Summary of Contents for Dynascan DB-93M

  • Page 1 Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com...

  • Page 2: Table Of Contents

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com INDEX 1 of 2 Page no. INTRODUCTION MAINTENANCE AND SAFETY CAUTIONS SUPPLIED ARTICLES AND OPTIONAL ACCESSORIES 3.1.- SUPPLIED ARTICLES 3.2.- OPTIONAL ACCESSORIES CHARACTERISTICS TECHNICAL SPECIFICATIONS 5.1.- GENERAL 5.2.- TRANSMITTER 5.3.- RECEIVER...
  • Page 3 Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com INDEX 2 of 2 Page no. 11.5.- SETTING SQUELCH 11.6.- “SCRAMBLER” FUNCTION 11.7.- BACKLIGHT COLOR SELECTION 11.8- “BEEP” ON/OFF 11.9.- VOICE PROMPT 11.10- “ANI” FUNCTION 11.11.- KEYPAD LOCK 11.12.- TIME OUT TIMER “TOT”...

  • Page 4: Introduction

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 1.- INTRODUCTION: • Our Company he thanks him for the trust deposited in this product, we are convinced that it will be highly pleased with the quality and operation functions of this equipment.

  • Page 5: Maintenance And Safety Cautions

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com WARNING! - The transceiver operation can be prohibited in certain places or enclosures, follow the use restrictions. - Before using this transceiver, obtain the necessary authorization administrative or license. - Follow the requirements of your country in the use of Radioamateur transceiver.

  • Page 6: Supplied Articles And Optional Accessories

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com WARNING! - The user is the responsible one of providing the enough protection during a thunderstorm uses the transceiver with an external antenna in a vehicle, or it uses it in a housing like a fixed station and it installs the antenna outdoors in a high location.

  • Page 7: Technical Specifications

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com - “Duplex” function. - Self-setting “CTCSS/DCS”. - FM RADIO receiving. - Independent “A” band and “B” band operation setting. 5.- TECHNICAL SPECIFICATIONS: 5.1.- GENERAL: Frequency range: 76 MHz –...

  • Page 8: Transceiver Description

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 6.- TRANSCEIVER DESCRIPTION: 6.1.- CONTROLS, KEYS AND CONNECTORS: Selector knob Antenna [ON/OFF/Volumen] control Status led indicator Speaker Microphone LCD display [Menu] key [A/B] key [Enter] key [VFO/MR] key Alphanumeric keypad [Reverse frequency] key...

  • Page 9: Lcd Display

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 6.2.- LCD DISPLAY: Icon Description Battery level indicator. Shows the TX offset direction in relation to the Rx frequency. Power level indicator, “HI” = High power / “LO” = Low power. HI/LO Keypad lock.

  • Page 10: Install And Remove The Belt Clip

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 7.4.- INSTALL AND REMOVE THE BELT CLIP: Place the belt clip for slipping it for the grooves of the battery rear side until the end. To remove the belt clip, liberate the retention lash of the belt clip and slip it until he separates to the battery.

  • Page 11: Alarm Function

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 8.4.- ALARM FUNCTION: Hold down the programmed side key with this function, the transceiver will sound alarm tone and send “ANI” identification code to others transceiver of their group. 8.5.- EMERGENCY CHANNEL: Press the [#T-R] key, in any case the transceiver can call up the emergency call channel, and the display shows “CAL”.

  • Page 12: Operation Mode Selection

    - SE: The transceiver stops on a busy channel or frequency and exits the scan mode. 8.9.- OPERATION MODE SELECTION: This transceiver has three modes to choose from: Double-standby, channel mode and frequency mode. 1.- Double-standby mode: Long press the [A/B] key to enter or exit the double-standby mode. In double-standby mode, there will be two channel A or B instructions.

  • Page 13: Side Keys

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 8.13- SIDE KEYS: PTT: Press to transmit, release to receive. Side key programmed as follow: 1) Optional signaling call. 2) Alarm function. 3) 1750 MHz signaling tone. 4) Squelch.

  • Page 14: Store

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com [0ANI] key to turned on or off the “ANI” function. 8.16.- STORE: To store a frquency and its settings (CTCSS, DCS, SHIFT REPEATERS, etc.) follow the procedure below: 1.- At first, choose all the settings to store.

  • Page 15: Menu Operation

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com [MENU] + [9VOICE] + [ENTER]: Voice annunciation on/off. [MENU] + [#T-R] + [ENTER]: Transmitting/receiving “CTCSS/DCS” setting. [MENU] + [*LOCK] + [ENTER]: Repeater shift setting. 10.- MENU OPERATION: To operate with all the settings of the menu, you have to follow these general steps: 1.- Press the [MENU] key.

  • Page 16: Advanced Operations

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 11.- ADVANCED OPERATIONS: 11.1.- SCANNING: Press the [MENU] key. Turn the selector knob until the display shows “SCAN” (menu 001). Press the [ENTER] key. Press the [VFO/MR] to stop scanning and exit. 11.2.- PRIORITY CHANNEL SCAN: In channel mode, press the [MENU] key.

  • Page 17: Scrambler" Function

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 6.- Press the [VFO/MR] key to exit. To activate and select rapidly the squelch level, you can also use the fast menu. Press the [MENU] key, then press the [5SQL] key and follow the procedure above described.

  • Page 18: Ani" Function

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 5.- Press the [ENTER] key again. 6.- Press the [VFO/MR] key to exit. To select rapidly this function, you can also use the fast menu. Press the [MENU] key, then press the [9VOICE] and follow the procedure above described.

  • Page 19: Wide And Narrow Band Selection

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 11.14.- WIDE AND NARROW BAND SELECTION: 1.- Press the [MENU] key. 2.- Turn the selector knob until “N/W” (menu 014) is displayed. 3.- Press the [ENTER] key. 4.- Turn the selector knob to select from “NARROW or WIDE”.

  • Page 20: Select "Ctcss" And "Dcs" On Transmitting

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 5.- Press the [ENTER] to confirm. You can use keypad or software to input or program a non-standard “CTCSS/DCS”. 11.19.- SELECT “CTCSS” AND “DCS” ON TRANSMITTING: 1.- Press the [MENU] key.

  • Page 21: Fm Radio And Monitor Two Way Radio Signal

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 3.- Press the [ENTER] key. 4.- Turn the selector knob and select “OFF” or 10 different tones. 5.- Press the [ENTER] key. 6.- Press the [VFO/MR] key to exit. 11.25.- FM RADIO AND MONITOR TWO WAY RADIO SIGNAL: 1.- Press the [MENU] key.

  • Page 22: Cross-Band Repeater Mode

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 3.- Press the [ENTER] key. 4.- Turn the selector knob to select “FIXED” or “CALLIN”. 5.- Press the [ENTER] key. 6.- Press the [VFO/MR] key to exit. “FIXED”: The transceiver always transmit in current channel.

  • Page 23: Channel Name Edit

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 11.33.- CHANNEL NAME EDIT: 1.- Press the [MENU] key. 2.- Turn the selector knob until “NAME” (menu 033) is displayed. 3.- Press the [ENTER] key. 4.- Turn the selector knob to select the wanted character.

  • Page 24: Troubleshooting

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 14.- TROUBLESHOOTING: If your transceiver has problems, by following this table. Problem Cause/solution Cannont power on the The battery pack has been exhausted, please change for a loaded battery transceiver.

  • Page 25: Declaration Of Conformity

    Παύλος Μεϊµάρης Ελπίδος 34 (ΒΑΟ) Συκιές, Θεσσαλονίκη τηλ 2310.634.513, 6977.38.38.73 URL: http://www.meimaris.com - Εmail: info@meimaris.com 16.- GUARANTEE: WARRANTY CERTIFICATE Brand name: Model: Serial no.: Acquirer name: Address: Stamp and name of the establishment sales: Country: Postal code: Telephone no.: Date of purchase of the equipment: WARNING: The warranty is valid provided it is total and properly executed in a readable and clear way,...
