........... 6 Usage for various functions ...29 M3 Orange Introduction ....7 Using Mobile phone ........30 Specification and Characteristics ....8 Using Internet ..........34 Product Configuration ........ -
Page 7: M3 Orange Introduction
M3 Orange Introduction Specification and Characteristics Product Configuration Name and Function of Each Part Inserting and Removing the Battery Charging LED Information Inserting and Removing USIM CARD... -
Page 8: Specification And Characteristics
Specification and Characteristics Classification Information Product Name M3 Orange MARVELL PXA-320 806Mhz Windows Mobile 6.5 NAND 128 / 256MB / 1G System 256MB 240 x 320, 3.5”, Color TFT LCD(260,000Color) Display Backlight LED Type The Americas - EGSM-850 / GSM-1900... - Page 9 Etc. Operating Temperature -10 ˚C ~ + 50 C (Main Unit / Adapter) Input : AC 220V Adapter Power Output : DC 5.2V / 5A Battery Lithium Ion 3,300mA/h IP54(DUST & WATER PROOF) Impact 1.5m drop M3 Orange User Manual...
-
Page 10: Product Configuration
Two Standard Batteries USB Cable Portable Adapter ORANGE www.m3mobile.net It is available to download contents of this user manual and programs provided by software CD from M3 Mobile homepage. Stylus Pens Earphone Manual CD Manual • Not all items above may be included according to the shipment option. -
Page 11: Name And Function Of Each Part
Name and Function of Each Part M3-Orange Main Unit Barcode Scanner Window External memory card Camera Button cover Antenna Scanner LED(left) GSM/WCDMA LED(mid) Charging LED(right) Flash Receiver Camera Volume Scanner button Stylus LCD Touch Screen Reset button Scanner Button Battery Detachment Button... - Page 12 (External serial connection, etc) When using Ethernet Cradle Ethernet: Enables use of Ethernet function for Main Unit • USB Host and USB Ethernet are optional functions. • Optional functions or items that were not purchased cannot be used. M3 Orange User Manual...
-
Page 13: Inserting And Removing The Battery
Insert the battery to the battery pack position, and then cover the ribbon. After putting the battery cover, tighten a screw in a counterclockwise direction. Removing Battery • Loosen a screw in a clockwise direction, and remove the battery cover. After removing the battery cover, pull out the battery by drawing the ribbon. M3 Orange User Manual... -
Page 14: Charging
Improper battery replacement may cause an explosion. • When the battery is completely discharged, connect the adapter and reset the device to check whether the LCD turns on, and then use the device after charging for at least 10 minutes. M3 Orange User Manual... -
Page 15: Led Information
The charging status of the battery attached to the M3 Orange can be checked through LED on the upper left side of the M3 Orange. The charging status of the aux. battery can be checked through the LED on the lower right corner of the cradle. -
Page 16: Inserting And Removing Usim Card
• Insert USIM CARD with the terminals facing downward. • Insert the battery and cover the Ribbon, tighten up the battery cover. • Turn on the power of terminals and check if it is installed correctly. M3 Orange User Manual... -
Page 17: Basic Instructions
Basic Instructions Button Information Soft Reset Main Window Using the Stylus Transcriber / Keyboard ActiveSync Inserting and Removing Micro SD Card... -
Page 18: Button Information
End Button Long Press: Phone On/Off Up / Down Button Volume up and down Function mode Camera Button Execute camera / Take picture Enter Button Operation Button Scanner Button Scanner beam operation BackSpace Delete the letter M3 Orange User Manual... -
Page 19: Soft Reset
Click the Reset Button when one of installed software programs causes unexpected problems while you use the device. All currently running software will be terminated upon software reset and working files or data might be lost, but the existing stored data of files are not affected. Soft Reset M3 Orange User Manual... -
Page 20: Main Window
Show the received message Task information Show the task information Lock Screen Quick guide Show the simplified user manual Contact Phone Lock screen Show the screen or lock the information Phone / Contact Operate the phone program M3 Orange User Manual... -
Page 21: Using The Stylus
This function is frequently used for the touch screen. Click the item once to select or execute file copy, cut, and paste functions, or to use (In case of excuting the scroll bar, drag function will not the keyboard. be excuted.) M3 Orange User Manual... -
Page 22: Transcriber / Keyboard
Transcriber : When you enter the letter, number, symbol with stylus, this program automatically writes where the cursor is positioned. You don’t have to care about the input section. Screen for selecting Transcriber Block Recognizer Transcriber Letter Recognizer M3 Orange User Manual... - Page 23 • You choose the input method by clicking icon at the bottom of screen. • You can enter the text by touching the keyboard directly. Screen for selecting Keyboard Small Keybard Big Keyboard Options M3 Orange User Manual...
-
Page 24: Activesync
Never connect the USB of the cradle to the USB port of the PC before installing the Active- Sync program. As Microsoft’s PDA device driver software is included in the ActiveSync, con- necting before installing may cause problems since the PDA device may not be recognized by your PC. M3 Orange User Manual... - Page 25 The device cannot be synchronized with Outlook Express that comes with Windows, and Microsoft Outlook or later versions of the program must be installed on the PC. Warning! • Strong external noise from static electricity around the system may disturb the connection. In this case, retry the synchronization. M3 Orange User Manual...
-
Page 26: Synchronizing Data
The synchronization process compares the data on the PC and PDA, and updates the data on both sides with the latest data. Personal schedule manager data or files can also be synchronized with the corresponding files on the PC. M3 Orange User Manual... - Page 27 Check whether the USB cable is properly connected to the cradle and the PC’s USB port. • Check whether the power of the M3 and LCD is on. • Select File > Connection Setting from the ActiveSync program, and then open the window.
-
Page 28: Inserting And Removing Micro Sd Card
Once inserting Micro SD Card, [Storage Card] icon appears in [Start] [File Explorer] [Show] as below. • Click [Storage Card] icon and check the contents in Micro SD Card. (Refer to the progress below.) Inserting the Memory card M3 Orange User Manual... -
Page 29: Usage For Various Functions
Usage for various functions Using Mobile phone Using Internet Using Scanner Using Camera Bluetooth communication... -
Page 30: Using Mobile Phone
Select ear-microphone button in the screen of incoming calls and make calls. • When choosing the mute mode in the screen of incoming calss, the screen keeps appeaing but there is no sound. Call key Main screen Screen for incoming calls M3 Orange User Manual... -
Page 31: Making A Call
When the phone number is registered as the shortcut key, you can make a call with the shortcut key by pressing long the corresponding number. • Make a call with the recent list by pressing long the button of ear-microphone. Make a call by dialing Make a call by searching the Screen of dialing contact list M3 Orange User Manual... - Page 32 You can send the message according to the priority. (Normal / Express / Urgent) • Message that you often use can be put in the input box as using the saved message. • Sent message will be saved automatically in the SMS sent list. Screen of sending SMS M3 Orange User Manual...
- Page 33 Phone : You can chage the setting of ring tone or keypad. Security : You can set up security service. Services : You can change the setting of mobile service. Network : You can change the setting of mobile center. Phone setting M3 Orange User Manual...
-
Page 34: Using Internet
Today screen. • After choosing AP device that you want to connect in the Wireless connection program, and connet. • If you get correct IP after connecing Wireless LAN, you can use the Internet service. Wi-Fi setting M3 Orange User Manual... - Page 35 • You can seach the Internet on the main site or move to the other site by entering the web address in the address bar. Bookmark Previous Keyboard Zoom in / out Menu Internet explorer menu M3 Orange User Manual...
-
Page 36: Using Camera
Video : Video mode Camera button Select [Menu] [Video]/[Still], and it converts video / camera mode mutually. • My Pictures : Check the photograph/ video taken. Select [Thumbnails] in the shooting mode. STILL MODE VIDEO MODE My Pictures M3 Orange User Manual... - Page 37 Taking a photograph • Auto-focus : Adjust the fucus automatically by selecting Trigger AF in menu before shooting. • Shooting : In Camera-on mode, take a picture, record or end a video by pressing Camera or Enter key. M3 Orange User Manual...
-
Page 38: Using Scanner
Usage for laser scanner Barcode Scanner Scanner Button Correct method for scanning Incorrect method for scanning Warning! • Scanner is Option item. When Scanner is not set up in your product, you cannot use Scanner function. M3 Orange User Manual... - Page 39 Correct method for scanning Incorrect method for scanning Incorrect method for scanning Warning! • Mid-guideline of scanning turns ‘Green’. • If you put Mid-guideline too closely to Barcode or it is dislocated, it cannot be read. M3 Orange User Manual...
-
Page 40: Bluetooth Communication
Turn on the mobile and BT device that will be conncted. • Select [Wireless Manager] in Today screen. • Connect it after choosing the BT device in the BT connection program. • Enter Passcode, and use the BT device. M3 Orange User Manual... -
Page 41: Breakdown Diagnosis
Breakdown Diagnosis Breakdown Diagnosis... -
Page 42: Breakdown Diagnosis
Check whether the mobile is installed to Cradle correctly. • Check whether the adapter jack is inserted well. • Check whether LED that diplays the charging status lights on. Keep touching the LCD screen in the unintentional spot. • Try to adjust the monitor. M3 Orange User Manual... -
Page 43: Customer Support & A/S
Customer Support & A/S Customer Support & A/S Product Warranty... -
Page 44: Customer Support & A/S
Product line : 202 Chun-ui Techno park 2, 201-610, Chun-ui dong, Won-Mi gu, Bucheon Service hours: 9am~6pm, weekdays. No service on holidays. Inquiries about the program / Requisition A/S via Web-site • You can access Korean internet domain M3 Mobile. • Korean domain: Website: http://www.m3mobile.co.kr M3 Orange User Manual... -
