2. Technical Specification
• Extremely small, fast and powerful LED Moving Beam,
• DMX Channels: 9/12/16CH
• Pan/ Tilt: 650*/ 240* speed adjustable
• Smooth electronic dimming: 0-100%
• Electronic strobe with pulse and random effects
• High efficiency, low power consumption
• Super compact, low weight
Weight: 5,7kg
Voltage: 100V-240V, 50/60Hz
Fuse: T6.3A
Power Consumption: 150W
Light source: 3W LED x36 (R8, G10, B10, W8)
Dimension: 375x322x445mm
3. Display
To show the various menus and the selected functions
LED
DMX
MASTER
SLAVE
SOUND
Button
MENU
DOWN
UP
ENTER
Mains Input
Connect to supply power.
Mains Output
Connect to supply power to the next unit.
DMX Input/ Output
For DMX512 link, use 3/5-pin XLR cable to link the unit together.
4. Main Function
To select any of the given functions, Press the MENU buton up to when the required
one is showing on the display. Select the function by ENTER buton and the display
www.flash-butrym.pl
ON
ON
ON
Flashing
To select the programming functions
To go backwardin the selected functions
To go forward in the selected functions
To confirm the selected functions
DMX Input Present
Master Mode
Slave Mode
Sound Activation
