MAINTENANCE AND CLEANING

W AR N IN G ! If the user of this appliance fails to m aintain it in the condition
in w hich it w as shipped from the factory or if the appliance is not used
solely for its intended purpose or if appliance is not m ainta in ed in
acco rdance w ith the instructions in this m anu al, then the risk o f a fire
and/or the production of carbon m onoxide exists w hich can cause
personal injury, property dam age or loss of life.
C AU TIO N : Label all w ires before disconnecting for servicing. Proper polarity
m ust be observed so the furnace m otor w ill run w ith the proper direction of
rotation to insure correct air delivery. (S ee w iring diagram ).
C AU TIO N : Label all w ires prio r to disconnection w hen servicing controls.
W iring error can cause im proper and dangerous furnace operation.
Alw ays verify proper operation of furnace after servicing.
Yo ur furnace should be insp ected by a qualified service agency yearly before
turning the furnace on. Particular attention should be given to the follow ing
item s.
1. Inspect furnace installation and vent term ination to be sure furnace is properly
secured in place (S ee Installation Instructions), that vent term ina tes to the
atm osphere, and that vent tubes overlap properly (S ee Installing V ent Assem bly).
2. Inspect cham ber and venting to assure that these com ponents are physically
s o und, without holes or excessive corrosion and that the installation and/o r
reinstallation is in accordance w ith Suburban's Installation Instructions. (R eference
installation m anual supplied with furnace.)
W AR N IN G ! It is im perative that the products of com bustion be properly
vented to atm osphere and that all com bustio n a ir supplied to burner be
draw n from outside atm osphere.
3. C heck the base on which furnace is m ounted. Be sure it is physically sound,
void of any sagging, deterioration, etc.
4. Inspect furnace, the venting and the gas piping to furnace for obvious signs of
deterioration. C orrect any defects at once.
5. Inspect com bustion cham ber for restrictions in e xh a u st or intak e. It is
im perative that the flow of intake com bustion air and the flow of exhaust gases
being expelled to the outside atm osphere not be obstructed. A n y s o o t or loose
debris should be blown out using com pressed air.
6. Inspect all gaskets. If any gaskets show signs of leakage or deterioration,
replace them . Safe operation of the furnace depends on all gaskets being tight.
7. Inspect return a ir in le t openings to the furnace. R em ove any restrictions to
assure a de quate a ir flo w.
You, as the o w ner/user, should inspect the furnace m onthly during the
heating season for pre se n ce of soot on vent. O perating the furnace under this
condition could lead to serious property dam age, personal injury or loss of life. If
soot is observed on the vent, im m ediately shut the furnace down and c o n ta c t a
qualified service agency.
Listed below are several safety related item s that you should follow during the
heating season to assure continued safe operation of the furnace.
1. Inspect furnace venting. V enting m ust be free of obstructions, void of soot and
properly term inated to the atm osphere.
W AR N IN G ! D o not install screens over the vent for any reason. Screens
w ill becom e restricted and cause unsafe furnace operation. Accessories
are being m ark eted for R V products w hich w e do not recom m end. For
your safety, only factory authorized parts are to be used on your furnace.
Figure 1
2. P eriodically observe the m ain burner flam e to assure it is burning with a hard
blue flam e with well defined burner ports (S ee Figure 2). If flam e appears yellow
or burner has a lazy flam e, shut furnace down. It is possible that burner needs
cleaning or replaced. T o inspect the m ain burner, rem ove the four (4) screws (A ,
B , C and D) securing the burner access door to the com bustion cham ber (S ee
Figure 1). If excessive rust and corrosion are present on burner surface, the
burner m ust be thoroughly cleaned or replaced. The burner m ay be cleaned using
a steel wire brush and blown clean using high com pression air. C ontact a qualified
service person for assistance.
N O T E : To observe flam e, cabinet front m ust be rem oved. O peration of burner can
then be observed through the viewing window on front of cham ber. (S ee Figure
1.)
3. P eriodically in s p e c t the vent for obstructions or presence of soot. S oot is
form ed whenever com bustion is incom plete. This is your visual warning that the
furnace is operating in an unsafe m anner. If soot is present, im m ed iately shut
furnace down and contact your dealer or a qualified service person.
4. K eep furnace clean. More frequen t cleaning m ay be required due to excessive
lint from carpeting, bedding m aterial, etc. It is im perative that control
com partm ents, burners and circulating air passageways of the appliance be kept
clean.
5. T he m otor is perm anently lubricated and requires no oiling.
6. K eep the furnace area clear of any com bu stible m aterials, gasoline or other
flam m able vapor and liquids.
7. B efore operating furnace, check the location of the furnace vent to m ak e sure
it will not be blocked by the opening of any door on the trailer. If it can be blocked,
do not operate the furnace with the door open.
8. D o not restrict the flow of com bustion air or the warm air circulation to the
furnace. To do so could cause personal injury and/or death.
9. N ever operate the furnace if you sm ell gas. D o not assum e that the sm ell of
g a s in your R V is norm al. A ny tim e you detect the odor of gas, it is to be
considered life threatening and corrected im m ediately. E xtinguish any open flam es
including cigarettes and evacuate all persons from the vehicle. S hut off gas supply
at LP gas bottle. (S ee safety notice on front cover of this m anual.)
10. Im m ediately shut furnace down and call a service agency if furnace cycles
erratically or delays on ignition.
W AR N IN G ! S hould overheating occur, or the gas supply fail to shut off,
shut off the m anual gas valve to the appliance before shutting off the
electrical supply.
11. N ever attem pt to repair dam aged parts. A lways have them re p la ced by a
qualified service agency.
12. N ever attem pt to repair the furnace yourself. Seek the h elp of a qualified
service person.
13. C lothing or other flam m able m aterial should no t b e placed on or near the
appliance.
14. Always follow the O perating Instructions. D o not deviate from the step-by-step
procedures.
15. In any installation in which the vent of this appliance can be covered due to the
construction of the R V or som e special feature of the R V such as slide out, pop-up
etc. always insure that the appliance cannot be operated by setting the therm ostat
to the positive "O FF" position and shutting off all electrical and gas supply to the
appliance. N ever operate furnace with vent covered.
16. W hen considering add-on room s, porch or patio, atte ntion m ust be given to
the venting of your furnace. For your safety, do not term inate furnace vent inside
add-on room s, s creen p orch or onto patios. D oing so will result in products of
com bustion being vented into the room or occupied areas.
1
Figure 2
