Installation Instructions

1. Install the Filters and Membrane Cartridge
• Wearing sterile gloves, remove the two filters and membrane from the
sterile packaging and place them in the appropriate housings.
WHITE
CAP
POST-FILTER
CARBON BLOCK
REVERSE OSMOSIS
MEMBRANE
• Secure filter housings by hand tightening Counter Clockwise (looking
from the top) to Ultrefiner II bracket(see figure 5).
BLACK
CAP
PRE-FILTER
CARBON BLOCK
HAND TIGHTEN
FILTER HOUSING
ONTO THE BRACKET
PLUG FILTERS INTO THE
BRACKET ASSEMBLY
INSURE FILTER HOUSING
HAS O-RING IN PLACE
ENSURE O-RING IS SEATED
IN FILTER HOUSING
CORRECTLY
Helpful Tip: Be careful not to contaminate the
filters and membrane by touching non-sterile
objects.
Figure 4
Figure 5
INSERT FILTER
7
