OperatOr and parts Manual
Loader
Models 895, S895, 895HSL,
S895HSL, 895 TSL & S895 TSL
032012
P3549A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S895 and is the answer not in the manual?

Questions and answers

Related Manuals for Allied S895

Summary of Contents for Allied S895

  • Page 1 OperatOr and parts Manual Loader Models 895, S895, 895HSL, S895HSL, 895 TSL & S895 TSL 032012 P3549A...

  • Page 3: Table Of Contents

    Table of Contents - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Table of Contents Introduction ..........................4 • Terminology ........................4 • Hydraulic (Hose Kit) ......................5 Specifications ..........................6 Safety ............................8 • Safety ..........................8 • General Safety ........................9 • Installation ........................9 • Safety Decals ........................10 • Important Precautions ....................

  • Page 4: Introduction

    With one of the largest mounting kit application lists in the industry, there is an Allied front-end loader available for nearly every tractor, large or small, new or old. Custom colors are available to match all tractor brands which adds resale value and visual appeal.

  • Page 5: Hydraulic (Hose Kit)

    Safety - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Hydraulic (Hose Kit) Hose Kit “A” Loader powered by the tractor remotes. Consists of four hoses leading from loader tubing to tractor remote couplers Hose Kit “B” Loader operated by an external OC or CC valve that is powered from the tractor remotes.

  • Page 6: Specifications

    Specifications - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Specifications...
  • Page 7 Specifications - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Model number: 895 Mounting height: 50.0 (nominal) Typical range: 46.0 to 54.0 Description Bucket Lift Leveling TSL Bucket Bore 3.00 3.50 4.00 3.00 1.75 2.25 1.75 1.75 Stroke 26.50 32.50 10.50...

  • Page 8: Safety

    Safety - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Safety Safety Instructions Remember, YOU are the key to safety. Good safety practices not only protect you, but also the people around you. Make these practices a working part of your safety program. Be certain that everyone operating this equipment is familiar with the recommended operating and maintenance procedures and follows all the safety precautions.

  • Page 9: General Safety

    Safety - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL General Safety Instructions • Have a first-aid kit available for use and know how to use it. • Have a fire extinguisher available, stored in a highly visible location, and know how to use it.

  • Page 10: Safety Decals

    Safety - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Safety Decals...

  • Page 11: Important Precautions

    Safety - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Important Precautions...

  • Page 12: Operation

    Operation - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Operation Operation General Operating Notes: Refer to tractor Operator's Manual for Operating information on the tractor's hydraulic system. Hydraulic systems using auxiliary valves should have them located for easy reach from the tractor seat.

  • Page 13: Operating Suggestions For Loading

    Operation - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Operating Suggestions for Loading When handling heavy loads, be sure to lower lift arms slowly. This is known as feathering the hydraulic lever. If load is lowered too fast and stopped suddenly, excessive shock loads are created which can damage loader or tractor.

  • Page 14: Operating Suggestions For Backfilling

    Operation - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Operating Suggestions for Backfilling DO THIS Backgrade work surface with a loaded bucket. When backfilling approach pile with a flat Release all pressure on lift cylinders so full bucket. Leave dirt in bucket. Dumping on each weight of bucket is scraping ground.

  • Page 15: Attaching The Loader To Your Tractor

    Operation - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Attaching the Loader to Your Tractor Postions the tractor as centrally as possible and drive, using lowest gear possible, into the loader frame until hoses can be connected. 2. Couple up the hydraulic hose lines to the loader or tractor valve ensuring proper function (see...
  • Page 16 Operation - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Continue to drive the tractor forward until the subframe uprights are seated in the boot. 8. Secure the subframe uprights with the bolts and washers. Torque 500 ft-lb. When mounting for the first time, the front hook...

  • Page 17: Removing The Loader From Your Tractor

    Operation - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Removing the Loader from Your Tractor When removing the loader, it must be fitted with a bucket or other WARNING suitable attachment to give the frame stability after removal. If this is not done, the frame will not remain standing.
  • Page 18 Operation - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL 4. Roll back the bucket slightly and simultaneously extend or retract the lift cylinders to free hooks from spools. Then slowly back up the tractor. 5. Once the subframe is clear of the boot and the hook is clear of the mounting boss, roll back the bucket all the way.

  • Page 20: Troubleshooting

    Troubleshooting - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Troubleshooting Problem Possible Cause Remedy Check connections and Quick couplers leaking compatibility or replace Hydraulic oil too heavy Change or replace filter Oil filter plugged Clean or replace filter Hydraulic pump worn...
  • Page 21 Troubleshooting - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Problem Possible Cause Remedy Improper hydraulic pump Repair or replace pump operation Load is greater than boom Check loader specifications lift capacity Insufficient lift capacity Internal boom cylinder Replace any worn parts and...

  • Page 22: General Instructions

    General Instructions - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL General Instructions As with any piece of equipment, the care with which your loader is operated and maintained will greatly affect it’s life and the safety of the people using it.

  • Page 23: Hsl General Note And Instructions

    HSL General Note and Instructions - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL HSL General Note and Instructions The hydraulic self-leveling system (HSL) utilizes two metering cylinders which displace oil into or out of the bucket cylinders as the loader is raised or lowered. The cylinder volumes and geometry’s are carefully matched for each loader model to provide the correct amount of oil to...

  • Page 24: Tsl General Note And Instructions

    TSL General Note and Instructions - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL TSL General Note and Instructions The true self leveling system (TSL) utilizes mechanical linkages to maintain bucket level while raising and lowering. The pivot plate weldment, leveling tubes and linkages have been developed to ensure that the bucket remains at the same position throughout its range of motion.

  • Page 25: Maintenance

    Maintenance - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Maintenance Lubrication Lubricate tractor hydraulic unit as indicated in tractor operator's manual. Keep bushings on lift arm pivots and cylinders well lubricated. Use high-grade lithium grease every 8 hours of operation.

  • Page 26: Bolt Torque

    Bolt Torque - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Bolt Torque Checking Bolt Torque The tables shown below give correct torque values for various bolts and hex bolts. Tighten all bolts to the torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide.

  • Page 28: Parts

    Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Sub Frame Assembly...
  • Page 29 Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Item Part # Description HSL/ S895 HSL/TSL 24543 895 Sub Frame Weldment Left 24544 895 Sub Frame Weldment Right 31447 895 HSL Sub Frame Weldment Left 31448 895 HSL Sub Frame Weldment Right...

  • Page 30: Main Frame Assembly And Parts List - Hsl

    Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Main Frame Assembly - HSL...
  • Page 31 Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Item Part # Description 895 S895 895 S895 24542 895 Main Frame Weldment 31442 895 HSL Main Frame Weldment 24395 Quick Attach Weldment Left 24396 Quick Attach Weldment Right 113102...

  • Page 32: Main Frame Assembly And Parts List - Tsl

    Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Main Frame Assembly - TSL...
  • Page 33 Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Item Part # Description 895 TSL S895 TSL 25233 895 TSL Mainframe 25233 S895 TSL Mainframe 24705 Quick Attach Left 24706 Quick Attach Right 113102 Cross Tube 108827 Pin Weldment...
  • Page 34 Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Item Part # Description 895 TSL S895 TSL 813228 1/2" Wing Nut (Pl) 81637 1/2" Lock Washer (Pl) 813356 Decal - Buhler Allied x 1.75 114132 Decal - TSL x 1.75...

  • Page 36: Hydraulic Plumbing Assembly And Parts List - Hsl

    Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Hydraulic Plumbing Assembly...
  • Page 37 Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Item Part # Description 24417 3.0 Dia. x 26.50 Cyl. Assy. Bucket 24774 3.50 Dia. x 32.50 Cyl. Assy. Lift 811754 3/8 x 18" Hose 3/4 Morb x 3/4 Swfjic 811434 3/8 x 30"...

  • Page 38: Hydraulic Plumbing Assembly And Parts List - Tsl

    Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Hydraulic Plumbing Assembly - HSL...
  • Page 39 Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Item Part # Description 24421 4.0 Dia. x 10.50 Cyl. Assy. Level 24417 3.5 Dia. x 26.50 Cyl. Assy Bucket 24773 3.0 Dia. x 32.50 Cyl. Assy Lift 811754 3/8 x 18 Hose 3/4 Morb x 3/4 Swfjic...

  • Page 40: Hydraulic Cylinder Assembly

    Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Hydraulic Plumbing Assembly - TSL...
  • Page 41 Parts - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Item Part # Description 24774 3.5 Dia x 32.50 Cylinder Assembly Lift 24734 3.0 Dia x 24.75 Bucket Cylinder 812069 Tee 3/4-16Mjic x 3/4-16 Mjic 886897 Adaptor Str 7/8 Morb x 3/4 Mijc 811414 Elbow 90º...

  • Page 42: Assembly

    Assembly - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Assembly Hydraulic Cylinder Assembly Item Description Bucket Cylinders Lift Cylinders Diameter 3.00" 3.00” 3.00" 3.50" 4.00" Length of Stroke 26.50" 24.75” 32.50" 32.50" 10.50" Retracted Length 39.50" 53.25” 45.25" 45.25"...

  • Page 43: Pre-Delivery Check List

    Safety - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL Pre-delivery Check List Before delivering this equipment please complete the following check list. __ 1. The loader has been installed using the appropriate mounting kit for the tractor and loader.
  • Page 44 Repair Parts Limited Warranty Buhler Industries Inc. warrants Allied by Farm King replacement parts purchased after the expiration of the Buhler Industries Inc. Limited Warranty, and used and serviced as provided for in the Operator’s Manual, to be free from defects in materials or workmanship for a period of thirty (30) days from the invoice date for the parts.
  • Page 45 Warranty Requirements To be covered by warranty, each Allied by Farm King new product must be registered with Buhler Industries Inc. within thirty (30) days of delivery to original retail purchaser. If the customer decides to purchase replacement components before the warranty disposition of such components is determined, Buhler Industries Inc.
  • Page 46 Warranty - 895, S895, 895HSL, S895HSL, 895TSL & S895 TSL (Note that some provinces or states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations and exclusion may not apply to you.) This warranty gives you specific legal rights and...
  • Page 48 www.farm-king.com www.farm-king.com 1330 43rd Street NW Fargo, North Dakota USA 58102 Ph.: 701.282.7014 | Fax: 701.282.5865 E-mail: info@buhler.com www.farm-king.com Equipment shown is subject to change without notice. ©2010 Buhler Trading Inc. Printed in USA. TSX:BUI a division of Buhler Industries Inc.
