IRT Eurocard
Type HDA-4510
1.485 Gb
s HD 6 O/P
/
Reclocking Distribution Amplifier
Designed and manufactured in Australia
IRT can be found on the Internet at:
http://www.irtelectronics.com
4510-HDA.ib.Rev0.doc
Page 1 of 12
19/07/2006
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IRT HDA-4510
Summary of Contents for IRT HDA-4510
- Page 1 +61 2 9439 7439 Email: sales@irtelectronics.com Web: www.irtelectronics.com IRT Eurocard Type HDA-4510 1.485 Gb s HD 6 O/P Reclocking Distribution Amplifier Designed and manufactured in Australia IRT can be found on the Internet at: http://www.irtelectronics.com 4510-HDA.ib.Rev0.doc Page 1 of 12 19/07/2006...
-
Page 2: Table Of Contents
Technical Specifications Configuration Link Settings Location of links & user settings Installation SMU-4000 Installation Figure 1: SMU-4000 module HDA-4510 SNMP Functions Front and rear layouts SNMP – What Is It? Maintenance & Storage Warranty & Service Equipment return Drawing List Index This instruction book applies to units later than S/N 0506001. -
Page 3: General Description
IRT’s 4000 series frame fitted with SNMP capability. The HDA-4510 is designed to fit IRT’s 4000 series frame for use with IRT’s SNMP system as well as being suitable with IRT’s Standard 1000 and 3000 series Eurocard frames and may be used alongside any other of IRT’s analogue or digital Eurocards. -
Page 4: Technical Specifications
General: Temperature range 0 - 50° C ambient Mechanical Suitable for mounting in IRT 19" rack chassis with input, output and power connections on the rear panel. Dimensions 6 HP x 3U Extended Eurocard (220 mm x 100 mm). Weight With rear assembly 385g. -
Page 5: Configuration
Configuration Link Settings: LK2 IN Reclocker set for HD or SD operation (Default position IN). Reclocker automatically bypassed on lock loss. LK3 IN Selects Manual PLL rate. Selects Auto PLL rate (Default position OUT, LK3 not installed). LK4, LK5, LK6 Set manual PLL rate. Must be left open when Auto PLL selection (LK3 OUT) used. -
Page 6: Installation
Installation Pre-installation: Handling: This equipment may contain or be connected to static sensitive devices and proper static free handling precautions should be observed. Where individual circuit cards are stored, they should be placed in antistatic bags. Proper antistatic procedures should be followed when inserting or removing cards from these bags. Power: AC mains supply: Ensure that operating voltage of unit and local supply voltage match and that correct rating fuse... -
Page 7: Smu-4000 Installation
Note also that an SMU-4000 will only be functionally operational when the main module that it is plugged into is fitted into an IRT 4000 series frame fitted with a CDM-4000 SNMP agent and being interrogated by a suitable Network Management System. -
Page 8: Front And Rear Layouts
Front & rear panel connector diagrams The following front panel and rear assembly drawings are not to scale and are intended to show connection order and approximate layout only. H DA -4 5 1 0 6 O/P HD/SD D.A. OUTPUTS OUTPUTS INPUT SK10... -
Page 9: Snmp - What Is It
(SNMPv3). It is not the intention here to discuss the differences between various versions, only to bring attention to the fact that IRT Electronics modules, fitted with SNMP capability, use SNMPv1. An SNMP managed network consists of three key components: Network Management Systems (NMS), agents, and managed devices. - Page 10 SNMP with IRT Products: IRT Electronics currently employs SNMPv1 with its 4000 series frame. The frame acts as an agent when fitted with a CDM-4000 module. This module has its own designated slot next to the power supply so as to not affect the number of modules that the frame will take.
-
Page 11: Maintenance & Storage
For situations when “No Fault Found” for repairs, a minimum charge of 1 hour’s labour, at IRT’s current labour charge rate, will apply, whether the equipment is within the warranty period or not. -
Page 12: Drawing List Index
Drawing List Index Drawing # Sheet # Description 804999 HDA-4510 HD/SD Distribution Amplifier Schematic Diagram 4510-HDA.ib.Rev0.doc Page 12 of 12 19/07/2006... - Page 13 1 11-10-2004 2 08-06-2005 ECR1794 3 18-10-2005 ECR1823...
