Firefighter's Telephone
ECC-FFT
Instruction Manual
B
Document LS10031-000FL-E
9/4/2013
Rev:
P/N LS10031-000FL-E:B
ECN 13-707

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECC-FFT and is the answer not in the manual?

Questions and answers

Summary of Contents for Fire-Lite ECC-FFT

  • Page 1 Firefighter’s Telephone ECC-FFT Instruction Manual Document LS10031-000FL-E 9/4/2013 Rev: P/N LS10031-000FL-E:B ECN 13-707...
  • Page 2 Adequate written records of all inspections should be kept. (especially in bedrooms), smoking in bed, and violent explosions Limit-D-1-2013 ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 3: Installation Precautions

    LiteSpeed™ is a trademark; and FireLite® Alarms is a registered trademark of Honeywell International Inc. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation. ©2013 by Honeywell International Inc. All rights reserved. Unauthorized use of this document is strictly prohibited. ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...
  • Page 4 •Brief description of content you think should be improved or corrected •Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 5: Table Of Contents

    2.1: Mounting Options ............................11 2.2: Backbox Installation ............................11 2.3: Installing the ECC-FFT ..........................13 2.3.1: Operating Power ..........................13 2.3.2: DIP switch settings on ECC-FFT ......................13 DIP Switch............................13 2.4: UL Power-limited Wiring Requirements.....................14 2.5: ECC-FFT Fire Fighter Telephone Module Connection................15 2.6: FPJ-F Installation............................16 2.7: SLC Device Installation..........................17...
  • Page 6 Alarm Systems, UL 864, 9th Edition. Operation of this product with products not tested for UL 864, 9th Edition has not been evaluated. Such operation requires the approval of the local Authority Having Jurisdiction (AHJ). ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 7: Section 1: Product Description

    • One Form-C system trouble relay - TB6 • ECC-FFT Fire Fighter Telephone module for control and annunciation of up to 24 remote telephone jacks • A maximum of ten (10) Fire Fighter Remote Handsets (FHS-F) can be used at one time to communicate over the telephone circuit connected to the ECC-FFT •...

  • Page 8: Ecc-Fft Board Layout

    Figure 1.1 above shows the circuit board that attaches to the cabinet. If you should need to remove the board assembly for repair, remove the seven mounting nuts which hold the assembly in the cab- inet. Then lift the control board out of the cabinet. ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 9: Electrical Specifications

    Zone 24 Figure 1.2 ECC-FFT Keypad 1.5 Electrical Specifications 1.5.1 Power Requirements Voltage for the ECC-FFT must be a UL-listed, power-limited, filtered, non-resettable nominal 24 VDC source. The voltage source must be within the range of 17-29 VDC. Circuits Voltage...

  • Page 10: 3: Wiring Specifications

    High frequency noise, such as that produced by the inductive reactance of a speaker or bell, can also be reduced by running the wire through ferrite shield beads or by wrapping it around a ferrite toroid. ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 11: Section 2: Installation

    Mark and predrill hole in the wall for the center top keyhole mounting bolt using the dimensions illustrated in Figure 2.2 on page 12. Install center top fastener in the wall with the screw head protruding. ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...
  • Page 12 3.875” into wall to Dress Panel avoid covering venting holes on top of box. Mounting slots for optional Trim Ring Semi-flush mounting hole Hinge Slot for Dress Panel Figure 2.2 Cabinet Dimensions & Knockout Locations ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 13: Installing The Ecc-Fft

    Refer to Figure 2.3 for location of the DIP switches on the ECC-FFT board. Configure the ECC-FFT using the dip switch settings in Table 2.1. Add SLC modules to the system through Autoprogram feature. See Section 3.3 for Autoprogram Operation.

  • Page 14: Ul Power-Limited Wiring Requirements

    0.25” (6.35 mm) away from any nonpower-lim- ited circuit wiring and nonpower-limited circuit wiring must enter and exit the cabinet through dif- ferent knockouts and/or conduits. A typical wiring diagram for the ECC-FFT is shown below. Note: The dress panel is shown swung open for illustration purposes only.

  • Page 15: Ecc-Fft Fire Fighter Telephone Module Connection

    Installation 2.5 ECC-FFT Fire Fighter Telephone Module Connection The ECC-FFT provides connection for a single Class B or Class A telephone audio circuit. See page 21 through page 26 for examples of audio zone configurations. An MMF-301 monitor module can be used to monitor the connection of the Fire Fighter Telephone remote handset (FHS-F) into the FPJ-F, which is then displayed on the ECC-FFT active zone LED during the Autoprogram fea- ture.

  • Page 16: Fpj-F Installation

    To FFT-SLC terminal TB4 connectors or other MMF-301s Audio Audio 4.7K, ½ watt ELR (install on last device for Style Y [Class B] telephone circuit only) FPJ-F Figure 2.7 FFT to FPJ-F Connection ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 17: Slc Device Installation

    Wiring SLC in Style 4 (Class B) Configuration No special wire is required for the ECC-FFT SLC loop. The wire can be untwisted, unshielded, solid or stranded as long as it meets the National Electric Code 760-51 requirements for power lim- ited fire protective signaling cables.
  • Page 18 The device located farthest from the SLC must be less than the maximum distance per wire gauge. SLC device max loop resistance = 40 ohms SLC device Figure 2.9 Calculating Wire Run Length for a T-tap ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 19: Wiring Slc Devices In Style 6 & 7 (Class A) Configuration

    ONES rotary dial to set the ones place in a one or two digit number, and use the TENS rotary dial to set the tens place in a two digit number. MMF-301 modules can be assigned any unique address from 1 to 24. ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 20: Audio Phone Circuit Installation

    2.8 Audio Phone Circuit Installation 2.8.1 Maximum Number of Devices The ECC-FFT supports up to 24 zones. Each zone consists of one addressable monitor module (MMF-301) and a minimum of one Fire Fighter Telephone Jack (FPJ-F). 2.8.2 Wiring Requirements for the Audio Telephone Circuit No special wire is required for the Audio Telephone Circuit.

  • Page 21: Single Phone Jack Audio Circuit In Class B Configuration

    4.7K, 1/2 watt ELR (install on last device for Style Y [Class B] telephone circuit only) ADDRESS 14 15 FPJ-F LOOP TENS ONES Figure 2.11 Single Phone Jack Audio Circuit in Class B ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 22: Single Phone Jack Audio Circuit In Class A Configuration

    Break wire run to ONES provide supervision of connections. FPJ-F ADDRESS 14 15 LOOP TENS ONES ADDRESS 14 15 FPJ-F LOOP TENS ONES Figure 2.12 Single Phone Jack Audio Circuit in Class A ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 23: Multi-Phone Jack Audio Circuit In Class B Configuration

    FPJ-F FPJ-F 4.7K, 1/2 watt ELR ADDRESS 14 15 (install on last device for Style Y [Class B] LOOP telephone circuit only) TENS ONES Figure 2.13 Multi-Phone Jack Audio Circuit in Class B ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 24: Multi-Phone Jack Audio Circuit In Class A Configuration

    FPJ-F FPJ-F FPJ-F Contact EOL Contact EOL Connected Disconnected ADDRESS 14 15 LOOP TENS ONES FPJ-F FPJ-F FPJ-F 14 15 ADDRESS LOOP TENS ONES Figure 2.14 Multi-Phone Jack Audio Circuit in Class A ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 25: Telephone Jack Only Audio Circuit

    Break wire run to provide supervision of connections. FPJ-F 4.7K, 1/2 watt ELR (install on last device for Style Y [Class B] telephone circuit only) FPJ-F Figure 2.15 Telephone Jack Only Audio Circuit in Class B ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...
  • Page 26 For system supervision- For terminals 2 and 3, do not use looped wire under terminals. Break wire run to provide supervision of connections. FPJ-F FPJ-F Figure 2.16 Telephone Jack Only Audio Circuit in Class A ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...

  • Page 27: Section 3: System Operation

    Section 3: System Operation The operation of the ECC-FFT Fire Fighter Telephone system allows audio communication from 24 remote connections through remote handsets to a single local handset. Up to 10 remote handsets can be connected and communicating at one time.

  • Page 28: Autoprogram Operation

    The user presses the Autoprogram key again to repeat the SLC search process. If the user does not press the Accept key within one minute after the Autoprogram is complete, its configuration will be discarded and the FFT will be restarted. ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...
  • Page 29 Carefully cut along the outside of each label. Identify the keypad buttons as desired and slide the labels in. The labels slide upwards through the slits in the bottom of the keypad, covering the white spaces. ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...
  • Page 30 Slide-in Labels Autoprogram Operation ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...
  • Page 31 Manufacturer's Return Material Authorization form. The replacement part shall come from Manufacturer's stock and may be new or refurbished. THE FOREGOING IS DISTRIBUTOR'S SOLE AND EXCLUSIVE REMEDY IN THE EVENT OF A WARRANTY CLAIM. Warn-HL-08-2009.fm ECC-FFT Instruction Manual — P/N LS10031-000FL-E:B 9/4/2013...
  • Page 32 World Headquarters 1 Firelite Place Northford, CT 06472-1653 USA 203-484-7161 fax 203-484-7118 www.firelite.com...
