Draytek Vigor2600 Quick Start Manual page 16

Wireless LAN
The Vigor2600W and Vigor2600We are equipped with a wireless LAN interface
Interface
compliant with the 11Mbps IEEE 802.11b protocol. The features of wireless LAN
capability enable high mobility of several simultaneous users accessing all LAN facilities
just like on a wired LAN as well as Internet and WAN access.
The Frequency Domain is set as Europe and the MAC address will show as above. Click
General Settings, you could configure the SSID and wireless channel.
Scheduler: You can set wireless device to work at some time interval only. These are 4
internals you can choose: schedule1, schedule2, schedule3, and schedule4. The default
setting is always working. You can set the schedule under Advanced Setup >> Call
Schedule Setup. (Please refer to detail manual on the attached CD)
16
