OPERATOR AND PARTS MANUAL
Loader
Models 895 & 895 TSL
082014
P3549

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 895 and is the answer not in the manual?

Questions and answers

Related Manuals for Allied 895

Summary of Contents for Allied 895

  • Page 1 OPERATOR AND PARTS MANUAL Loader Models 895 & 895 TSL 082014 P3549...

  • Page 3: Table Of Contents

    Table of Contents - 895 & 895TSL Table of Contents Introduction ..........................4 • Terminology ........................4 • Hydraulic (Hose Kit) ......................5 Specifications ..........................6 Safety ............................8 • Safety Instructions ......................8 • General Safety Instructions .....................9 • Installation ........................9 • Safety Decals ........................10 •...

  • Page 4: Introduction

    With one of the largest mounting kit application lists in the industry, there is an Allied front-end loader available for nearly every tractor, large or small, new or old. Custom colors are available to match all tractor brands which adds resale value and visual appeal.

  • Page 5: Hydraulic (Hose Kit)

    Safety - 895 & 895TSL Hydraulic (Hose Kit) Hose Kit “A” Loader powered by the tractor remotes. Consists of four hoses leading from loader tubing to tractor remote couplers Hose Kit “C” Loader operated by an external valve that is plumbed into the tractor hydraulic system.

  • Page 6: Specifications

    Specifications - 895 & 895TSL Specifications...
  • Page 7 Specifications - 895 & 895TSL Model number: 895 Mounting height: 50.0 (nominal) Typical range: 46.0 to 54.0 Description Bucket Lift TSL Bucket Bore 3.00 3.50 3.00 1.75 2.00 1.75 Stroke 26.50 32.50 24.75 A - Maximum lift height (full height): 172" (14.3') B - Clearance with bucket dumped (full height): 140"...

  • Page 8: Safety

    Safety - 895 & 895TSL Safety Safety Instructions Remember, YOU are the key to safety. Good safety practices not only protect you, but also the people around you. Make these practices a working part of your safety program. Be certain that everyone operating this equipment is familiar with the recommended operating and maintenance procedures and follows all the safety precautions.

  • Page 9: General Safety Instructions

    Safety - 895 & 895TSL General Safety Instructions • Have a first-aid kit available for use and know how to use it. • Have a fire extinguisher available, stored in a highly visible location, and know how to use it.

  • Page 10: Safety Decals

    Safety - 895 & 895TSL Safety Decals...

  • Page 11: Important Precautions

    Safety - 895 & 895TSL Important Precautions...

  • Page 12: Operation

    Operation - 895 & 895TSL Operation Operation General Operating Notes: Refer to tractor Operator's Manual for Operating information on the tractor's hydraulic system. Hydraulic systems using auxiliary valves should have them located for easy reach from the tractor seat. Hoses should be connected in such a manner that pushing forward on valve handles lowers...

  • Page 13: Operating Suggestions For Loading

    Operation - 895 & 895TSL Operating Suggestions for Loading When handling heavy loads, be sure to lower lift arms slowly. This is known as feathering the hydraulic lever. If load is lowered too fast and stopped suddenly, excessive shock loads are created which can damage loader or tractor.

  • Page 14: Operating Suggestions For Backfilling

    Operation - 895 & 895TSL Operating Suggestions for Backfilling DO THIS Backgrade work surface with a loaded bucket. When backfilling approach pile with a flat Release all pressure on lift cylinders so full bucket. Leave dirt in bucket. Dumping on each weight of bucket is scraping ground.

  • Page 15: Attaching The Loader To Your Tractor

    Operation - 895 & 895TSL Attaching the Loader to Your Tractor Postion the tractor as centrally as possible and drive, using lowest gear possible, into the loader frame until hoses can be connected. 2. Couple up the hydraulic hose lines to the loader or tractor valve ensuring proper function (see...
  • Page 16 Operation - 895 & 895TSL Continue to drive the tractor forward until the subframe uprights are seated in the boot. 8. Secure the subframe uprights with the bolts and washers. Torque 500 ft-lb. When mounting for the first time, the front hook...

  • Page 17: Removing The Loader From Your Tractor

    Operation - 895 & 895TSL Removing the Loader from Your Tractor When removing the loader, it must be fitted with a bucket or other WARNING suitable attachment to give the frame stability after removal. If this is not done, the frame will not remain standing.
  • Page 18 Operation - 895 & 895TSL 4. Roll back the bucket slightly and simultaneously extend or retract the lift cylinders to free hooks from spools. Then slowly back up the tractor. 5. Once the subframe is clear of the boot and the hook is clear of the mounting boss, roll back the bucket all the way.

  • Page 20: Troubleshooting

    Troubleshooting - 895 & 895TSL Troubleshooting Problem Possible Cause Remedy Check connections and Quick couplers leaking compatibility or replace Hydraulic oil too heavy Change or replace filter Oil filter plugged Clean or replace filter Hydraulic pump worn Repair or replace pump...
  • Page 21 Troubleshooting - 895 & 895TSL Problem Possible Cause Remedy Improper hydraulic pump Repair or replace pump operation Load is greater than boom Check loader specifications lift capacity Insufficient lift capacity Internal boom cylinder Replace any worn parts and leakage install a seal repair kit...

  • Page 22: General Instructions

    General Instructions - 895 & 895TSL General Instructions As with any piece of equipment, the care with which your loader is operated and maintained will greatly affect its life and the safety of the people using it. Keep all pivots well lubricated for longer bushing life. Inspect every 500 hours of operation for wear.

  • Page 23: Tsl General Note And Instructions

    TSL General Note and Instructions - 895 & 895TSL TSL General Note and Instructions The true self leveling system (TSL) utilizes mechanical linkages to maintain bucket level while raising and lowering. The pivot plate weldment, leveling tubes and linkages have been developed to ensure that the bucket remains at the same position throughout its range of motion.

  • Page 24: Maintenance

    Maintenance - 895 & 895TSL Maintenance Lubrication Lubricate loader bushings and pivots every eight hours of average operation with high-grade grease. For grease fitting locations see illustration below. Select grease based on the expected outside temperature range. Lithium, Molybdenum and synthetic greases are preferred. Use the tractor hour meter as a guide.

  • Page 25: Bolt Torque

    Bolt Torque - 895 & 895TSL Bolt Torque Checking Bolt Torque The tables shown below give correct torque values for various bolts and hex bolts. Tighten all bolts to the torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide.

  • Page 26: Parts

    Parts - 895 & 895TSL Sub Frame Assembly...
  • Page 27 Part # Description 24543 895 Sub Frame Weldment Left 24544 895 Sub Frame Weldment Right 31447 895 TSL Sub Frame Weldment Left 31448 895 TSL Sub Frame Weldment Right 112751 Hook Weldment 112747 Plate Clamp 113125 Spacer Block 112748 Shim 113204 Cross Member 113077 Shaft Pivot 2.25 Dia x 6.50 Long...

  • Page 28: Main Frame Assembly And Parts List

    Parts - 895 & 895TSL Main Frame Assembly...
  • Page 29 Parts - 895 & 895TSL Item Part # Description 24542 895 Main Frame Weldment 24395 Quick Attach Weldment Left 24396 Quick Attach Weldment Right 113102 Tube Cross Qtach 108827 Pin Weldment 111231 Stand Weldment 113114 Strap Stand 84162 Cotter Pin 0.156 x 1.00 Pl 110907 Pin 0.625 Dia.

  • Page 30: Main Frame Assembly And Parts List - Tsl

    Parts - 895 & 895TSL Main Frame Assembly - TSL...
  • Page 31 Parts - 895 & 895TSL Item Part # Description 895 TSL 25233 895 TSL Mainframe 24705 Quick Attach Left 24706 Quick Attach Right 113102 Cross Tube 108827 Pin Weldment 114304 Stand Tube 114303 Stand Foot 113690 Link Spacer 110907 Stand Pin 0.625 Diameter...
  • Page 32 Parts - 895 & 895TSL Item Part # Description 895 TSL 81637 1/2" Lock Washer (Pl) 86273 Nut Lock 0.438 NC GrB (Pl) 813935 Decal “Important” 815194 895 Series Decal LHS 815195 895 Series Decal RHS...

  • Page 34: Hydraulic Plumbing Assembly And Parts List

    Parts - 895 & 895TSL Hydraulic Plumbing Assembly View A View B...
  • Page 35 Parts - 895 & 895TSL Item Part # Description 24417 3.0 Dia. x 26.50 Cylinder Assembly Bucket 24774 3.50 Dia. x 32.50 Cylinder Assembly Lift 811754 3/8 x 18" Hose 3/4 Morb x 3/4 Swfjic 114492 3/8 x 22" Hose 3/4 Swfjic x 3/4 Swfjic 114605 3/8 x 24"...

  • Page 36: Hydraulic Plumbing Assembly And Parts List - Tsl

    Parts - 895 & 895TSL Hydraulic Plumbing Assembly - TSL...
  • Page 37 Parts - 895 & 895TSL Item Part # Description 24774 3.5 Dia x 32.50 Cylinder Assembly Lift 24734 3.0 Dia x 24.75 Bucket Cylinder 812069 Tee 3/4-16Mjic x 3/4-16 Mjic 886897 Adaptor Str 7/8 Morb x 3/4 Mijc 811414 Elbow 90º 3/4-16 Morb To 3/4 Mjic 812128 Elbow 90º...

  • Page 38: Assembly

    Assembly - 895 & 895TSL Assembly Hydraulic Cylinder Assembly Item Description Bucket Cylinders Lift Cylinders Diameter 3.00" 3.00" 3.50" Length of Stroke 26.50" 24.75" 32.50" Retracted Length 39.25" 53.25" 45.25" Extended Length 65.75" 78.00" 77.75" Cylinder Assembly No. 24417 24734 24774 Seal Kit No.

  • Page 39: Pre-Delivery Check List

    Safety - 895 & 895TSL Pre-delivery Check List Before delivering this equipment please complete the following check list. __ 1. The loader has been installed using the appropriate mounting kit for the tractor and loader. __ 2. The hydraulic system installed is appropriate for the tractor and loader.

  • Page 40: Warranty

    Repair Parts Limited Warranty Buhler Industries Inc. warrants Allied by Farm King replacement parts purchased after the expiration of the Buhler Industries Inc. Limited Warranty, and used and serviced as provided for in the Operator’s Manual, to be free from defects in materials or workmanship for a period of thirty (30) days from the invoice date for the parts.
  • Page 41 Warranty Requirements To be covered by warranty, each Allied by Farm King new product must be registered with Buhler Industries Inc. within thirty (30) days of delivery to original retail purchaser. If the customer decides to purchase replacement components before the warranty disposition of such components is determined, Buhler Industries Inc.
  • Page 42 Warranty - 895 & 895TSL (Note that some provinces or states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations and exclusion may not apply to you.) This warranty gives you specific legal rights and you may also have other rights, which vary from province to province or state to state.
  • Page 44 www.farm-king.com www.farm-king.com 1330 43rd Street NW Fargo, North Dakota USA 58102 Ph.: 701.282.7014 | Fax: 701.282.5865 E-mail: info@buhler.com www.farm-king.com Equipment shown is subject to change without notice. ©2014 Buhler Trading Inc. Printed in USA. TSX:BUI a division of Buhler Industries Inc.
