- Page 1 OPERATOR AND PARTS MANUAL Loader Models 795 & 795 TSL 072014 P9949...
-
Page 3: Table Of Contents
Table of Contents - 795 Loader Table of Contents Introduction ..........................4 • Terminology ........................4 • Hydraulic (Hose Kit) ......................5 Specifications ..........................6 Safety ............................8 • Safety Instructions ......................8 • General Safety Instructions .....................9 • Installation ........................9 • Safety Decals ........................10 • Important Precautions ....................11 Operation ...........................12... -
Page 4: Introduction
With one of the largest mounting kit application lists in the industry, there is an Allied front-end loader available for nearly every tractor, large or small, new or old. Custom colors are available to match all tractor brands which adds resale value and visual appeal. -
Page 5: Hydraulic (Hose Kit)
Introduction - 795 Loader Hydraulic (Hose Kit) Hose Kit “A” Loader powered by the tractor remotes. Consists of four hoses leading from loader tubing to tractor remote couplers Hose Kit “C” Loader operated by an external valve that is plumbed into the tractor hydraulic system. -
Page 6: Specifications
Specifications - 795 Loader Specifications... - Page 7 Specifications - 795 Loader Model number: 795 Mounting height: 43.0" (nominal) Typical range: 40.0 to 46.0 Description Bucket Lift TSL Bucket Bore 3.00 3.00 3.00 1.50 1.75 1.75 Stroke 20.50 30.00 22.00 A - Maximum lift height (full height): 163" (13.6') B - Clearance with bucket dumped (full height): 137"...
-
Page 8: Safety
Safety - 795 Loader Safety Safety Instructions Remember, YOU are the key to safety. Good safety practices not only protect you, but also the people around you. Make these practices a working part of your safety program. Be certain that everyone operating this equipment is familiar with the recommended operating and maintenance procedures and follows all the safety precautions. -
Page 9: General Safety Instructions
Safety - 795 Loader General Safety Instructions • Have a first-aid kit available for use and know how to use it. • Have a fire extinguisher available, stored in a highly visible location, and know how to use it. • Wear appropriate protective gear. This list may include but is not limited to:... -
Page 10: Safety Decals
Safety - 795 Loader Safety Decals... -
Page 11: Important Precautions
Safety - 795 Loader Important Precautions... -
Page 12: Operation
Operation - 795 Loader Operation Operation General Operating Notes: Refer to tractor Operator's Manual for Operating information on the tractor's hydraulic system. Hydraulic systems using auxiliary valves should have them located for easy reach from the tractor seat. Hoses should be connected in such a manner that pushing forward on valve handles lowers... -
Page 13: Operating Suggestions For Loading
Operation - 795 Loader Operating Suggestions for Loading When handling heavy loads, be sure to lower lift arms slowly. This is known as feathering the hydraulic lever. If load is lowered too fast and stopped suddenly, excessive shock loads are created which can damage loader or tractor. -
Page 14: Operating Suggestions For Backfilling
Operation - 795 Loader Operating Suggestions for Backfilling DO THIS Backgrade work surface with a loaded bucket. When backfilling approach pile with a flat Release all pressure on lift cylinders so full bucket. Leave dirt in bucket. Dumping on each weight of bucket is scraping ground. -
Page 15: Attaching The Loader To Your Tractor
Operation - 795 Loader Attaching the Loader to Your Tractor Postion the tractor as centrally as possible and drive, using lowest gear possible, into the loader frame until hoses can be connected. 2. Couple up the hydraulic hose lines to the loader or tractor valve ensuring proper function (see... - Page 16 Operation - 795 Loader Continue to drive the tractor forward until the subframe uprights are seated in the boot. 8. Secure the subframe uprights with the bolts and washers. Torque 500 ft-lb. When mounting for the first time, the front hook...
-
Page 17: Removing The Loader From Your Tractor
Operation - 795 Loader Removing the Loader from Your Tractor When removing the loader, it must be fitted with a bucket or other WARNING suitable attachment to give the frame stability after removal. If this is not done, the frame will not remain standing. - Page 18 Operation - 795 Loader 4. Roll back the bucket slightly and simultaneously extend or retract the lift cylinders to free hooks from spools. Then slowly back up the tractor. 5. Once the subframe is clear of the boot and the hook is clear of the mounting boss, roll back the bucket all the way.
-
Page 19: General Instructions
General Instructions - 795 Loader General Instructions As with any piece of equipment, the care with which your loader is operated and maintained will greatly affect its life and the safety of the people using it. Keep all pivots well lubricated for longer bushing life. Inspect every 500 hours of operation for wear. -
Page 20: Tsl General Note And Instructions
TSL General Note and Instructions - 795 Loader TSL General Note and Instructions The true self leveling system (TSL) utilizes mechanical linkages to maintain bucket level while raising and lowering. The pivot plate weldment, leveling tubes and linkages have been developed to ensure that the bucket remains at the same position throughout its range of motion. -
Page 21: Troubleshooting
Troubleshooting - 795 Loader Troubleshooting Problem Possible Cause Remedy Check connections and Quick couplers leaking compatibility or replace Hydraulic oil too heavy Change or replace filter Oil filter plugged Clean or replace filter Hydraulic pump worn Repair or replace pump... - Page 22 Troubleshooting - 795 Loader Problem Possible Cause Remedy Improper hydraulic pump Repair or replace pump operation Load is greater than boom Check loader specifications lift capacity Insufficient lift capacity Internal boom cylinder Replace any worn parts and leakage install a seal repair kit...
-
Page 23: Maintenance
Maintenance - 795 Loader Maintenance Lubrication Lubricate loader bushings and pivots every eight hours of average operation with high-grade grease. For grease fitting locations see illustration below. Select grease based on the expected outside temperature range. Lithium, Molybdenum and synthetic greases are preferred. Use the tractor hour meter as a guide. -
Page 24: Bolt Torque
Bolt Torque - 795 Loader Bolt Torque Checking Bolt Torque The tables shown below give correct torque values for various bolts and hex bolts. Tighten all bolts to the torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide. -
Page 26: Parts
Parts - 795 Loader Sub Frame Assembly... - Page 27 Part # Description 31411 795 Sub Frame Weldment Left 31412 795 Sub Frame Weldment Right 31408 795 TSL Sub Frame Weldment Left 31409 795 TSL Sub Frame Weldment Right 112751 Hook Weldment 112747 Plate Clamp 112746 Spacer Block 112748 Shim 111423 Cross Member Weldment 112642 Shaft Pivot 1.75 Dia x 5.50 Long...
-
Page 28: Main Frame Assembly Drawing And Parts List
Parts - 795 Loader Main Frame Assembly... - Page 29 Parts - 795 Loader Item Part # Description 31596 795 Main Frame Weldment 24296 Quick Attach Weldment Left 24297 Quick Attach Weldment Right 816343 Cross Tube 108827 Pin Weldment 111231 Stand Weldment 111232 Strap Stand 110907 Pin 0.625 Dia. Stand...
-
Page 30: Main Frame Assembly Drawing And Parts List -Tsl
Parts - 795 Loader Main Frame Assembly - TSL... - Page 31 Parts - 795 Loader Item Part # Description Qty TSL 24731 795 TSL Mainframe 24717 Quick Attach Left 24716 Quick Attach Right 816343 Cross Tube 108827 Pin Weldment 114296 Stand Tube 114303 Stand Foot 113690 Link Spacer 110907 Stand Pin 0.625 Diameter...
-
Page 32: Hydraulic Plumbing Assembly And Parts List
Parts - 795 Loader Hydraulic Plumbing Assembly... - Page 33 Parts - 795 Loader Item Part # Description 24309 3.0 Dia. x 20.50 Cyl. Assy. Bucket 24314 3.0 Dia. x 30.00 Cyl. Assy. Lift 811572 3/8 x 15" Hose 3/4 Morb x 3/4 Swfjic 811754 3/8 x 18" Hose 3/4 Morb x 3/4 Swfjic 114605 3/8 x 24"...
-
Page 34: Hydraulic Plumbing Assembly And Parts List - Tsl
Parts - 795 Loader Hydraulic Plumbing Assembly - TSL... - Page 35 Parts - 795 Loader Item Part # Description 24314 3.0 Dia x 30.00 Cylinder Assembly Lift 24708 3.0 Dia x 22.00 Cylinder Assembly Bucket 812069 Tee 3/4-16Mjic x 3/4-16 Mjic 886897 Adaptor Str 7/8 Morb x 3/4 Mijc 811414 Elbow 90° 3/4-16 Morb To 3/4 Mjic 812128 Elbow 90°...
-
Page 36: Assembly
Assembly - 795 Loader Assembly Hydraulic Cylinder Assembly Bucket TSL Bucket Lift Item Description Cylinders Cylinders Cylinders Diameter 3.00" 3.00" 3.00" Length of Stroke 20.50" 22.00" 30.00" Retracted Length 35.38" 51.75" 41.50" Extended Length 55.88" 73.75" 71.50" Cylinder Assembly 24309... -
Page 37: Pre-Delivery Check List
Safety - 795 Loader Pre-delivery Check List Before delivering this equipment please complete the following check list. __ 1. The loader has been installed using the appropriate mounting kit for the tractor and loader. __ 2. The hydraulic system installed is appropriate for the tractor and loader. -
Page 38: Warranty
Repair Parts Limited Warranty Buhler Industries Inc. warrants Allied by Farm King replacement parts purchased after the expiration of the Buhler Industries Inc. Limited Warranty, and used and serviced as provided for in the Operator’s Manual, to be free from defects in materials or workmanship for a period of thirty (30) days from the invoice date for the parts. - Page 39 Warranty Requirements To be covered by warranty, each Allied by Farm King new product must be registered with Buhler Industries Inc. within thirty (30) days of delivery to original retail purchaser. If the customer decides to purchase replacement components before the warranty disposition of such components is determined, Buhler Industries Inc.
- Page 40 Warranty - 795 Loader (Note that some provinces or states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations and exclusion may not apply to you.) This warranty gives you specific legal rights and you may also have other rights, which vary from province to province or state to state.
