HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

SERVICE MANUAL

MODEL NAME
KDL-52S4100
KDL-52S4100
ORIGINAL MANUAL ISSUE DATE: 10/2008
:UPDATED ITEMS
REVISION DATE
10/2008
12/2008
9-883-808-02
REMOTE COMMANDER
RM-YD025
RM-YD025
SUBJECT
No revisions or updates are applicable at this time.
Updated G Board Schematic. Replaced pages 44-46.
DESTINATION
US
CANADA
LCD DIGITAL COLOR TELEVISION
FX
CHASSIS

Advertisement

Table of Contents
loading

Related Manuals for Sony KDL-52S4100

Summary of Contents for Sony KDL-52S4100

  • Page 1: Service Manual

    HISTORY INFORMATION FOR THE FOLLOWING MANUAL: SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION KDL-52S4100 RM-YD025 KDL-52S4100 RM-YD025 CANADA ORIGINAL MANUAL ISSUE DATE: 10/2008 :UPDATED ITEMS REVISION DATE SUBJECT 10/2008 No revisions or updates are applicable at this time. 12/2008 Updated G Board Schematic.
  • Page 2 SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION KDL-52S4100 RM-YD025 KDL-52S4100 RM-YD025 CANADA KDL-52S41000 RM-YD025 LCD DIGITAL COLOR TELEVISION 9-883-808-02...

  • Page 3: Table Of Contents

    KDL-52S4100 TABLE OF CONTENTS SECTION TITLE PAGE SECTION TITLE PAGE Specifi cations ................. 4 SECTION 3: DIAGRAMS ..............21 3-1. Circuit Boards Location ............21 Warnings and Cautions - ENGLISH ..........6 Warnings and Cautions - FRENCH ..........7 3-2. Printed Wiring Boards and Schematic Diagrams Information .........

  • Page 4: Specifi Cations

    KDL-52S4100 SPECIFICATIONS Power Requirements 120V - 240V AC, 50/60Hz HDMI IN 1/2/3: HDMI VIDEO (IN) 1/2: Video: 480i, 480p, 720p, 1080i, 1080p, 1080/24p S Video (4-Pin Mini DIN) (Video 1 only) Audio: Two channel linear PCM 32, 44.1, and 48 kz, Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative...
  • Page 5 KDL-52S4100 KDL-52S4100 Power Consumption in use 295W in standby Less than 1.0 W Speaker Output (W) 10W + 10W Speaker/Full Range (2) 65 x 147 mm Dimensions (W x H x D) with stand 1274 x 873 x 346 x 34...

  • Page 6: Warnings And Cautions - English

    Components identifi ed by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operation are identifi...

  • Page 7: Warnings And Cautions - French

    Les composants identifi es par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces sont d’une importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le present manuel ou dans des supplements publies par Sony.

  • Page 8: Safety-Related Component Warning

    KDL-52S4100 SAFETY-RELATED COMPONENT WARNING There are critical components used in LCD color TVs that are important for safety. These components are identifi ed with shading and mark on the schematic diagrams and the electrical parts list. It is essential that these critical parts be replaced only with the part number specifi...
  • Page 9 Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com KDL-52S4100...

  • Page 10: Safety Check-Out

    KDL-52S4100 SAFETY CHECK-OUT The AC leakage from any exposed metal part to earth ground and After correcting the original service problem, perform the following from all exposed metal parts to any exposed metal part having a safety checks before releasing the set to the customer: return to chassis, must not exceed 0.5 mA (500 microamperes).

  • Page 11: Self-Diagnostic Function

    KDL-52S4100 SELF-DIAGNOSTIC FUNCTION IMPORTANT: The units in this manual DO NOT contain a self-diagnostic function. If an error occurs, the TV will not stay on. It is our recommendation that if a repair is required for this set, the technician should bring both the A Board and the G Board to the customer location.

  • Page 12: Section 1: Disassembly

    KDL-52S4100 SECTION 1: DISASSEMBLY 1-1. REAR COVER REMOVAL Remove 2 screws from HDMI connectors Remove 2 screws from terminal positions Remove 4 screws Remove 20 screws Rear Cover 1-2. FUNCTION KEY AND H1 BOARD REMOVAL Slide out Function Unit from Bezel...

  • Page 13: A Board And G Board Removal

    KDL-52S4100 1-3. A BOARD AND G BOARD REMOVAL Remove 1 screw from Side Bracket Remove 1 screw from HDMI position Disconnect 4 connectors Remove 2 HEX screws Remove 8 screws Remove 9 screws Remove 1 FH screw Remove Hexagon Nut from tuner...

  • Page 14: Table-Top Stand Assembly And Under Cover Removal

    KDL-52S4100 1-4. TABLE-TOP STAND ASSEMBLY AND UNDER COVER REMOVAL Place the TV set face down onto the soft cloth Remove 4 screws Remove 1 screw Table-Top Stand Assembly Under Cover Bottom Bracket KDL-52S4100...

  • Page 15: Ac Inlet, Structural Frames And Brackets Removal

    KDL-52S4100 1-5. AC INLET, STRUCTURAL FRAMES AND BRACKETS REMOVAL Remove 2 screws from Top Vesa Bracket Top Vesa Bracket Remove 2 screws from G Support 2 Remove 2 screws from G Board frame Remove 2 screws from Center Frame Remove 10 screws from Spine Frames...

  • Page 16: Lcd Panel Removal

    KDL-52S4100 1-7. LCD PANEL REMOVAL Disconnect LVDS connector Disconnect 2 Inverter (Balancer Board) connector assemblies (See Detaching the Inverter Connector Assembly) Disconnect 1 connector Remove 3 screws LCD Panel Bezel 1-7-1. DETACHING THE INVERTER CONNECTOR ASSEMBLY CAUTION: Follow the instructions provided to remove the Inverter Connector Assembly...

  • Page 17: Attaching The Inverter Connector Assembly

    KDL-52S4100 1-7-2. ATTACHING THE INVERTER CONNECTOR ASSEMBLY CAUTION: Follow the instructions provided to reconnect the Inverter Connector Assembly. (1) Hold the center (2) Press the center of (3) Slide the of the connector the connector to slider to lock insert it...

  • Page 18: Bottom Cover, H2 Board, H3 Board, Led Lens And Ir Lens Removal

    KDL-52S4100 1-8. BOTTOM COVER, H2 BOARD, H3 BOARD, LED LENS AND IR LENS REMOVAL Remove 2 screws Disconnect 1 connector and slide out H3 (LED) Board Disconnect 1 connector and remove 1 screw from H2 (IR) Board Remove 1 screw from IR Lens...

  • Page 19: Wire Dressing

    KDL-52S4100 WIRE DRESSING OVERALL VIEW T-CON KDL-52S4100...

  • Page 20: Section 2: Service Adjustments

    KDL-52S4100 SECTION 2: SERVICE ADJUSTMENTS 2-1. RESETTING TO FACTORY DEFAULTS AFTER BOARD REPLACEMENT Traditional Service Mode is not available in this chassis. The only option for service technicians is to reset all of the settings to the Factory Default from the Self Diagnostic screen.

  • Page 21: Section 3: Diagrams

    KDL-52S4100 SECTION 3: DIAGRAMS 3-1. CIRCUIT BOARDS LOCATION H3 (LED) 3-2. PRINTED WIRING BOARDS AND All voltages are in V. SCHEMATIC DIAGRAMS INFORMATION S : Measurement impossibility. : B+line. All capacitors are in μF unless otherwise noted. pF : μμF 50WV or : B-line.
  • Page 22 KDL-52S4100 REFERENCE INFORMATION Terminal name of semiconductors in silk screen printed circuit ( RESISTOR CAPACITOR : RN METAL FILM : TA TANTALUM Circuit Device Printed symbol Terminal name : RC SOLID : PS STYROL Collector Transistor : FPRD NONFLAMMABLE CARBON...

  • Page 23: Block Diagram

    KDL-52S4100 3-3. BLOCK DIAGRAM 52" Panel 52" 52" KDL-52S4100...

  • Page 24: Schematics And Supporting Information

    KDL-52S4100 3-4. SCHEMATICS AND SUPPORTING INFORMATION A BOARD SCHEMATIC DIAGRAM (1 OF 19) — D1101 D1101 NC(1N4148) NC(1N4148) POWER CONNECTOR VOT_SHORT_DET_N 6,7,13,19,21 +15V L1101 L1101 MHC2012S121UB-GP MHC2012S121UB-GP CN1101 CN1101 L1107 L1107 MHC2012S121UB-GP MHC2012S121UB-GP L1120 L1120 MHC2012S121UB-GP MHC2012S121UB-GP +11.3V_U1102 +12V —...

  • Page 25: A Board Schematic Diagram (2 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (2 OF 19) — COMPONENT 1 I/P COMPONENT 2 I/P — CN1202 CN1202 CN1201 CN1201 R1226 R1226 0R5J-6-GP 0R5J-6-GP C1212 C1212 SCD1U25V3KX-GP SCD1U25V3KX-GP Y2_1 COMP_Y2 R1225 R1225 0R5J-6-GP 0R5J-6-GP Y1_1 C1209 C1209 SCD1U25V3KX-GP SCD1U25V3KX-GP COMP_Y1...

  • Page 26: A Board Schematic Diagram (3 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (3 OF 19) — — +5V_ESD +5V_ESD D1305 D1305 D1308 D1308 ISP_D +5V_ESD C1308 C1308 BAV99-7-F-GP BAV99-7-F-GP BAV99-7-F-GP BAV99-7-F-GP SCD1U25V3KX-GP SCD1U25V3KX-GP L1302 L1302 MLB-160808-26-GP MLB-160808-26-GP +5V_ESD +5V_ESD +5V_VGA D1304 D1304 D1302 D1302 — CN1301 CN1301...

  • Page 27: A Board Schematic Diagram (4 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (4 OF 19) — D1804 D1804 1N4148W-7-F-GP 1N4148W-7-F-GP VOT_SHORT_DET_N — U1802 U1802 +5V_TUNER L1410 L1410 MHC2012S121UB-GP MHC2012S121UB-GP +6.5V ADJ/GND C1825 C1825 C1826 C1826 C1823 C1823 C1824 C1824 TM1401 TM1401 APL1117-50VC-TRL-GP APL1117-50VC-TRL-GP TUNER-27P-GP-U TUNER-27P-GP-U E100U16VM-25-GP E100U16VM-25-GP...

  • Page 28: A Board Schematic Diagram (5 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (5 OF 19) — — L1505 L1505 MLB-160808-26-GP MLB-160808-26-GP C1534 C1534 SC1KP50V2KX-1GP SC1KP50V2KX-1GP +3.3V_DEMO L1504 L1504 MLB-160808-26-GP MLB-160808-26-GP +5V_DEMO1 +5V_DEMO1 R1522 R1522 2KR3F-L-GP 2KR3F-L-GP +1.65V R1510 R1510 1KR3F-GP 1KR3F-GP L1506 L1506 MLB-160808-26-GP MLB-160808-26-GP C1536 C1536...

  • Page 29: A Board Schematic Diagram (6 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (6 OF 19) — D1611 D1611 Q1602 Q1602 Q1605 Q1605 HDMI1 HDMI3 — R1612 R1612 1KR3J-L1-GP 1KR3J-L1-GP HDMI_ACLK- HDMI_ACLK- R1620 R1620 1KR3J-L1-GP 1KR3J-L1-GP D1615 D1615 HDMI_AHPD HDMI_CHPD MMBT3904-7-F-GP MMBT3904-7-F-GP HDMI_ACLK+ HDMI_ACLK+ MMBT3904-7-F-GP MMBT3904-7-F-GP HDMI_CCLK- HDMI_CCLK-...

  • Page 30: A Board Schematic Diagram (7 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (7 OF 19) — +3.3V_HDMI — R1702 R1702 R1701 R1701 R1703 R1703 HDMI_SWOUT_RXC- HDMI_SWOUT_RXC+ HDMI_SWOUT_RX0- 4K7R3J-2-GP 4K7R3J-2-GP 3K3R3J-L-GP 3K3R3J-L-GP 3K3R3J-L-GP 3K3R3J-L-GP HDMI_SWOUT_RX0+ HDMISK_SCL_3V HDMI_SWOUT_RX1- D1701 D1701 MBR0520LT1G-GP MBR0520LT1G-GP +5V_H1 F1701 F1701 FUSE-D75A32V-GP FUSE-D75A32V-GP +5V_HA HDMIA_+5V...

  • Page 31: A Board Schematic Diagram (8 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (8 OF 19) — USB UPDATE/DEBUG PORT CN1801 CN1801 SW1801 SW1801 OG-321610G-GP OG-321610G-GP +5V_USB 5,11 RXD_H D1802 D1802 12,21 MCU_RXD — 5,11 TXD_H L1805 L1805 BLM18PG181SN-3GP BLM18PG181SN-3GP SW1802 SW1802 OG-321610G-GP OG-321610G-GP +5V2_ALPSB1 +5V_USB 12,21 MCU_TXD...

  • Page 32: A Board Schematic Diagram (9 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (9 OF 19) — — R1939 R1939 10KR3J-L1-GP 10KR3J-L1-GP PWR5V HDMI_SWOUT_5VIN R1940 R1940 — 10KR3J-L1-GP 10KR3J-L1-GP U1901A U1901A HIDTV-PRO-FX69-GP HIDTV-PRO-FX69-GP AC26 TS0_IN_D0 CPL_TXA0- TS1_D0 TA1M AC25 TS0_IN_D1 CPL_TXA0+ TS1_D1 TA1P AD26 TS0_IN_D2 TB1M CPL_TXA1- TS1_D2 AD25 —...

  • Page 33: A Board Schematic Diagram (10 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (10 OF 19) — — U1901B U1901B HIDTV-PRO-FX69-GP HIDTV-PRO-FX69-GP HP_MD[0..31] HP_MD0 — AA23 FRD_0 FRD0/POD_D0 HP_MD1 AA24 FRD_1 FRD1/POD_D1 HP_MD2 FRD_2 FRD2/POD_D2 HP_MD3 JTAG FRD_3 FRD3/POD_D3 HP_MD4 FRD_4 FRD4/POD_D4 HP_MD5 FRD_5 FRD5/POD_D5 HP_MD6 CN2001 CN2001...

  • Page 34: A Board Schematic Diagram (11 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (11 OF 19) — D2103 D2103 1N4148W-7-F-GP 1N4148W-7-F-GP VOT_SHORT_DET_N 3,6,7,19,21 L2129 L2129 MHC2012S121UB-GP MHC2012S121UB-GP +5V_U2102 D2102 D2102 1N4148W-7-F-GP 1N4148W-7-F-GP U2103 U2103 — VOT_SHORT_DET_N 3,6,7,19,21 VCCH_12 U2102 U2102 +1.2V_ADC L2101 L2101 MLB-160808-26-GP MLB-160808-26-GP C2172 C2172 C2174...

  • Page 35: A Board Schematic Diagram (12 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (12 OF 19) — — HIDTV_PRO POWER HP_VDDM — HP_VCC_12 U1901D U1901D HIDTV-PRO-FX69-GP HIDTV-PRO-FX69-GP — VDDF VDDM +3.3V_VDDF VDDF VDDM VDDC: 1.2V, core power VDDC: 1.2V, core power VDDF VDDM VDDM: 1.8V/2.5V, memory I/O power VDDM: 1.8V/2.5V, memory I/O power...

  • Page 36: A Board Schematic Diagram (13 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (13 OF 19) — HP_MCLK0 HP_MCLK0 HP_VDDM R2302 R2302 R2301 R2301 — C2303 C2303 DDR MEMORY 75R3F-GP 75R3F-GP SCD1U10V2KX-5GP SCD1U10V2KX-5GP HP_CK0_TRM DDR_MVREF 1KR3F-GP 1KR3F-GP C2304 C2304 R2303 R2303 R2304 R2304 C2305 C2305 SCD01U50V2KX-1GP SCD01U50V2KX-1GP SCD1U10V2KX-5GP SCD1U10V2KX-5GP —...

  • Page 37: A Board Schematic Diagram (14 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (14 OF 19) — — — BOOT ROM & FLASH RN2403 RN2403 SRN0J-5-GP SRN0J-5-GP FRD15 FRD_15 FRD1 — FRD_1 FRD2 FRD_2 FRA20 FRA_20 RN2404 RN2404 SRN0J-5-GP SRN0J-5-GP FRD7 FRD_7 FRD0 FRD_0 FRD4 FRD_4 FRD14 FRD_14...

  • Page 38: A Board Schematic Diagram (15 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (15 OF 19) — — L2501 L2501 L2505 L2505 TXA0+ TXB0- CPL_TXA0+ CPL_TXB0- TXA0- TXB0+ CPL_TXA0- CPL_TXB0+ LVDS INTERFACE TCM1210-301-2P-T000-GP TCM1210-301-2P-T000-GP TCM1210-301-2P-T000-GP TCM1210-301-2P-T000-GP L2502 L2502 L2506 L2506 — CN2501 CN2501 TXA1- TXB1- CPL_TXA1- CPL_TXB1- TXA1+...

  • Page 39: A Board Schematic Diagram (16 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (16 OF 19) — AUDIO PROCESSOR — C2602 C2602 SC10U6D3V6KX-4GP SC10U6D3V6KX-4GP C2603 C2603 SCD1U16V3KX-3GP SCD1U16V3KX-3GP C2601 C2601 SC10U6D3V6KX-4GP SC10U6D3V6KX-4GP SIF_P C2630 C2630 SCD022U50V3KX-GP SCD022U50V3KX-GP SIFP C2631 C2631 SC180P50V2JN-1GP SC180P50V2JN-1GP L2602 L2602 BLM18HE152SN1D-GP BLM18HE152SN1D-GP SIF_OUT R2639...

  • Page 40: A Board Schematic Diagram (17 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (17 OF 19) A BOARD SCHEMATIC DIAGRAM (17 OF 19) — L2704 L2704 MHC2012S121UB-GP MHC2012S121UB-GP +15V_AMP — L2703 L2703 MHC2012S121UB-GP MHC2012S121UB-GP +15V C2720 C2720 C2703 C2703 C2704 C2704 C2705 C2705 C2706 C2706 C2707 C2707 C2719...

  • Page 41: A Board Schematic Diagram (18 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (18 OF 19) — — AUDIO OUTPUT STAGE & MUTE CONTROL +15V R2804 R2804 R2802 R2802 +5V_ESD Q2805 Q2805 D2802 D2802 CN2801 CN2801 — R2807 R2807 2K7R3J-1-GP 2K7R3J-1-GP 4K7R3J-2-GP 4K7R3J-2-GP LOUT 13V_SW 0R3-0-U-GP 0R3-0-U-GP MMBT3904-7-F-GP...

  • Page 42: A Board Schematic Diagram (19 Of 19)

    KDL-52S4100 A BOARD SCHEMATIC DIAGRAM (19 OF 19) — — KEYPAD CN2902 CN2902 L2903 L2903 MHC2012S121UB-GP MHC2012S121UB-GP +3.3V_MCU +3.3V_SB — C2903 C2903 C2923 C2923 +3.3V_SB_KEY L2902 L2902 MLB-160808-26-GP MLB-160808-26-GP +3.3V_SB R2924 R2924 100R3J-4-GP 100R3J-4-GP POWER_Key SCD1U25V3KX-GP SCD1U25V3KX-GP R2926 R2926 100R3J-4-GP...
  • Page 43 KDL-52S4100 [POWER, ANALOG INPUT, D-SUB INPUT, TUNER_S, DEMODULATOR, HDMI, HDMI SWITCH, TUNER ALPS & USB, HIDTV PRO, DDR, BOOT ROM & FLASH, LVDS INTERFACE, AUDIO PROCESSOR, AUDIO AMP, AUDIO OUT & MUTE, MCU] [POWER, ANALOG INPUT, D-SUB INPUT, TUNER_S, DEMODULATOR, HDMI, HDMI SWITCH, TUNER ALPS & USB, HIDTV PRO, DDR, BOOT ROM & FLASH, LVDS INTERFACE, AUDIO PROCESSOR, AUDIO AMP, AUDIO OUT & MUTE, MCU]...

  • Page 44: G Board Schematic Diagram (1 Of 3)

    KDL-52S4100 G BOARD SCHEMATIC DIAGRAM (1 OF 3) — 1/4W 301Kohm 1N5407-47L 1/8W 6.19Kohm R379 SCK13084LSY751 D801 C 5A OTC28A24 OTC28A14 CN1:1 NTC1 FL1:1 FL2:1 250VAC 470pF 1/4W 1Mohm D15XB60-7000 CRV-DP7722 QP-33A28 — STTH8R06FP L800:1 D800 FB802 FB801 0.6*12.5*4 250VAC 100pF 50V 0.01uF...

  • Page 45: G Board Schematic Diagram (2 Of 3)

    KDL-52S4100 G BOARD SCHEMATIC DIAGRAM (2 OF 3) — 1W 100mohm T301:3 R317 D304 1N4148TA — 16V 2.2uF 1/8W 51ohm 1SS355 TE-17 1/4W 4.7ohm C703 R313 D302 R315 T302:3 R320 — 1/4W 470ohm Q308 PMMT591A,215 STTH8R06FP FB301 D309 1/10W 68.1Kohm...

  • Page 46: G Board Schematic Diagram (3 Of 3)

    KDL-52S4100 G BOARD SCHEMATIC DIAGRAM (3 OF 3) — L900 T901:1 1SS355 TE-17 D906 CD-6.0-NB03 D900 1/4W 10Kohm STPS10L60CFP R912 — 1N4007-47L BAS316 D904 D909 EGP10DAMP D907 R917 1/4W 4.7ohm — FB901 R910 1/10W 2Mohm 1/8W 22ohm R923 — 1/10W 39.2Kohm...
  • Page 47 KDL-52S4100 [POWER] [POWER] COMPONENT SIDE CONDUCTOR SIDE BOTTOM SIDE SIDE 2950206109 DESIGN IN TAIWAN MAIN_OVP MADE IN CHINA DCWP IC304 — — DPS-245BP ZD370 >P LP< DPS-275MP T301 R130E R620 C336 PRIMARY SECONDARY SECONDARY C328 C132 L130 D130 D603 PRIMARY...

  • Page 48: H1 Board Schematic Diagram

    KDL-52S4100 H1 BOARD SCHEMATIC DIAGRAM — 3V3_KEYPAD R9109 R9109 R9110 R9110 R9111 R9111 R9113 R9113 4K7R3J-2-GP 4K7R3J-2-GP 113R3F-GP 113R3F-GP 68D1R5F-GP 68D1R5F-GP 787R3F-GP 787R3F-GP C9113 C9113 R9112 R9112 R9114 R9114 R9115 R9115 0R3-0-U-GP 0R3-0-U-GP 37D4R5F-GP 37D4R5F-GP 0R3-0-U-GP 0R3-0-U-GP POWER SOURCE MENU —...
  • Page 49 KDL-52S4100 [KEYBOARD] COMPONENT SIDE SW9103 SW9101 SW9107 SW9106 SW9104 SW9105 SW9102 — 07496-2 48.71H02.021 KEYPAD BOARD MADE IN TAIWAN [KEYBOARD] CONDUCTOR SIDE R9112 R9113 CN9103 R9114 R9111 R9109 R9110 R9115 R9116 R9119 L9102 — D9109 C9118 CN9104 D9111 D9110 R9117...

  • Page 50: H2 Board Schematic Diagram

    KDL-52S4100 H2 BOARD SCHEMATIC DIAGRAM — — IRM-40KHZ-GP IRM-40KHZ-GP IRM9101 IRM9101 — CN9101 CN9101 R9102 R9102 R9104 R9104 L9101 L9101 3V3_IR 3V3_IR_1 3V3_IR_2 3V3_IR_3 MHC2012S121UB-GP MHC2012S121UB-GP 22R6J-GP 22R6J-GP 22R6J-GP 22R6J-GP — R9103 R9103 10KR3F-L-GP 10KR3F-L-GP IR_DET R9101 R9101 IR_DET_1 JWT-CON3-6-GP...
  • Page 51 KDL-52S4100 [IR BOARD] COMPONENT SIDE 07497-2 C9101 48.71H03.021 C9102 IR CONTROL BD D9101 MADE IN TAIWAN — L9101 R9103 C9105 IRM9101 R9101 C9103 C9104 [IR BOARD] CONDUCTOR SIDE C9107 — C9108 R9104 R9102 C9106 — KDL-52S4100...

  • Page 52: H3 Board Schematic Diagram

    KDL-52S4100 H3 BOARD SCHEMATIC DIAGRAM — 1N4148W-7-F-GP 1N4148W-7-F-GP D9112 D9112 LED_GREEN(POWER)_1 1N4148W-7-F-GP 1N4148W-7-F-GP D9113 D9113 LED_RED(STANDBY)_1 LED_AMBER(TIMER)_1 1N4148W-7-F-GP 1N4148W-7-F-GP D9114 D9114 — 1N4148W-7-F-GP 1N4148W-7-F-GP D9115 D9115 LED_GREEN(PIC_OFF)_1 Dual color Green D9102 D9102 D9103 D9103 D9104 D9104 LED-R-55-GP LED-R-55-GP LED-G-156-GP LED-G-156-GP —...
  • Page 53 KDL-52S4100 [LED] COMPONENT SIDE D9105 C9110 07498-2 C9109 D9114 D9112 D9106 48.71H04.021 LED BOARD D9113 D9108 — D9103 D9104 MADE IN TAIWAN D9107 D9102 C9112 C9111 D9115 [LED] CONDUCTOR SIDE — CN9102 KDL-52S4100...

  • Page 54: Section 4: Exploded Views

    SCREW, +PSW M5X16 (SCREWS TO ATTACH TABLE-TOP STAND TO LCD TV) For product protection and safety reasons, Sony strongly recommends that you use the screws provided with the TV CAUTION: These screws cannot be used to secure the TV to the Wall Mount Brackets.

  • Page 55: Chassis

    See Appendix A: Encryption Key Components in the back of this manual. 4-2. CHASSIS (Check the Sony Electronics Service Information website for any additional service related issues for this model.) 7-682-973-09 SCREW, +PSW M5X8 4-382-854-01...

  • Page 56: Bezel Assembly And Lcd Panel

    See Appendix A: Encryption Key Components in the back of this manual. 4-3. BEZEL ASSEMBLY AND LCD PANEL (Check the Sony Electronics Service Information website for any additional service related issues for this model.) 7-685-662-29 SCREW, +BVTP2 4X14 TYPE2 SLIT...

  • Page 57: Screw Legend

    KDL-52S4100 4-4. SCREW LEGEND (Check the Sony Electronics Service Information website for any additional service related issues for this model.) 7-685-662-29 SCREW, +BVTP2 4X14 TYPE2 SLIT REAR COVER-20 SPEAKER-8 BOTTOM FRAME-4 BOTOM COVER-2 LCD-3 LED-4 7-682-973-49 SCREW, +PSW M5X16 REAR COVER-5 TABLE-TOP STAND-4...
  • Page 58 SCREW, +PSW M5X16 (SCREWS TO ATTACH TABLE-TOP STAND TO LCD TV) For product protection and safety reasons, Sony strongly recommends that you use the screws provided with the TV. CAUTION: These screws cannot be used to secure the TV to the Wall Mount Brackets.

  • Page 59: Appendix A: Encryption Key Components

    MUST BE RETURNED to Sony. b) and if the core charge is NOT covered under the product warranty, the defective un-repaired or modifi...
