JVC TK-C215V4U Instructions Manual

Jvc dome camera instructions
Hide thumbs

Advertisement

DOME CAMERA

TK-C215V4
For Customer Use:
Enter below the Serial No. which is located on the body.
Retain this information for future reference.
Model No.
TK-C215V4
Serial No.
INSTRUCTIONS
LST0420-001A
(A)

Advertisement

Table of Contents
loading

  Also See for JVC TK-C215V4U

  Summary of Contents for JVC TK-C215V4U

  • Page 1: Dome Camera

    DOME CAMERA TK-C215V4 For Customer Use: Enter below the Serial No. which is located on the body. Retain this information for future reference. Model No. TK-C215V4 Serial No. INSTRUCTIONS LST0420-001A...
  • Page 2: Introduction

    European Union. If you wish to dispose of this product, please visit our web page www.jvc-europe.com to obtain information about the take-back of the product. [Other Countries outside the European Union] If you wish to dispose of this product, please do so in accordance with applicable national legislation or other rules in your country for the treatment of old electrical and electronic equipment.
  • Page 3 Embedding of cameras in the ceiling may not be allowed due to regulations in some regions. Please consult your nearby authorized JVC dealer for more details. The ceiling to mount the camera has to be strong enough to support the weight of this product.
  • Page 4: Important Safeguards

    Introduction These are general IMPORTANT SAFEGUARDS and certain items may not apply to all appliances. 1. Read all of these instructions. 2. Save these instructions for later use. 3. All warnings on the product and in the operating instructions should be adhered to. 4.
  • Page 5: Characteristics

    Thank you for purchasing this product. (These instructions are for: TK-C215V4U.) Before beginning to operate this unit, please read the instruction manual carefully in order to make sure that the best possible performance is obtained. Characteristics Realizing a High Picture Quality...
  • Page 6: Table Of Contents

    Introduction Contents Introduction Safety Precautions ... 2 Characteristics ... 5 Contents ... 6 Operating Precautions ... 7 Name of Parts ... 8 Camera ... 8 Camera (Interior) ... 9 Setting the Lens and Switches ... 10 Installation and connection About Connection Cables ... 12 Video signal cables ...
  • Page 7: Operating Precautions

    Operating Precautions To save energy, when it is not being used turn the system’s power off. This camera has been designed for indoor use. It cannot be used outdoors. Do not install or use the camera in the following places. ●...
  • Page 8: Name Of Parts

    Introduction Name of Parts Camera Mounting hole (elliptical) x 4 Use these when mounting the camera to the electrical box. (A pg. 18) NOTE: When installing the camera onto the electric box, install it using the supplied adaptor ring. Mounting hole (round) x 4 Use these when mounting the camera to the ceiling or wall.
  • Page 9: Camera (Interior)

    Camera (Interior) The dome cover, inner dome and outer case are removed. Procedures for removal. (A pg. 14 AEmbedding the camera to the ceilingB, Step 3. to Step 5.) Strap A plate to connect the camera unit and the dome cover. Fastening Screw (x 3) When embedding the camera in the ceiling, turn this screw to secure the camera.
  • Page 10: Setting The Lens And Switches

    Introduction Setting the Lens and Switches Set the video setting switches on the camera unit before mounting it. To set the switches, use a fine-tipped screwdriver. RESET/ [ SPOT ] LL PHASE WHT. BAL. IRIS LEVEL FOCUS ADJUST Function selection switch setting table (Items in bold are factory position) SELECT PHASE...
  • Page 11 [WHT.BAL.] ATW/MANUAL selection switch. For selecting whether to adjust the white balance automatically or manually. When the setting is changed from manual to ATW, the setting values in the manual mode will be reset. The camera switches to the same mode as with pressing the [RESET] button.
  • Page 12: Installation And Connection

    Installation and connection About Connection Cables The maximum connection distance varies with the type of cable used. Please refer carefully to the table for each cable during connection. * Be sure to turn off the power of devices before connecting cables. Video signal cables Connect the coaxial cables (BNC) to the video signal output connector (BNC).
  • Page 13: System Diagram

    ● Please refer to the instruction manual for the cover in use for details on installation of the embedded cover (recess bracket). ● For detail related to embedded cover (recess bracket), please contact JVC. CAUTION VIDEO OUT RISK OF ELECTRIC SHOCK...
  • Page 14: Embedding The Camera To The Ceiling

    Installation and connection Mounting the Camera (continued) Embedding the camera to the ceiling * Make use of a ceiling material with a thickness between 9.5 mm to 22 mm. Setup Open a hole in the ceiling. (R120 mm, 4 3/4 inches) Draw the fall prevention wire mounted to the ceiling slab and the cable out from the...
  • Page 15 Connecting Attach the fall prevention wire to the camera, followed by attaching it to the ceiling slab (Fall prevention wire is not included.) Connect the video signal cable. (A pg. 12) Lower the cover and connect the connectors. Upon connecting, cover the connectors using the protection cover.
  • Page 16: When Mounting The Camera Directly To The Ceiling Or On The Wall

    Installation and connection Mounting the Camera (continued) When mounting the camera directly to the ceiling or on the wall When mounting to a wall, replace areas indicated as “ceiling” in the procedures by “wall”. Setup Open a hole in the ceiling. (R 30 mm, 1 1/8 inches) Make use of the template supplied to open a hole.
  • Page 17: Adjusting Images

    Attach from the ceiling slab Fall prevention wire (not supplied) Connect the video signal cable. (A pg. 12) Lower the protection cover and connect the connectors. Upon connecting, restore the protection cover to cover the connectors. Connect the input power supply cable. (A pg.
  • Page 18: When Mounting The Camera To The Electrical Box

    Installation and connection Mounting the Camera (continued) When mounting the camera to the electrical box NOTE: Before mounting the camera to electrical boxes, please refer to local building codes for box type to use for low-voltage wiring. Connecting Align j with the shooting direction when mounting the cover to the electrical box.
  • Page 19: Adjusting Image

    Adjusting Image Adjusting Images Upon mounting the camera, adjust the images while checking the actual image. Mounting the test monitor Connect the [MONITOR] terminal of this camera to a test monitor to adjust the camera’s shooting direction, image and focus. * The power to the camera body must be ON when adjustments are performed.
  • Page 20: Adjusting The Field Angle/Focus/ Brightness

    Adjusting Image Adjusting Images (continued) Adjusting the field angle/focus/ brightness Upon determining the imaging direction, adjust the field angle, focus and iris level accordingly. The method of adjustment varies with the camera in use. Iris Level Adjustment IRIS LEVEL Focus Adjust Button FOCUS ADJUST Adjusting field angle...
  • Page 21: Mounting The Inner Dome

    Mounting the Inner Dome After setting is complete, mount the Inner dome. Mount the inner dome . Mount the inner dome to the claws (3 locations). CAUTION: ● Mount the inner dome such that it does not cover the lens. ●...
  • Page 22: Others

    Others Specifications Camera Signal system : Based on NTSC standard Scanning frequencies : 15.734 kHz (Horizontal), 59.94 Hz (Vertical) Image device: 1/4" IT CCD Effective picture elements: : 380,000 pixels, 768 (H) x 494 (V) Sync system : Line lock/Internal Video S/N: 50 dB (AGC OFF, white 50 % output)
  • Page 23 Focus chart...
  • Page 24 LST0420-001A © 2006 Victor Company of Japan, Limited...
