STUDIO DUE CS-2 Operator's Manual

Hide thumbs Also See for CS-2:
Table of Contents

Advertisement

Quick Links

See also: User Manual
User's and operator's manual for art. 0402/C and 0403/C
Manuale d'uso e dell'operatore per art. 0402/C e 0403/C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STUDIO DUE CS-2

Summary of Contents for STUDIO DUE CS-2

  • Page 1 User’s and operator’s manual for art. 0402/C and 0403/C Manuale d'uso e dell'operatore per art. 0402/C e 0403/C...
  • Page 2 This page is intentionally left blank...
  • Page 3 Safety informations Informazioni di sicurezza ........................page 2 Technical features Caratteristiche tecniche ........................page 4 Setup Settaggio ............................page 5 DMX signal connection / DMX terminal line Connessione segnale DMX / Terminale di linea DMX ..............page 6 CS2 DMX listing Lista valori DMX CS2 ........................
  • Page 4 WARNING SAFETY INFORMATION READ ALL CAUTIONS AND WARNINGS PRIOR TO OPERATE THIS EQUIPMENT. INSTRUCTION TO PREVENT INJURY OR DAMAGE DUE TO ELECTRIC SHOCK, FIRE, MECHANICAL HAZARDS AND UV RADIATION HAZARDS. •PROTECTION AGAINTS FIRE 1)This equipment is designed for use with the following lamps only: ACL STI-250W-28V or ACL GE-250W-28V.
  • Page 5 The CS-2 is the unit with 2 PAR-64 lights, using 2 Air Craft 250W 28V lamps: the lamps can be separately dimmered by 2 DMX channels, and also the PAN movement can be individually regulated at 8 or 16 bit by 2 DMX channels, while the TILT movement at 8 or 16 bit is the same for both the PAR-64.
  • Page 6 / tensione nominale: 100V, 120V, 230V, 240V/50-60Hz with internal voltage selector PHOTOMETRIC PARAMETERS rated current / corrente nominale: CS-2: 230V= 2,4A - CS-4: 230V= 4,8A rated power / potenza nominale: CS-2: 230V= 550W - CS-4: 230V= 1100W PARAMETRI FOTOMETRICI •...
  • Page 7 When the fixture is switched on will be present, for few seconds, the writing "STUDIO DUE CS SPOT LINE" (from 3.00 software- version only), than all the motors and the displays start a reset and then position themselves in the deafult settings: now you can start the set-up of the fixture through the electronic panel with 4 keys “MENU-DOWN-UP-ENTER”, then choose the best setting...
  • Page 8 EXAMPLE OF CONNECTION DMX CONTROLLER-SPOT / ESEMPIO DI COLLEGAMENTO CENTRALINA - FARI DMX CONTROLLER CENTRALINA DMX LAST SPOT/ SPOT SPOT SPOT ULTIMO SPOT EXAMPLE 1/ESEMPIO 1 TERMINATION RESISTOR TERMINALE DI LINEA LAST SPOT/ SPOT SPOT SPOT ULTIMO SPOT DMX CONTROLLER CENTRALINA DMX DMX1 output/linea uscita DMX1 EXAMPLE 2/ESEMPIO 2...
  • Page 9 It utilize: 14 DMX channels, 16 bit (mod 3), 11 DMX channels, 8 bit (mod 2) e 9 DMX channels, 8 bit (mod 1). Il CS-2 può funzionare sia a 16 che a 8 bit utilizzando: 14 canali DMX a 16 bit (mod 3), 11 canali DMX a 8 bit (mod 2) e 9 canali DMX a 8 bit (mod 1).
  • Page 10 CS4 DMX SETTING: 20 CHANNELS 16 BIT; 15 CHANNELS 8 BIT; 13 CHANNELS 8 BIT The CS4 can work at 16 or 8 bit. It utilize: 20 DMX channels, 16 bit (mod 3), 15 DMX channels, 8 bit (mod 2), 13 DMX channels, 8 bit (mod 1). Il CS4 può...
  • Page 11 N =NEUTRAL (Blue)(Blu) =EARTH (Green Yellow)(Verde Giallo) =EARTH (Green Yellow)(Verde Giallo) FUSES: FUSE: CS-2 - 230V = 1X T5A 250V CS-4 - 230V = 2X T5A 250V CS-2 - 117V = 1X T8A 250V CS-4 - 117V = 2X T8A 250V WARNING...
  • Page 12 LAMP'S INSTALLATION AND REPLACEMENT / INSTALLAZIONE E SOSTITUZIONE LAMPADA AIRCRAFT STI-250W-28V OR GE-250W-28V LAMP LAMPADA AIRCRAFT STI-250W-28V OPPURE GE-250W-28V COLOR FILTER INSTALLATION / MONTAGGIO GELATINA COLORATA RING FIXING SCREWS VITI ANELLO DI FISSAGGIO COLOUR FILTER FIXING RING ANELLO DI FISSAGGIO GELATINA COLOUR FILTER Ø200mm GELATINA COLORATA Ø200mm...
  • Page 13 MECHANICAL LOCK / BLOCCO MECCANICO IMPORTANT! BEFORE TO MOVE THE LOCK KEY, BE SURE TO HAVE POSITIONED THE FIXTURE IN THE RIGHT WAY, AS SHOWN IN THE DRAWING. IMPORTANTE! POSIZIONARE LE PARTI MOBILI COME DA DISEGNO PRIMA DI INSERIRE IL BLOCCO MECCANICO. THE FIXING BRACKET / STAFFE DI FISSAGGIO FIXING BRACKET STANDARD FIXED WITH BOLTS...
  • Page 16 Cod. CSDIM...
  • Page 17 CS2: SPARE PARTS, TECHNICAL DRAWINGS CS2: PARTI DI RICAMBIO E DISEGNI TECNICI --- CS/2 --- --- CS/2 --- Description Description base structure lamps cable fan grille motors cables voltage transformer head structure fixing plate lateral cover connecting terminal lateral cover (shaped) lateral motor plate motor cover lateral block plate...
  • Page 18 CS2: HEAD...
  • Page 19 CS2: BASE...
  • Page 20 This page is intentionally left blank Questa pagina e stata intenzionalmente lasciata in bianco...
  • Page 21 CS4: SPARE PARTS, TECHNICAL DRAWINGS CS4: PARTI DI RICAMBIO E DISEGNI TECNICI --- CS/4 --- --- CS/4 --- Description Description base structure fixing bracket fan grille fast lock fast lock sliding ring voltage transformer fixing plate lamps cable connecting terminal motors cables lateral motor plate lateral block plate...
  • Page 22 CS4: HEAD...
  • Page 23 CS4: BASE...
  • Page 24 This page is intentionally left blank Questa pagina e stata intenzionalmente lasciata in bianco...
  • Page 25 This page is intentionally left blank Questa pagina e stata intenzionalmente lasciata in bianco...
  • Page 26 NOTE...
  • Page 27 This page is intentionally left blank...
  • Page 28 Head Office: STUDIO DUE s.r.l. (I) Str. Poggino, 100 - 01100 Viterbo (Italy) tel. +39.0761.352520 fax +39.0761.352653 info@studiodue.com STUDIO DUE (UK) 3 Encon Court Owl Close Moulton Park Industrial Estate Northampton England UK - NN3 6 HZ tel. +44.1933.650.820 info@studiodue.co.uk...

This manual is also suitable for:

Cs-4
