FILE NO. SVM-12070

SERVICE MANUAL

SPLIT TYPE
Indoor Unit
Outdoor Unit
RAS-18N3KVR-E
RAS-18N3AV-E
RAS-22N3KVR-E
RAS-22N3AV-E
R410A
December, 2012
