Roland PC-600 Quick Referenc Manual

If the PC-600 Stops and LEDs Flash
Check the LED display.
The POWER LED and SETUP LED are flashing
The unit is installed in a location outside the operating-temperature range.
>> Install in location where the operating temperature is appropriate.
See "3-9 Specifications Operating Temperature".
The SETUP LED is flashing
The pinch roller is above the grit roller.
The loaded material is displaced from the sensor.
>>Loading the material correctly.
See "2-3 Loading the Material".
One of the CARTRIDGE HOLDER LEDs is flashing.
The cartridge set the corresponding location is installed incorrectly.
>>Install the ink-ribbon cartridge correctly.
See "2-5 Installing a Ribbon Cartridge".
The ink ribbon at the corresponding location has been used up.
>>Install a new ribbon cartridge of the same color.
See "2-5 Installing a Ribbon Cartridge Replacing an Ink Cartridge".
The SETUP LED and CARTRIDGE HOLDER LEDs 1 through 6 are all flashing.
Ink-ribbon cartridges have been installed at the six cartridge holder locations, and at the printing carriage.
During printing, the carriage could not retrieve an ink-ribbon cartridge, or could not return a cartridge to the
cartridge holder.
>>Install the ink-ribbon cartridge correctly.
See "2-5 Installing a Ribbon Cartridge".
The CARTRIDGE HOLDER LEDs 1 through 6 are all flashing.
A ribbon cartridge need for printing is absent.
>>Install the ribbon cartridge that is needed for printing.
See "2-5 Installing a Ribbon Cartridge".
The SETUP LED and one of the CARTRIDGE HOLDER LEDs from 1 trough 6 are
flashing.
A fatal error occurs.
>> Switch off the main power, then switch it on again.
See "3-8 What to Do If...".
4
PC-600 Quick Reference Guide
Keep this document close at hand, so that you can get to it immediately if there is a problem.For detailed information about using the
panel and other basic procedures and features, see the User's Manual.
Table of Contents
To Stop Printing or Cutting .................... 1
If Printing Is Grimy ................................. 1
To Change the Origin Point for Printing or Cutting .... 2
If the Material Cannot Be Cut Properly ......... 2
Copyright © 2000 ROLAND DG CORPORATION
To Stop Printing or Cutting
1
Open the front cover.
--> Operation pauses.
3
Hold down the [CLEAR] key until the CLEAR
LED starts to flash.
>> The DATA CLEAR LED flashes.
>> When all commands sent from the computer to
the PC-600 are deleted, the DATA CLEAR LED
goes out.
See "2-8 Pausing and Stopping Operation".
If Printing Is Grimy
The PC-600 automatically performs cleaning of the printing head. You can also perform forced cleaning by pressing the [HEAD
CLEANING] key, but normally automatic cleaning is sufficient. If printing is especially grimy, press the [HEAD CLEANING] key to
perform cleaning. To start cleaning, hold down the key until a beep is heard.
See "3-7 Care and Maintenance".
R2-000608
To Cut a Piece of Material Off the Roll .......... 3
When Not in Use ................................... 3
Storing Material ..................................... 3
If the PC-600 Stops and LEDs Flash .... 4
2
Halt transmission of printing or cutting instruc-
tions from the computer.
1
