Suburban NT-24SP User's Information Manual

uburban
Manufacturing Company
] I s
C E R T I F I E D
USER'S INFORMATION MANUAL
For Models
NT-24SP NT-30SP NT-34SP
NT-12s NT-16s NT-20s
This book contains instructions covering the operation a n d
maintenance of your furnace. K e e p with unit a t all times.
Should you require further information, contact y o u r dealer or nearest
Suburban Service Center.
- - - -
WARNING! Installation of this appliance
must be made in accordance with the
written instructions provided in this
manual. No agent, representative or
employee of Suburban or other person
has the authority to change, modify or
waive any provision of the instructions
contained in this manual.
WARNING! I m p r o p e r i n s t a l l a t i o n ,
adjustment, alteration, service or
maintenance can cause property damage,
personal injury or loss of life. Refer to the
installation instructions andlor owners
manual provided with this appliance.
MAINTENANCE AND CLEANING
in which i t was shipped from the factory or i f the appliance is not used
solely for its intended purpose or i f appliance i s not maintained i n
accordance with the instructions i n this manual, then the risk of a fire
andlor the production of carbon monoxide exists which can cause
CAUTION: Label all wires before disconnecting for servicing. Proper polarity
must be observed so the furnace motor will run with the proper direction of
rotation to insure correct air delivery (See Wiring Diagram.)
CAUTION: Label all wires prior to disconnection when servicing controls.
Wiring errors can cause improper and dangerous furnace operation.
Always verify proper operation of furnace after servicing.
You, as the ownerluser, should inspect the furnace monthly during the
heating season for presence of soot on vent. Operat~ng the furnace under this
condition could lead to serious propew damage, personal injury or loss of life. If
soot is observed on the vent, immediately shut furnace down and contact a
qualified service agency.
Listed below are several safety related items that you should follow during the
heating season to assure continued safe operation of the furnace.
1.
lnspect furnace venting. Venting must be free of obstructions, void of soot and
properly terminated to the atmosphere. (Refer to installation manual.)
S U B U R B A N M A N U F A C T U R I N G COMPANY
P o s t O f f i c e B o x 3 9 9
D a y t o n , T e n n e s s e e 37321
ignition systems are "OFF" during any
type of refueling and while vehicle is in
motion or beina towed.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Extinguish any open flame.
Evacuate all persons from the vehicle.
Shut off the gas supply at the gas
container or source.
Do not touch any electrical switch, or
use any phone or radio in the vehicle.
Do not start the vehicle's engine or
electric generator.
Contact the nearest gas supplier or
qualified service technician for repairs.
If you cannot reach a gas supplier or
qualified service technician, contact the
nearest fire department.
Do not turn on the gas supply until the
gas leak(s) has been repaired.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
WARNING! Do not install screens over the vent for any reason. Screens
will become restricted and cause unsafe furnace operation. Accessories
are being marketed for RV products which we do not recommend. For
your safety, only factory authorized parts are to be used on your furnace.
2. Periodically inspect the vent for obstructions or presence of soot. Soot is
formed whenever combustion is incomplete. This is your visual warning that the
furnace is operating in an unsafe manner. If soot is present, immediately shut
furnace down and contact your dealer or a qualified service person.
3.
Periodically observe the main burner flame to assure it is burning with a hard
blue flame with well defined burner ports (See Figure 2). If flame appears yellow
or burner has a lazy flame, shut furnace down. It is possible that burner needs
cleaning or replaced. To Inspect the main burner, remove the four (4) screws (A.
8. C and D) securing the burner access door to the combustion chamber (See
Figure 1) If excessive rust and corrosion are present on burner surface, the
burner must be thoroughly cleaned or replaced. The burner may be cleaned using
a steel wire brush and blown clean using high compression air. Contact a qualified
service person for assistance.
NOTE: To observe flame, cabinet front must be removed. Operation of burner can
then be observed through the viewing window on front of chamber (See Figure 1).
4. Keep furnace clean. More frequent cleaning may be required due to excessive
lint from carpeting, bedding material, etc. It is imperative that control
compartments, burners and circulating air passageways of the appl~ance be kepi
clean.
Form No. 2497-C
