Will Burt AntennaMast AM2 Operator's Manual

Manual deploy & deploy w/mast tube lift winch
Hide thumbs Also See for AntennaMast AM2:

Advertisement

Quick Links

Download this manual
Model AM2
Manual Deploy
& Deploy w/Mast
Tube Lift Winch
Operator's Manual
www.willburt.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the AntennaMast AM2 and is the answer not in the manual?

Questions and answers

Related Manuals for Will Burt AntennaMast AM2

Summary of Contents for Will Burt AntennaMast AM2

  • Page 1 Model AM2 Manual Deploy & Deploy w/Mast Tube Lift Winch Operator’s Manual www.willburt.com...

  • Page 2: Document History

    *Page 6 explains the installation of the mast and accessories. **Page 7 lists the mast contents. Document History Version Date Remarks TP-5000801-00 12/15/13 Original Release Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 3 Disassembling the Mast ..........33 Maintaining the Mast ............33 Customer Support Warranty Information ............34 Model # _____________ Serial # _____________ Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 4 Helmets or hard hats, eye protection, gloves, and safety shoes or combat boots must be worn while working in the mast deployment area. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 5 Always dis- connect power before performing service, repair or test operations. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 6 • Install Base Tube • Stake the Base Plate • Stake the Guy Lines • Tighten the Guy Lines Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 7 (supplied in place of Mast Tube Lift Winch) Mast Tube Lift Winch Kit Orange Lift Plate (Some models) Orange Winch w/Key Payload Accessory Kit As ordered Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 8 Manual Deployment...
  • Page 9 Remove the tripod. Remove the top tube and base tube making sure to keep separate from mast tubes. BOTTOM Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 10 Lift the tripod and pull the spring loaded pin outwards. This unlocks the tripod. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 11 *Be careful of buried cables and utilities when staking the mast. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 12 Tighten the top and bottom clamps. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 13 4-way guy collar at 90 angles. ° Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 14 If you are raising the mast during windy conditions, the mast will need to be guyed as you raise the mast. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 15 The lift puck can also be used to push up the tubes. Repeat this step until all tubes are loaded. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 16 Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 17 Clip the carabineer of each of the tensioners to the ring of the guy stake. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 18 *Check to make sure the center mast tube remains straight and perpendicular. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 19 Deployment with Mast TubeLift Winch...
  • Page 20 Remove the tripod. Remove the top tube and base tube making sure to keep separate from mast tubes. BOTTOM Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 21 Lift the tripod and pull the spring loaded pin outwards. This unlocks the tripod. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 22 *Be careful of buried cables and utilities when staking the mast. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 23 Tighten the top and bottom clamps. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 24 4-way guy collar at 90 angles. ° Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 25 If you are raising the mast during windy conditions, the mast will need to be guyed as you raise the mast. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 26 Feed the cable through the rollers of the orange base plate. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 27 Place the key between the leg braces opposite of the orange winch so the legs of the key are resting on the top of the leg braces. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 28 Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 29 *For masts taller than 12m / 40 ft., two stakes are required, depending on the soil type. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 30 Clip the carabineer of each of the tensioners to the ring of the guy stake. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
  • Page 31 *Check to make sure the center mast tube remains straight and perpendicular. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...

  • Page 32: Grounding Instructions

    Make certain that all of the cables are held firmly to the ground in order to increase grounding effect. Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...

  • Page 33: Maintenance

    Inspect all guy lines for frayed or cut lines. Inspect guy handles for cracks or tears. Wipe down all parts with a cloth Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...

  • Page 34: Warranty

    169 S. Main Street Orrville, OH 44667 USA Corporate Telepone: +1-330-682-7015 Customer Service: +1-330-684-4000 Service & Parts: +1-330-684-5244 Fax: +1-330-684-1190 E-Mail: contact_us@willburt.com Do not duplicate, alter, or copy without the written consent of The Will-Burt Company. © Copyright 2013 The Will-Burt Company www.willburt.com...
