„M108RGBW" on the display and move all the motors to their „HOME" position and
you may hear some noises for about 20 seconds. After that the unit will be ready to
receive DMX signal or run the built in programs.
7. Master/ Slave Built In preprogrammed Function
By lining the units in master/ slave connection, the first unit will controll the other units
to give an automatic, sound activated, synchronized light show. This function is good
when you want an instant show. You have to set the first unit in master mode Show
Mode and select Show 1 or Show 2 or Show 3 ors Show 4 mode. Its DMX input jack
will have nothing plugged into it, and its master LED will be constantly on and sound
LED will flash to the music. The other units will have to set in Slave mode and select
Slave 1 (normal) or Slave 2 (2 light show) mode, Their DMX cables plugged into the
DMX input jacks (daisy chain) and the slave led lights will constantly on.
2-light show
In Slave mode, Slave 1 means the unit works normally and Slave 2 means 2-light
show. In order to create a great light show, you can set Slave 2 on the second unit to
get contrast movement to each other, even if you have two units only.

8. DMX Controller

By using a universal DMX Controller to control the units, you will need to set DMX
address from 1 to 512 so that the units can recive DMX signal.
Press the MENU buton up to when the DMX Adress is showing on the display.
Pressing ENTER buton and the display will blink. Use DOWN and UP buton to
change the DMX512 address. Once the address has been selected, press the
ENTER buton to setup, to go back to the functions without any change press the
MENU buton again. Hold and press the MENU buton about one secondo r wait for
one minute to exit the menu mode.
Please refer to the following diagram to address your DMX512 channel for the first 4
units.
Channel Mode Unit 1 Address
9 channels
12 channels
16 channels

9. DMX512 Configuration

9 Channel Mode:
Channel List
CH1
CH2
www.flash-butrym.pl
Unit 2 Address
1 10
1 13
1 17
Value
000-255
000-255
Unit 3 Address Unit 4 Address
19
25
33
Function
Pan (0-630*)
Tilt (0-240*)
28
37
49
