Electrical Parts List - Pioneer DEH-3300R-2 Service Manual

ELECTRICAL PARTS LIST(Page 34)
Tuner Amp Unit
Circuit Symbol and No.
IC601
R514,R515
R516
R518
R519
R520
R521
R522,R524,R534,R535
R523
R525,R526,R527
R529
R530
R536
R537
Part No.
DEH-3300R/X1N/EW DEH-3300R-2/X1N/EW,X1M/EW
DEH-3330R/X1N/EW DEH-3330R-2/X1N/EW,X1M/EW
PE5202A
RS1/16S473J
RS1/16S473J
RS1/16S222J
RS1/16S222J
RS1/16S681J
RS1/16S102J
RS1/16S0R0J
RS1/16S102J
Not used
Not used
Not used
RS1/16S0R0J
Not used
104
(1/4W)
104
DEH-3300R-2,3330R-2
PE5245A
Not used
RS1/16S104J
Not used
RS1/16S102J
RS1/16S0R0J
RS1/16S222J
Not used
RS1/16S0R0J
RS1/16S222J
RS1/4PU0R0J
RS1/16S0R0J
RS1/16S102J
RS1/16S104J
5
