JBL SOURCE Service Manual page 20

Ò
Dolby Pro-Logic Surround Processor/CD Player/Tuner
Ref. # Part Number
C808, 838, 840, PRE3951-101
859, 864, 865
C809, 812 PRM3737-222 COND MYLAR 0.0022 uF 100V 5%
C810, 861, 862 PRM3737-102 COND MYLAR 0.001 uF 100V 5%
C811, 832 PRM3737-473 COND MYLAR 0.047 uF 100V 5%
C815 PRD3545-102
C816, 853, 874, PRA3951-101
C876
C819, 821, 826 PRM3737-333 COND MYLAR 0.033 uF 100V 5%
C825 PRE3955-479
C828 PRE3955-108
C829, 851, 852 PRA3952-100
C833 PRD3545-221
C834, 854 PRE3955-478
C836, 837 PRD1335-300
C841, 842 PRD1335-820
C843, 844, 845, PRD1335-390
846
C847, 848 PRD3545-331
C849, 850 PRD3545-152
C857 PRD3545-201
C863, 875 PRM3737-104 COND MYLAR 0.1 uF 100V 5%
C873 PRD4965-203
C890 PRM3737-152 COND MYLAR 0.0015 uF 100V 5%
C891, 892, 894, PRE3952-221
895
C893 PRN1052-470
Resistors
R801, 837, 859, QAF0650-102
860, 894, 895
R802, 803, 826, QAF0650-333
868, 884, 885
R804 QAF0650-105
R805 QAF0650-153
R806, 822, 870, QAF0650-473
873, 874, 877,
879, 880
R810, 811, 824, QAF0650-104
834, 835, 871,
875, 876
R812, 838 QAF0650-222
R813 QAF0650-334
R814 QAF0650-474
R815, 878, 893 QAF0650-472
J811, R816, 833, QAF0650-103
R836, 840, 841,
R842, 843, 844,
R853, 854, 855,
R856, 857, 858,
R861, 862, 892
Description
COND ELECT 100 uF 10V 20%
COND DISC 1000 pF 50V 10% Y5P 1
COND ELECT 100 uF 10V 20%
MINI SIZE
COND ELECT 4.7 uF 50V 20%
COND ELECT 0.1 uF 50V 20%
COND ELECT 10 uF 16V 20%
MINI SIZE
COND DISC 220 pF 50V 10%
11 Y5P D=5
COND ELECT 0.47 uF 50V 20%
COND DISC 30 pF 50V 5% NP0 T.C. 2
COND DISC 82 pF 50V 5% NP0
COND DISC 39 pF 50V 5% NP0
COND DISC 330 PF 50V 10% Y5P
COND DISC 1500 pF 50V 10%
11 Y5P D=6
COND DISC 200 pF 50V 10% Y5P
DISC .02 uF 50V +80-20%
11 Z5V D=7
COND ELECT 220 uF 16V 20%
COND ELECT 47 uF 16V 20% N.P. 1
RESISTOR 1K OHM 1/6W 5% CF
RESISTOR 33K OHM 1/6W 5% CF
RESISTOR 1.0M OHM 1/6W 5% CF 1
RESISTOR 15K OHM 1/6W 5% CF
RESISTOR 47K OHM 1/6W 5% CF
RESISTOR 100K OHM 1/6W 5% CF 8
RESISTOR 2.2K OHM 1/6W 5% CF 2
RESISTOR 330K OHM 1/6W 5% CF 1
RESISTOR 470K OHM 1/6W 5% CF 1
RESISTOR 4.7K OHM 1/6W 5% CF 3
RESISTOR 10K OHM 1/6W 5% CF
Qty Ref. # Part Number
6 R817 QAF0650-100
R818 QAF0650-273
2
R820 QAF0650-203
3
R821 QAF0650-824
2
R823 QAF0650-514
R825 QAF0650-753
4
R827, 864, 865 QAF0650-822
R828, 830, 849, QAF0650-223
3
850, 851, 852,
1 889
1 R829 QAF0650-124
3 R831, 896 QAF0650-562
R832 QAF0650-332
1
R845, 846, 847, QAF0650-363
848
2
R866, 867 QAF0650-224
R872 QAF0650-101
2
R890, 891 QAF0650-683
4
R899 QAF0650-682
2
Diodes
2
D801, 802, 803, RAD4148-001
804, 809
1
ZD801 RAZ0859-068
2
1
Transistors
1
Q801, 802, 803, RAP0952-001
813, 814, 818
4
Q805, 806 RAN2878-001
Q807, 811, 812, RAN0945-001
815, 816, 817
Q808 RAP0733-001
6
Q810 RHP0772-001
Q819 RAN2001-001
6 Integrated Circuits
IC801 RCI1782-001
1
IC802 RCI2508-001
8
IC803 RCI9258-001
IC805, 806 RHI5218-002
IC809 RHI6218-001
MISCELLANEOUS
CN801 CCN0122-018
CN301, 81, 82, 83 CCN7879-022
18
CN802 CCN7879-036
SOURCE
Description
RESISTOR 10 OHM 1/6W 5% CF
RESISTOR 27K OHM 1/6W 5% CF
RESISTOR 20K OHM 1/6W 5% CF
RESISTOR 820K OHM 1/6W 5% CF 1
RESISTOR 510K OHM 1/6W 5% CF 1
RESISTOR 75K OHM 1/6W 5% CF
RESISTOR 8.2K OHM 1/6W 5% CF 3
RESISTOR 22K OHM 1/6W 5% CF
RESISTOR 120K OHM 1/6W 5% CF 1
RESISTOR 5.6K OHM 1/6W 5% CF 2
RESISTOR 3.3K OHM 1/6W 5% CF 1
RESISTOR 36K OHM 1/6W 5% CF
RESISTOR 220K OHM 1/6W 5% CF 2
RESISTOR 100 OHM 1/6W 5% CF
RESISTOR 68K OHM 1/6W 5% CF
RESISTOR 6.8K OHM 1/6W 5% CF 1
DIODE SW IN4148
DIODE ZENR 5.0-5.2V .5W
HITACHI HZ5C-2
XISTR PNP 2SA952 NEC
XISTR NPN 2SC2878
XISTR NPN 2SC945P NEC
XISTR PNP 2SA733Q,P NEC
XISTR PNP 2SB772P/Q NEC
XISTR NPN 2SC2001L NEC
IC 48 PIN CXA1782BQ SONY
RF AMP + S.S.P
IC 80 PIN CXD2508AQ SONY
D.S.P + D.A.C
IC 28 PIN KA9258D SAMSUNG
POWER DRIVE IC
IC 8 PIN M5218AL MITSUBISHI
OP AMP or 4558L OP-AMP
IC 9 PIN BA6218 MOTOR DRIVER IC1
CONNECTOR 18 PIN
PD18-1810D P=1.0 mm
CONNECTOR J.S.T. 2.0mm PH
B2B-PH-K TOP SIZE
CONN 90DEG 2 PIN PITCH=2.0mm 1
SIDE ENTRY TYPE
Qty
1
1
1
1
7
4
1
2
5
1
6
2
6
1
1
1
1
1
1
2
1
4
1 7
