IRT Eurocard Types
DVA-3009
Dual 270 Mb/s ASI/SDI 3 O/P
Distribution Amplifier
Designed and manufactured in Australia
IRT can be found on the Internet at:
http://www.irtelectronics.com
3009-dva.ib.doc
Page 1 of 8
06.05.2003
Advertisement
Table of Contents
Related Manuals for IRT DVA-3009
Summary of Contents for IRT DVA-3009
- Page 1 +61 2 9439 7439 Email: sales@irtelectronics.com Web: www.irtelectronics.com IRT Eurocard Types DVA-3009 Dual 270 Mb/s ASI/SDI 3 O/P Distribution Amplifier Designed and manufactured in Australia IRT can be found on the Internet at: http://www.irtelectronics.com 3009-dva.ib.doc Page 1 of 8 06.05.2003...
-
Page 2: Table Of Contents
DVA-3009 Dual 270 Mb/s ASI/SDI 3 O/P Distribution Amplifier Instruction Manual Table of Contents Section Page Operational Safety General Description Specifications Technical description Installation Front and rear layouts Maintenance & Storage Warranty and service Equipment return Drawing list index This instruction manual applies to units later than S/N 0301001... -
Page 3: General Description
For applications requiring reclocking the DVA-3007 should be used. To provide for the polarity sensitive nature of ASI signals, all outputs of the DVA-3009 are in phase with the input. The DVA-3009 may be mounted in IRT’s 1 RU or 3 RU frames with other analogue or digital modules. -
Page 4: Specifications
General: Temperature range 0 - 50° C ambient Mechanical Suitable for mounting in IRT 19" rack chassis with input, output and power connections on the rear panel. Dimensions 6 HP x 3U Extended Eurocard (220 mm x 100 mm). Weight With rear assembly 365g. -
Page 5: Technical Description
Power: Ensure that the voltage selection of the IRT mounting frame used to house the DVA-3009 and the local AC mains supply voltage match and that the correct rating fuse is installed in the mounting frame power supply. -
Page 6: Front And Rear Layouts
Front & rear panel connector diagrams The following front panel and rear assembly drawings are not to scale and are intended to show connection order and approximate layout only. DV A-3 0 0 9 DUAL ASI/SDI DA INPUT A 3 = ALARM A 2 = ALARM B 1 = GND A OUTPUTS... -
Page 7: Maintenance & Storage
Before arranging service ensure that the fault is in the unit to be serviced and not in associated equipment. If possible, confirm this by substitution. Before returning equipment contact should be made with IRT or your local agent to determine whether the equipment can be serviced in the field or should be returned for repair. -
Page 8: Drawing List Index
Drawing List Index Drawing # Sheet # Description 804653 Dual ASI/SDI Distribution Amplifier. 3009-dva.ib.doc Page 8 of 8 06.05.2003... - Page 9 1 13-06-02 2 27-03-03 ECR1399...
