- Page 1 User Manual Version 2.0 © 2020...
-
Page 2: Cautions When Using This Manual
Thank you for purchasing M3 SL10K. This device provides high performance data collection and mobile communications that meet industrial standards. This user manual enables users to know the characteristics of M3 SL10K series and how to use it. Caution Please carefully read this manual before using the device to ensure safe and proper use, ⚫... -
Page 3: Copyright
M3 Mobile. Trademarks M3 Mobile and M3 logos are registered as trademarks of M3 Mobile. ⚫ M3 SL10K is a registered trademark of M3 Mobile Co., Ltd. -
Page 4: Safety Rules
Safety Rules Do not use the device while driving. ⚫ Traffic accidents may occur. ✓ Observe the rules on device use while driving. ✓ Do not touch the power plug with wet hands. ⚫ You may be electrocuted. ✓ Be careful when using the battery. ⚫... -
Page 5: Revision
Be careful when a headset is used. ⚫ Avoid long-term exposure to loud sounds to prevent damage to your hearing. ✓ Loud sounds while walking or driving distract your attention and may cause traffic ✓ accidents. Revision Release date of version 1.0: July 2019 Initial distribution ⚫... -
Page 6: Table Of Contents
Table of Contents Cautions When Using This Manual ................2 Caution ......................2 Copyright ...................... 3 Trademarks ....................3 Instructional Icons ....................3 Safety Rules ..................... 4 Revision ......................5 Table of Contents ....................6 Getting Started ..................9 Package Contents ....................... 9 1.1.1 Device and Accessories .................... - Page 7 2.3.3 Home Screen ......................21 2.3.4 Dock Bar ........................21 Data Input ........................22 2.4.1 Virtual Keyboard......................22 Device Reset ....................... 22 2.5.1 Soft Reset (1) ....................... 22 2.5.2 Soft Reset (2) ....................... 23 Connecting with a PC ....................26 Using the Application Screen ......................
-
Page 9: Getting Started
Getting Started Package Contents 1.1.1 Device and Accessories The M3 SL10K package includes the following items: <Battery> <Quick Manual > <M3 SL10K> <BOOTS> <Adapter> <USB Cable> If one or more items above are damaged or are not included in the package, contact the store where you purchased the device. -
Page 10: Battery
Insert the battery from the bottom in the right direction. ⚫ After inserting the battery, slide the Slide button to the left to fix the locking device. ⚫ M3 SL10K uses 3.8 V 4,500mAh Li-ion Battery. If an unapproved battery is used, it may explode. ⚫... -
Page 11: Charging The Battery
Before the battery is removed, Save the data being used. M3 SL10K can be used for up to 7 hours after the battery is fully charged. (The maximum time of using device depends on usage environment of a user.) - Page 12 AC adaptor is made to be used in 100–240V input, 5V output. If a voltage beyond the range is supplied, the device may be seriously damaged. LED Color Description Battery is being charged. Green Battery is fully charged. If the battery is used at the temperature other than -20 C (-4 F) to 50 C (122...
-
Page 13: Turning The Device On/Off
Turning the Device On/Off 1.3.1 Turning the Device On Press and hold Power button until the device vibrates. This will turn the device on and initial screen will display. If the battery is completely discharged, problems may occur when the device is turned on. -
Page 14: Turning The Device Off
1.3.3 Standby Mode If the device is not used for a long time, M3 SL10K automatically shifts to standby mode to decrease battery consumption. To manually set the device in standby mode, lightly press the Power button. -
Page 15: Memory Card
Memory Card 1.4.1 Inserting an External Memory Card The Micro-SD card is used as an external memory of M3 SL10K. After removing the battery, insert SD memory card into the Micro-SD card slot. -
Page 16: Checking Data
To insert Micro-SD card, Remove battery cover on the rear of the device and pull out the battery. Android 8.1 Oreo , the OS used in M3 SL10K, can support up to 64 GB for external memory. 1.4.2 Checking Data Information stored in the Micro-SD card can be checked by swiping bottom →... - Page 17 SIM Card 1.5.1 Inserting the SIM Card SIM card supports voice call and data transfer through mobile communications. The card should be the one verified by a local network supplier. To insert SIM card, Remove battery cover on the rear of the device and pull out the battery. Either the front or back of the SIM card can be connected to dual slot.
-
Page 18: Basic Use
Basic Use Features Device Layout... -
Page 19: Key
2.2.1 Button Button Description Scanner Operate scanner while executing scanner program. Volume High Increase volume. Volume Low Decrease volume. Camera Take pictures while executing camera program. Back Return to previous stage. Home Go to Home screen. Menu Display menu. Function Execute the work set to the button. -
Page 20: Status Bar
2.3.1 Status Bar The Status Bar displays status of the device. Icon Icon Name Description Battery Battery charging status or battery residual capacity Phone Call strength or no signal Sound / Vibration Sound or Vibration status of the device Wi-Fi Wi-Fi connection/disconnection Bluetooth Bluetooth connection/disconnection... -
Page 21: Home Screen
On the Home Screen, there are shortcut icons of main programs. A shortcut icon can be added or deleted. Icon Icon Name Description Setting Set M3 SL10K. E-mail Send or receive an e-mail. Play Store Run Play Store. Calendar Set, manage, or reserve a schedule. -
Page 22: Data Input
On the Dock Bar, up to four shortcut icons may be added or deleted. Icon Icon Name Description Phone Receive or make a call. Camera Manage address book. Message Receive or send a text message. Internet Enable Internet Data Input 2.4.1 Virtual Keyboard If focus is located in the input screen, the virtual keyboard will be automatically displayed. -
Page 23: Soft Reset (2)
2.5.2 Soft Reset (2) Long Press Power button more than 30sec. The program being executed will end, and the data or file being used will also be deleted. However, the stored data or file will not be affected by Soft Reset. 2.5.3 Factory Reset If serious problem occurs in the device or problem is not solved through Soft Reset, Perform factory reset. - Page 24 Check if Erase internal SD card is checked. → Reset device. → Erase everything ⚫ According to options, documents in internal SD card or Micro-SD card may be ⚫ deleted. As such, please check the options. All settings will be reset. Factory Reset Protection (FRP) Feature What is Device Protection, or Factory Reset Protection (FRP)?
- Page 25 Android devices provide built-in security features you can use to protect your device and information, including screen locks and data encryption. Data protection, or Factory Reset Protection (FRP), is a security feature on Android devices with Lollipop 5.1 or higher. FRP is automatically activated when you set up Google Account on your device.
-
Page 26: Connecting With A Pc
If you can't remember any of your Google Account information, you can send your device, along with proof of purchase, to an authorized M3Mobile supplier. M3 has special tools to reset the phone to factory defaults with no protection enabled. - Page 27 Charge this device – This mode is only for charging a device. Data cannot be sent. ⚫ Transfer files – Send files to another device. ⚫ Transfer photos (PTP) – Send photos or files. ⚫ Use device as MIDI – Use as Musical Instruments App. ⚫...
-
Page 28: Using The Application Screen
Using the Application Screen Phone Function M3 SL10K supports the 2G (GSM, CDMA), 3G (UMTS, HSPA+) and 4G (LTE) networks. 3.1.1 Basics Press the icon to use the Phone menu. Press the ) icon to see the recent call history. -
Page 29: Wi-Fi
Wi-Fi 3.2.1 Setting the Wi-Fi Feature Activating the Wi-Fi feature Swipe the bottom Click Settings and set the WLAN menu to ON/OFF to activate or → deactivate the Wi-Fi feature. -
Page 30: Scanner
If necessary, Enter password to complete the access. Scanner M3 SL10K provides 1D or 2D scanner as an option. For detailed information on available options, please contact the local distributor or refer to our Web site. (Homepage: http://www.m3mobile.net). 3.3.1 How to Use Scanner M3 Mobile provides the program needed to use a scanner by default. -
Page 31: Using The Scanner
3.3.2 Using the Scanner Place the device toward a targeted barcode and press Scan button. The laser beam of the scanner should completely cover barcode as shown in the following. <1D Scanner> <2D Scanner> 1. Do not look at the laser beam directly. (CLASS 2 LASER PRODUCT 1.0 mW, MAX OUTPUT: 650 nm) 2. -
Page 32: Bluetooth
Bluetooth 3.4.1 Setting the Bluetooth Feature A Bluetooth device frequently used can be registered, or M3 SL10K can be searched in another device. Activating the Bluetooth feature Click Settings and set the Bluetooth tab to ON/OFF to activate or deactivate Bluetooth feature. - Page 33 If the “Bluetooth pairing request” screen is displayed, enter PIN code of the Bluetooth device to complete access to the device. The device is tested in general conditions wherein the device is 0.5 cm apart from a user. To meet the radiation safety and protection standards of the Ministry of Science, ICT and Future Planning, the device and the antenna should be 0.5...
-
Page 34: Nfc
cm or more from a user regardless of the antenna use. It is recommended to refrain from using a metal belt clip, case, or accessory. Do not wear an accessory keeping 0.5 cm or shorter from the back part of the device or one that does not meet the radiation safety and protection standards of Ministry of Science, ICT and Future Planning. -
Page 35: Connecting The Nfc Feature
3.5.2 Connecting the NFC Feature Connecting with the NFC Device Open Web page or screen of a video, photo or contact. Place back part of the NFC device toward back part of M3 SL10K. Touch the screen. Data transfer would then start. - Page 36 10 m. Connecting to the NFC Chip / Tag Card Hold M3 SL10K as shown below. Do not cover the antenna area of a battery cover with your hands. Place M3 SL10K near NFC chip or tag card until data transfer is completed.
-
Page 37: Advanced Use
4. Advanced Use 4.1 OS Update The M3 Mobile distributes new OS to improve the quality and performance of a product. To check OS version of the device, Swipe the bottom → Click Emota → Check update and select the OS version. - Page 38 The OS of M3 SL10K can be updated through two methods. Use Micro-SD card and OS download to use Local update Connect the device with PC iii. OTA update For detailed information on OS update, please refer to the “OS” item of the M3 FAQ (FAQ download).
-
Page 39: Others
5. Others 5.1 SL10K-N Device Specifications Physical Features Wireless Communication Specification 155.8 x 72 x 25 mm Size CMCC 5M： (W x L x H) LTE 1/2/3/4/7/17/20/38/39/40/41 WWAN mm/inch 6.13 x 2.83 x 0.98 inch WCDMA 1/2/5/8 TD-SCDMA 34/39 Weight 292 g / 10.3 oz (Device unit) GSM 2/3/5/8 WIFI 802.11(a/b/g/n) -
Page 40: Sl10K-W Device Specifications
5.2 SL10K-W Device Specifications Physical Features Wireless Communication Specification 155.8 x 72 x 25 mm Size (W x L x H) WWAN mm/inch 6.13 x 2.83 x 0.98 inch Weight 292 g / 10.3 oz (Device unit) WIFI 802.11(a/b/g/n) 4.0"TFT LCD, 480 x 800 IPS Wireless LAN Frequency 2.4G+5.8G Screen... -
Page 41: Service
Service If you have any questions or complaints with using our product, please contact M3 Service Center or visit our Web site (http://itc.m3mobile.net). We do our best to immediately respond to your inquiry. The M3 FAQ document may help resolve general problems.
