Compatibility
This engine will operate on any traditional
O-31 Gauge track system, including
M.T.H.'s RealTrax
traditional tubular track. It is also compatible
with most standard AC transformers. (See
page 21 for a complete list of compatible
transformers and wiring instructions.)
PLEASE READ BEFORE USE AND SAVE
Premier SD60
MAC Diesel
Engine
OPERATOR'S MANUAL
®
™
or ScaleTrax
or
Advertisement
Table of Contents
Related Manuals for M.T.H. Premier SD60 MAC Diesel Engine
Summary of Contents for M.T.H. Premier SD60 MAC Diesel Engine
- Page 1 Premier SD60 MAC Diesel Engine OPERATOR’S MANUAL Compatibility This engine will operate on any traditional O-31 Gauge track system, including ® ™ M.T.H.’s RealTrax or ScaleTrax traditional tubular track. It is also compatible with most standard AC transformers. (See page 21 for a complete list of compatible transformers and wiring instructions.) PLEASE READ BEFORE USE AND SAVE...
-
Page 2: Table Of Contents
Table of Contents Set Up Checklist....................3 Lubrication.....................3 Priming The Smoke Unit............... 3 Checking The Battery................4 Basic Operation....................5 Activating Features................5 Proto-Sound 2.0 Operating Instructions............7 Activating Proto-Sound 2.0 Conventional Mode Features....7 Freight Yard Sounds (FYS)..............8 Proto-Coupler® Operation..............9 Speed Control.................. -
Page 3: Set Up Checklist
(see Fig. 3). Failure either to add fluid to the unit or to turn it off may damage the smoke unit heating element and/or wicking material. Premier SD60 MAC Diesel Engine... -
Page 4: Checking The Battery
If you notice that the sounds are garbled, test and charge the engine as described in the "Self-Charging Battery Back-Up" on page 15. Premier SD60 MAC Diesel Engine... -
Page 5: Basic Operation
Reverse Forward each press and release of the direction button. The engine is programmed to Neutral restart in neutral each time the track voltage is turned off for 25 seconds or more. Premier SD60 MAC Diesel Engine... - Page 6 To adjust the volume of all sounds made by this engine, turn the master volume control knob located next to the fuel tank clockwise to increase the volume and counter-clockwise to decrease the volume. Proto-Sound 2.0 Volume Adjustment Knob Figure 4: Manual Volume Adjustment Knob Premier SD60 MAC Diesel Engine...
-
Page 7: Proto-Sound 2.0 Operating Instructions
Fire the Front Coupler 1 Bell, 4 Whistles 1 Whistle, 2 Bells (From Neutral Only) Speed Control On/Off Lock into a Direction/Unlock 1 Whistle, 3 Bells Reset to Factory Defaults 1 Whistle, 5 Bells (From Neutral Only) Premier SD60 MAC Diesel Engine... -
Page 8: Freight Yard Sounds (Fys)
Bell and Horn buttons and can ring the bell or blow the horn as usual. Operator Direction Direction Direction Direction Bell Horn Horn Controls When Bell Turns Off Sound System Cued to Play Passenger Sequence Sequence Sequence Sequence Station Announcements (FYS) Premier SD60 MAC Diesel Engine... -
Page 9: Proto-Coupler® Operation
Horn button, allowing approximately ½ second to lapse between each quick button press. The sound of the liftbar and air line depletion will play, and the knuckle will be released. Fire Horn Horn Horn Rear Bell Coupler Premier SD60 MAC Diesel Engine... -
Page 10: Speed Control
Each time you shut down the engine completely, it will automatically turn speed control on. Speed Control Two Horn Blasts Place Bell Bell Horn Engine into (indicates change is made) Neutral Repeat to Return to Normal Condition Premier SD60 MAC Diesel Engine... -
Page 11: Locking Locomotive Into A Direction
Cab Chatter plays at random intervals when the engine idles in neutral. • Engine Start-up and Shut-down sounds play when the engine is initially powered on or is powered off for five seconds or more. Premier SD60 MAC Diesel Engine... -
Page 12: Maintenance
(in the truck block) with grease. 4. Reassemble the truck and motor, being careful not to pinch any wires between the truck block and motor mount. Premier SD60 MAC Diesel Engine... -
Page 13: Cleaning The Wheels, Tires And Track
Thereafter, keep an eye on the track and clean it when it gets dirty to ensure good electrical contact and to lengthen the life of the tires. Premier SD60 MAC Diesel Engine... -
Page 14: Traction Tire Replacement Instructions
One set of replacement tires is packaged with your model. Additional sets are available directly from the M.T.H. Parts Department (order online: www.mth-railking.com, e-mail: parts@mth-railking.com; mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532, FAX: 410-381-6122). Premier SD60 MAC Diesel Engine... -
Page 15: Headlight Replacement Instructions
Test: Put the engine in neutral and leave the track voltage at 10-12 volts (high enough for the lights to shine brightly and the engine to move steadily) for 15 minutes. Premier SD60 MAC Diesel Engine... -
Page 16: Protosmoke® Unit Operation
The smoke unit is essentially a small heating element and wick that soaks up and then heats a mineral oil-based fluid that emits a Figure 10: Adding Smoke Fluid Premier SD60 MAC Diesel Engine... - Page 17 Figure 11 : Smoke Unit Inspection replaced. Replacement parts and wick replacement instructions are available directly from the M.T.H. Parts Department (order online: www.mth-railking.com, e-mail: parts@mth-railking.com; mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532, FAX: 410-381-6122). Premier SD60 MAC Diesel Engine...
-
Page 18: Troubleshooting Proto-Sound® 2.0 Problems
Do NOT use oil. The coupler does not fire or stay The coupler needs to be cleaned. coupled. Wipe with denatured alcohol (not rubbing alcohol) and let dry. Premier SD60 MAC Diesel Engine... - Page 19 Because there are a limited number of sound clips available in each FYS sequence, it is probable that some of these sound clips will be repeated from time to time. Premier SD60 MAC Diesel Engine...
- Page 20 FYS cycle. of FYS after fourth press of the Wait at least 30 seconds in each FYS direction button. sound clip before pressing the direction button. Premier SD60 MAC Diesel Engine...
-
Page 21: Transformer Compatibility And Wiring Chart
Lionel SW Unknown 130-Watt Standard Lionel TW 8-18v 175-Watt Standard Lionel ZW A,B,C or D 8-20v 275-Watt Standard Lionel Post-War A,B,C or D Common 0-20v 135/190 Watt Electronic Celebration Series ZW * Conventional Mode Only Premier SD60 MAC Diesel Engine... -
Page 22: Additional Features Accessible Of Dcs Remote Control System
Direction Control Set Up-User can set initial individual start-up direction (start in forward or reverse) for double-heading operations • Locomotive Consist Set-up-User can determine locomotive values for consist make-ups, allowing multiple locomotives belonging to a consist to operate together Premier SD60 MAC Diesel Engine... -
Page 23: Service & Warranty Information
Authorized M.T.H. Service Centers are independently owned and operated and are not agents or representatives of M.T.H. Electric Trains. M.T.H. assumes no responsibility, financial or otherwise, for material lef t in their possession, or work done, by priv ately owned M.T.H. Authorized Service Centers. - Page 24 GRAMPA'S TRAIN SHOP ROUNDHOUSE SOUTH DAVIS ELECTRONICS RICE LAKE PORT ORANGE MILFORD 715-234-2996 386-304-7002 513-831-6425 MARYLAND RICK'S TOY TRAINS PLAZA HOBBY TOLEDO CUMBERLAND 419-478-0171 301-729-6424 PENNSYLVANIA ENGINE HOUSE HOBBIES BUSSINGER TRAINS GAITHERSBURG AMBLER 301-590-0816 215-628-2366 Premier SD60 MAC Diesel Engine...
- Page 25 SAMUELSON'S TRAIN SHOP DELAWARE VALPARAISO K R R B MODEL TRAINS INC. CALIFORNIA 219-462-2708 NEWARK CENTRAL COAST TRAINS 302-292-2779 ATASCEDERO IOWA 805-466-1391 CABOOSE STOP HOBBIES FLORIDA CEDAR FALLS TRAIN SHACK HOLLYWOOD STATION HOLLYWOOD 800-642-7012 BURBANK 954-921-2700 818-842-3330 Premier SD60 MAC Diesel Engine...
- Page 26 MICHIGAN MODEL TRAIN TRENTON 740-633-6607 CENTER 609-883-8790 PINCKNEY SCHAFFNER'S TRAINS 734-426-1651 COAST TRAINS AND CANTON COLLECTIBLES 330-452-4444 BRASSEUR ELECTRIC TRAINS, WALL INC. 732-556-9005 TRAINS-N- THINGS SAGINAW CANTON 989-793-4753 HOLLY BEACH TRAIN DEPOT 330-499-1666 WILDWOOD 609-522-2379 Premier SD60 MAC Diesel Engine...
- Page 27 YE OLDE TRAIN & CHRISTMAS GREAT TRAINS & HOBBIES SHOPPE LONGVIEW BOYERTOWN 903-757-2720 610-369-0755 VIRGINIA CHARLEROI SWEEPER LOCUST GROVE TRAINS CENTER LOCUST GROVE CHARLEROI 540-854-8955 724-483-3397 TRAINS, ETC. CRANBERRY HOBBY DEPOT LORTON CRANBERRY TWP 703-550-1779 724-776-3640 Premier SD60 MAC Diesel Engine...
