Pioneer DEH-P3370XM UC Service Manual

Multi-cd control high power cd player with xm/fm/am tuner
Hide thumbs Also See for DEH-P3370XM UC:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual, Installation Manual
Service
Manual
MULTI-CD CONTROL HIGH POWER CD PLAYER WITH XM/FM/AM TUNER
DEH-P3370XM
- This service manual should be used together with the following manual(s):
Model No.
Order No.
CX-977
CRT2624
- This product has the unit part numbers as below.
Unit Part No.
Description
CPN1760
CD Player
CPN1761
XM Tuner
*) The unit part numbers listed above are not for the service components.
- CD Player Service Precautions
1. For pickup unit(CXX1480) handling, please refer
to"Disassembly"(see page 85).
During replacement, handling precautions shall be
taken to prevent an electrostatic discharge(protection
by a jumper-solder).
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST .......................2
4. PCB CONNECTION DIAGRAM ................................40
5. ELECTRICAL PARTS LIST ........................................56
6. ADJUSTMENT..........................................................66
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2001
Mech. Module
Remarks
S9
CD Mech. Module:Circuit Description, Mech. Description, Disassembly
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
2. During disassembly, be sure to turn the power off
since an internal IC might be destroyed when a con-
nector is plugged or unplugged.
3. Please checking the grating after changing the ser-
vice pickup unit(see page 68).
7. GENERAL INFORMATION .......................................85
7.1 DIAGNOSIS ........................................................85
7.1.1 DISASSEMBLY .........................................85
7.1.2
7.2 PARTS .................................................................90
7.2.1 IC................................................................90
7.2.2 DISPLAY ..................................................107
7.3 OPERATIONAL FLOW CHART .........................108
8. OPERATIONS AND SPECIFICATIONS...................109
K-ZZS. AUG. 2001 Printed in Japan
ORDER NO.
CRT2752
UC
89
