Motor Unit Assembly Parts

6
7
(Down)
Contact
Brown
Wire
Drive
Gear
Center Limit
Contact
KEY PART
NO. NO. DESCRIPTION
1 41A4208 Chain spreader assembly.
2 41C4206A Gear and sprocket assembly.
Complete with:
Spring washer
Thrust washer
Retaining ring
Bearing plate
Roll pins (2)
Drive gear and worm gear
Helical gear w/retainer and grease
3 41A2817 Drive/worm gear kit w/grease
Roll pins (2)
4 41B4245 Line cord
5 143D152 End panel w/all labels
6 175B88M Light socket
7 108D34 Lens
8 30B387 Capacitor
9 12A373 Capacitor bracket
10 41A3150 Terminal block w/screws
16
20
19
17
18
16 15
LIMIT SWITCH ASSY.
Grey
Wire
(Up)
Yellow
Contact
Wire
1
2
4
3
10
3
11
13
14
12
KEY PART
NO. NO.
11 41D3058
12 41A3733-1 Cover
13 41A2818
14 41D3452
15 41C4398A RPM sensor assembly
16 41C4246
17 41A2826
18 41A2822A Interrupter cup assy.
19 41A5021-E Receiver logic board assy.
20 41A3673-1 End panel w/all labels
NOT SHOWN
41A2825
34
6
8
9
5
DESCRIPTION
Universal replacement motor &
bracket assembly
Complete with: Motor, worm,
bracket, bearing assembly, RPM
sensor.
Limit switch drive & retainer
Limit switch assembly
Wire harness assembly. w/plug
Shaft bearing kit
Complete with: Logic board,
end panel w/all labels &
light socket
Opener assembly hardware kit
(includes screws not designated by
a number in illustration).
7
