Page 12 Be sure to read the contents thoroughly. This manual will acquaint you with the use and maintenance of your new Four Winns boat. This manual also pro vides special information critical to the safety of the passengers, and longevity of the equipment. The infor- mation on the following page lists the graphics used to increase the visibility of these important messages.
Page 13: Safety Messages
Safety Messages The popularity of boating and other water sports has grown tremendously in the past few years. Because of this, safety is an important issue for everyone who shares our waterways. Remember that along with the freedom and exhilaration of boating comes the responsibility that you have for the safety of your passengers and the other boaters who share the water with you.
Page 14 We’d also like to remind you to be kind to our environment while you’re boating. Don’t throw garbage and other refuse overboard. Do your best to keep harmful compounds like gasoline, oil and antifreeze out of the water. Please see the notifications below: DISCHARGE OF OIL PROHIBITED THE FEDERAL WATER POLLUTION CONTROL ACT PROHIBITS THE DISCHARGE OF OIL OR OILY WASTE INTO OR UPON THE NAVIGABLE WATERS OF THE UNITED STATES, OR THE...
Page 15: Label Locations
In addition, the Hull Identifica tion Number ® are important to ensure the safe operation of your Four Winns plate is permanently attached below the deck-hull joint at the stern on the starboard side. Below are letters corresponding to the various locations for each item in the photos. See pages 14-16 for the actual wording of each of the various warning labels found on your boat.
Page 16 CAPACITY & WARNING LABELS NMMA Capacity Plate Imprinted Label on Ignition Panel Preface Owner’s Manual Page 13...
Page 17 Gasoline Vapor-Blower Warning Label Rotating Propeller - Helm Warning Label Rotating Propeller - Ladder Warning Label Leaking Fuel Warning Label CO Swim Platform and Ski Tow Warning Label Lounging Area Warning Label No Ventilation - Do Not Store Fuel Warning Label Transom/Side Door Warning Label CO-Cabin Warning Label CO-Helm Warning Label...
Page 18 Swim Platform Lounging Seats Warning Label NMMA Certified Sticker Winning Edge Sticker EU Builders Plate - CE Certification Plate (Export) Canadian Conformity Label Preface Owner’s Manual Page 15...
Page 19: Operation
“rules of the road”. Such cours es are strongly Besides the equipment installed on the boat by recommended. Books on this subject are also Four Winns, certain other equipment is re quired for available from local libraries. passenger safety. The “Boating Basics, A Guide to Responsible Boating”, describes the Federal equip-...
Page 20: Drugs And Alcohol
Look for other signs of potential prob lems. handle, or windshield. Check for the scent of fuel fumes. 4. Activate the bilge blower. Check the blower NOTICE: Four Winns boats are not equipped output. with a lightning protection system. A - 7...
Page 21 required by the indications on the dip sticks. 2. Turn the key switch to start and hold until engine Refer to Table 1: “SAE Viscosity Chart” and your starts, for no longer than 10 seconds. If engine engine manual included in the owner’s packet. does not start, let go momentarily, then try again.
Page 22: Grounding And Towing
Because of this, Four Winns strongly suggests that gagement. these activities be left to those who have the equip- ment and knowledge such as the US Coast Guard or •...
Page 23: Boat Owner Registration
tion can be obtained by calling 1 800-336-BOAT (2628) D. Laws and Regulations or by visiting their website at: www.boatus.com/ The US Coast Guard is the authority of the water- courseline. ways; they are there to help the boating public. State The United States Power Squadron also offers free boating regulations are enforced by local authorities.
Page 24: Discharge Of Oil
A - 14 DISCHARGE OF OIL The Federal Water Pollution Control Act prohibits the discharge of oil waste into or upon the navigable waters of the United States or the waters of the contiguous zone if such discharge causes a film or sheen upon or a discoloration of the surface of the water or causes a sludge or emulsion beneath the surface of the water.
Page 25 must note that State and local regulations may further restrict the disposal of garbage. Operators shall display one or more placards in a prominent location and in sufficient numbers so they can be observed and read by crew and passengers. These locations might include embarkation points, food service areas, galleys, garbage handling spaces and common deck spaces frequented by crew and pas-...
Page 26: Boating Safety
Boating Safety B - 1 GENERAL C. PFD Types Five types of PFDs have been approved by the US As the owner/operator of the boat, you are respon- Coast Guard. The PFDs are described as follows: sible for assuring that all required safety equipment is aboard.
Page 27 3. Teach children how to put a PFD on and allow them to try it in the water. That way, they know what the PFD is for and how it works. They will feel more comfortable with it if they suddenly find themselves in the water.
Page 28 Four Winns sport boat and deck boat models are considered to be Class 1 powerboats (16 to less than 26 feet). Since they have permanently-installed fuel tanks, they are required to carry one (1) B1 type hand- held portable fire extinguisher.
Page 29: Carbon Monoxide
“Educa tional Information About Carbon Extra drain plug Spark plugs Spare wire Monox ide”. This information pertains to all gasoline- Extra prop nut/washer powered boats manufactured by Four Winns. Gear For Extended Cruises NOTICE Foul weather gear Parallel rulers Dividers...
Page 30 A. Properties and Characteristics Certain health related problems and age will increase of Carbon Monoxide the effects of CO. People who smoke or are exposed to high concentrations of cigarette smoke, consume 1. Carbon monoxide is a colorless, odorless and alcohol or have lung disorders or heart problems, are tasteless gas.
Page 31 3. Observe the victim(s). The following are examples of possible 4. Administer oxygen if available. situations where carbon monoxide can accumulate within your boat while docked, 5. Contact medical help. If the victim is not breathing, anchored, or underway. Become familiar perform rescue breathing or approved cardiopul- monary resuscitation (CPR), as appropriate, until with these examples and their precautions...
Page 32: Exhaust Fumes
J. The Effect of Boats Moored Along Side 2. Excessive or unequally distributed weight. A boat operator should be aware that carbon monox- ide is emitted from any boat’s exhaust. The operation, mooring, and anchoring in an area containing other boats may be in an atmosphere containing CO not of the operator’s making.
Page 33 When the propulsion engine or generator is running, er manufacturer’s literature for additional information. CO is produced and may remain in the vicinity of the Please consult with your Four Winns Dealer regarding exhaust outlet (including underwater exhaust outlets). availability.
Page 34 CO if it operates at a rela- in the marine market place and are not an option tively high tem perature within manufacturer’s available through Four Winns. Portable generators specifica tions. will produce CO. These sets discharge their exhaust products in locations which can lead to an increase c.
Page 35: Safe Boating Practices
1. Gaskets at cylinder head connection 2. Check gaskets and sealing surfaces on hatches, doors, and access panels. 2. Casting and pipe fittings in the dry section Y. Maintenance - Liquid Drains 3. All joints Sink, shower and condensate drains can be a source 4.
Page 36: Personal Injury
• Observe all safety signs and warnings both D. Propeller inside the boat and in the immediate boating area. PERSONAL INJURY • Become familiar with, and adhere to, Do not allow anyone near a propeller, even the “Rules of the Road”. when the engine is off.
Page 37 F. Operation By Minors in a full circle to prevent damage in case of shifting winds. Minors should always be supervised by an adult Make certain you have enough anchor line (or scope) whenever operating a boat. Many states have laws re- garding the minimum age and licensing requirements for the depth of water.
Page 38: Water Sports
Anchors are available in different shapes, sizes and weights to fit different boats, uses, and conditions. 7. Always participate in water sports in safe areas. Your Four Winns dealer can tell you which anchor Stay away from other boats, beaches, restricted areas, swimmers and heavily traveled waterways.
Page 39 7. Give immediate attention to a person who has B. Water Skiing/Wakeboarding/Kneeboarding fallen. He or she is vulnerable in the water alone and may not be seen by other boaters. The popular sport of water skiing has brought a special set of safety precautions to observe in boating. 8.
Page 40: Basic Seamanship
Basic Seamanship C - 1 GENERAL Basic rules of seamanship, general information about navigational aids, and sources for additional reading and boater education are presented in this portion of your owner’s manual. A. Boating Regulations The US Coast Guard is the authority of the waterways. State boating regulations are enforced by local au- thorities.
Page 41 6. Night Running Boats operating between sunset and sunrise (hours vary by state), or in conditions of reduced visibility, must use navigational lights. Nighttime operation, especially during bad weather or fog, can be danger- ous. All “Rules of the Road” apply at night, but it is best to slow down and stay clear of all boats regard- less of who has right-of-way.
Page 42: Navigational Aids
blasts) if intent is not clear. A short blast is one or two called cans, look like cylinders. Unlighted red nun seconds long. A long blast is 4 to 6 seconds long. The buoys have a cone shaped top with their points Navigational Aids Chart at the end of this section lists cut off.
Page 43: Recommended Reading
patterns. For example, they may flash every three sec- C - 3 RECOMMENDED READING onds, or in groups such as two flashes and a pause. There are a number of flashing patterns, which help We recommend that you read the boating literature you identify the light at night.
Page 44: Navigational Aids Chart
sell your boat, it demonstrates to perspective buyers Skippers Course GPO Superintendent of Documents that you have done a good job taking care of it. Washington, DC 20012 202 512-1800 The Service Information Sheet allows you to record 202 512-2250 (fax) all the pertinent information regarding your Four ®...
Page 45: Warranty And Service
Edge™ card within this time frame please contact The Four Winns Winning Edge™ Owner Protection your Four Winns selling dealer for resolution. If Plan provides the new Four Winns purchaser with one upon receipt of the card you discover a discrepancy, of the most comprehensive corporate commitments please notify Four Winns at 231 775-1343.
Page 46 The service information with the Four Winns Customer Service Department, form should remain in the owners manual for easy to obtain it quickly. Four Winns will only sell replace- reference. ment parts to established Four Winns dealers. If you...
Page 47: Construction Standards
Along with boating, comes responsibility. Responsibility for safety, boating laws, and the environment. Please Show your colors! Four Winns offers a complete line think about the future of our waterways, oceans and of sports clothing designed to complement your new marine life while you’re out enjoying them and take all...
Page 48: Name / Address Change Form
NAME / ADDRESS CHANGE FORM Name & Address: ___________________________________________________ Please print clearly. ___________________________________________________ ___________________________________________________ ___________________________________________________ Telephone & E-Mail Address: ___________________________________________________ Hull Identification Number: ___________________________________________________ Boat Model: ___________________________________________________ NOTE: For warranty transfer please use the Warranty Transfer Request Form also Date of Purchase: ___________________ included in this manual.
Page 49 Warranty and Service - Section D Owner’s Manual Page 46...
Page 50: Warranty Registration Transfer Request
(5) years of the original retail sale. The transfer fee must be paid within fifteen (15) days of purchase of the used boat by check, money order or cashier’s check payable to Four Winns. We will notify the appropriate engine manufacturer of the boat warranty transfer.
Page 51 Warranty and Service - Section D Owner’s Manual Page 48...
Page 52: Engines And Instrumentation
Ringing in the ears be taken directly to an autho rized dealer for resolution. g. Tightness across the chest The Four Winns dealer from whom you purchased your h. Headache boat will handle all warranty and service matters with i.
Page 53 The See Figure E1. propeller(s) included with each Four Winns ® boat pro- vides the best general performance based on data B.
Page 54: Running Angle & Power Trim/Tilt
Boat Properly Trimmed For additional information on factors affecting perfor- mance, please consult your Four Winns dealer. E - 5 RUNNING ANGLE & POWER TRIM/TILT Boat Too High - Trim Bow “Down”...
Page 55 Al w ays press the trim tab swit ches in short one (1) sec ond bursts. If pressed too long, you can ove r com pen sate, and po ten tially lose con trol. DO NOT try to cor rect the situ a tion by pressing the other upper trim tab switch.
Page 56 E - 7 INSTRUMENTATION The helm stations on Four Winns ® models are equipped with a complete set of individual engine instrument gauges. These instrument gauges allow...
Page 57 DO NOT rely on the speedometer when trying to achieve a “NO WAKE” condition in a harbor or other enclosed water way. ALWAYS reduce throttle! Speed ometers are not effective at mea suring low opera tional speeds. You are responsible for damage caused by the wake of your boat.
Page 58 F. Fuel Gauge (4-in-1 Gauge) 2. The depth sounder has an audible and LCD dis- played depth alarm with adjustable shallow and deep The fuel gauge (included in the 4-in-1 gauge) displays limits and a depth below keel offset feature. These settings once made are stored in memory and will the level of fuel that is present in the fuel tank.
Page 59 below the keel or the depth below the transducer. without activating the other ship’s systems. Addition al Pressthe up or down arrow switches to adjust the information on ignition switch operation is covered in reading to the desired depth no more than 19.9 ft. Section A Opera tion, of this manual.
Page 60 (radio, depth sounder, etc.). DO NOT rely on the gine does not stop, see your Four Winns Dealer. compass readings until initial adjust ment (compensa- tion) has been performed. If the boat has a factory- 3.
Page 61 Periodically, spray the ignition switch with a contact cleaner. The ignition switch and all instruments, controls, etc. should be protected from the weather when not in use. Four Winns offers appropriate weather covers for each model. Excessive exposure can lead to gauge and ignition switch difficulties.
Page 62: Control Systems
Control Systems F - 1 GENERAL F - 2 CONTROL OPERATION Control systems permit operation of the engine’s A. General throttle and shift mechanisms. Typically, they consist of three major components; the control, the throttle NOTICE and shift cables. The control information included in this section is general only.
Page 63 2. To go FORWARD - move the shift/throttle lever forward. Once forward gear engagement is complete, push shift/throttle lever forward until desired speed is achieved. Trim/Tilt 3. To go in REVERSE - move the shift/throttle lever Switch rearward. Once rearward gear engagement is complete, push shift/throttle lever rearward until desired speed is achieved.
Page 64: Neutral Safety Switch
Control or cable adjustments are required to correct this condition should it persist. See your Four Winns dealer for necessary control and cable adjustments. F - 4...
Page 65: Steering Systems
Steering Systems G - 1 GENERAL The tilt mechanism should not be adjust ed Four Winns ® boats are equipped with a rotary steering when the boat is moving. Sudden boat move- system. Tilt and power steering are avail able on the SL models.
Page 66: Propeller Torque
This condition is normal and can be corrected only by steerable, but with increased effort. Return the boat increasing engine RPM. Wind, water currents and play to your Four Winns dealer as soon as possible to in steering compo nents can cause equivalent effects. correct the power steering system.
Page 67 If at any time the steering system becomes stiff, has an excessive amount of free play or shows any change in its operating characteristics, contact your Four Winns dealer to have the system inspected. Steering Systems - Section G Owner’s Manual Page 64...
Page 68: Electrical Systems
GENERAL NOTICE Listed on the battery switch panel and helm All electrical equipment on the Four Winns SL models circuit breaker panel are various labels for the operates on 12 volts DC. The SL models come circuit breakers protecting different com- equipped with either a single or dual battery system ponents.
Page 69: Single Engine - Single Battery System
H - 2 SINGLE ENGINE – SINGLE BATTERY SYSTEM When disconnecting the cables from the On certain SL models, a single battery is provided as battery, make sure all switches are off standard equip ment (12 volt DC) per Section H-1. When and disconnect the black negative cable(s) first to prevent spark.
Page 70: Volt Electrical Equipment
START” posi tion only when a single battery is not capable of start ing the engine. Ignition Circuit Breaker Four Winns recommends alternating between batteries during boating. Depending upon boat ing use, this may increase battery longevi ty. Use bat tery #1 for the first day of a cruise and switch to battery #2 on the second day.
Page 71 Blower - The BLOWER switch is used to activate the bilge blower. Toggle the switch to the “ON” position, activates the electric bilge blowers, changing the air in the engine compartment that may contain gas vapors. Gasoline vapors can explode resulting in injury or death.
Page 72 See Figure H13. Please also includes additional speak ers in stalled in the see your Four Winns dealer regarding availability. transom. The switch permits one to conveniently turn the transom/tower speakers “ON” or “OFF” while at the transom.
Page 73: 12 Volt Electrical System Shutdown Procedures
Additionally, the SL models come equipped with a satellite stereo receiver. Please see your Four Winns To shutdown: dealer for information and activation. 1. Turn the battery switch (if applicable) to the “OFF”...
Page 74 The American Boat and Yacht Council (ABYC) has published a standard for the color coding of boat Batteries produce hydrogen and oxygen gases wiring. Four Winns voluntarily complies with these standards so a qualified service technician can install when being charged. These explosive gases escape through the vent/fill caps and may form new equipment or troubleshoot the electrical system.
Page 75: Stray Current Corrosion
If corrosion damage is found, deter- mine and correct the cause of stray current to prevent further damage. Consult an experienced marine electrician or contact your Four Winns dealer for assistance. The use of some shore power battery chargers while the boat is in the water and the battery is connected to the system can cause stray current corrosion.
Page 76: Gasoline Fuel Systems
An entry on the Four Winns® Pre- Delivery in a pro per con tain er. Inspection Form portion of the Warranty Registration Card will attest to the deal er’s perfor mance of this...
Page 77 Four Winns. E. Fuel Senders The fuel sender consists of a float which travels up and down a stationary tube. The float measures the level of the fuel in the tank and sends a signal to the fuel gauge.
Page 78: Fuel Standards
Be cautious when using gasoline that contains alcohol. The fuel system components on the plastic fuel tanks used by Four Winns® will withstand up to 10% alcohol content in the gasoline. Also refer to the section on gasoline require ments in your engine manual for additional information.
Page 79: Fueling Instructions
a. Ensure that boat is moored securely. B. Recommendations b. Be sure the proper type and grade of fuel Assume blended gasoline is being used and follow as recommended by your Engine Owners these recommendations below. Manual is used. 1. Inspect fuel hoses often. A deterio rated hose c.
Page 80 5. After fueling: a. Replace all fill caps securely. b. Wipe up any spilled fuel. c. Determine that there is no odor of gaso line in the engine compartment or below decks before starting machinery, turning on lights or lighting stove. Oper ate the bilge blower sys- tem for at least four (4) minutes before engine start-up.
Page 81 For information concerning fresh water tank capaci- ties, please visit our website at www.fourwinns.com or contact your Four Winns dealer. The materials from which the compo nents of the water system are made may give the water supply a peculiar taste, especially when new.
Page 82: Fresh Water System
Inspect and correct the hose routing Transom (if neces sary). If a prob lem still exists, con tact Shower your Four Winns dealer for assis tance. NOTICE DO NOT operate the pump with an empty tank. Damage to the water pump may result.
Page 83 The fresh water pump supplies water to the aft shower Porta-Potti and when installed the cockpit faucet. The pump is Preparation: generally located in the vicinity of the fresh water tank. Separate unit by sliding the locking lever to the left “unlocked”...
Page 84 NOTICE Before each use: With seat cover closed, open and close the holding tank valve (Figure J9) to vent any pressure that may have built up as a result of heat or altitude. This prevents upward splashing of bowl contents when toilet is flushed.
Page 85: System Maintenance
To pump out the holding tank: The decomposition of waste produces a color- 1. Connect the dockside pump out connection less, odorless gas, methane, that is lighter than to the WASTE plate located on the deck. air, combusti ble, and ex treme ly le thal. Always provide sufficient ventila tion when effecting NOTICE repairs to the waste sys tem and allow no odor...
Page 86 To winterize: 1. Turn on the water pump/faucet and drain the water tank. The water tanks on some models can be drained by removing the with drawal hose from the tank and allow ing water to drain into the bilge. NOTICE DO NOT run the water pump without water in the system.
Page 87 Figure J14: General Water System Diagram Waste & Water Systems - Section J Owner’s Manual Page 84...
Page 88: Ventilation And Drainage Systems
K - 2 HULL DRAINAGE SYSTEMS VENTILATION A. Transom Drain ® All Four Winns stern drive models are equipped A transom drain with plug is provided in the engine with engine compartment ventilation. This system is designed to meet or exceed the requirements (in compartment to allow water drainage.
Page 89 The water will drain into the bilge and be pumped overboard by the bilge pump. D. Bilge Compartment Drainage ® Certain bulkhead areas of Four Winns boats are sealed in accordance with U.S. Coast Guard regula- tions effective at the date of manufacture. Drainage is provided and water can be removed with the bilge pump.
Page 90: Interior Equipment
Figure L2: Port Helm Glovebox L - 5 STEREO Four Winns offers a AM/FM/CD stereo as standard equipment on the SL models. The AM/FM/CD stereo is mounted on the helm. See Figure L5. The face plate opens to access the CD slot.
Page 91: Anchor Locker W/Hidden Ladder
L - 7 ANCHOR LOCKER w/HIDDEN LADDER The SL models have an anchor locker built into the bow. A hidden telescoping ladder is also located inside the anchor locker for boarding at the bow. To access the anchor locker simply lift the anchor lid using the pull handle.
Page 92: Aft Deck Storage
To stow the ladder, retract the ladder and rotate the ladder into the anchor locker. On certain models, the ladder will not completely rotate into the locker unless pressing down on the ladder to release the safety mechanism. The anchor locker has an overboard drain to remove any water that might otherwise accumulate.
Page 93 12VDC Receptacle MP3 Player Port Table Angled Leg Mount Figure L15: Cockpit Table Figure L13: Small Electronic Storage (Helm) L - 11 COCKPIT HEATER OPTION For watersports enthusiasts an optional cockpit heater is available. When the activity is done you can warm up quickly with heat.
Page 94: Exterior Equipment
The stainless steel transom ski tow is mounted on the transom above the swim platform. Four Winns A pull-up style cleat is standard on SL models. The recommends no more than two skiers be pulled pull-up cleat gives your boat a more sleek style.
Page 95 See Figure M4. Please see your Center Port W/S S.S. Stbd W/S Walk-Thru Four Winns Dealer for further information. Corner Supports Corner Catch W/S Door Figure M5: Windshield Figure M4: Bow Scuff Plate E.
Page 96: Swim Platform W/Ladder
M - 3 SWIM PLATFORM w/LADDER Never approach or use ladder when the motor Four Winns provides an extended swim platform on is running. Severe injury or death will result the SL models. See Figure M6. The integrated swim from contact with rotating propeller.
Page 97: Docking Lights
Good seaman- becomes easier during periods of reduced visibility. ship demands that you operate your boat Please see your Four Winns dealer for information quietly so as not to infringe on the rights of and availability. See Figure M9.
Page 98: Transom Door
Please contact your and ski devices only. Do not tow more than Four Winns dealer for further details. two persons at a time from this arch. Do not use arch for lifting, parasailing or towing other Flexiteek watercraft.
Page 99 (i.e. grill). The rail may also be removed from the mounts and stored. See Figures M15 - M18. Please see your Four Winns dealer for further details. Exterior Equipment - Section M Owner’s Manual Page 96...
Page 100 Figure M17: Tube Holder Figure M18: Grill Exterior Equipment - Section M Owner’s Manual Page 97...
Page 101 Upholstery N - 1 SEATING A. Bow Seating Bow seating is provid ed on the SL models. Certain bow cushions have hinges to allow for access to storage areas be low. Sidewall storage is also stan- dard. See Figures N1, N2 & N3. Figure N4: Port Passenger’s Chair Backrest (Rotates Forward to Create Passenger’s Lounge) Figure N1: Bow Seating...
Page 102 Please contact your Four Winns dealer regarding inquiries about this option. Walk-Thru Door (Slides down into position)
Page 103 2. Slide the seat completely forward or rearward (as needed to clear coaming/side pad or seat cushion) by using the adjustment lever located either on the Gas-Assist Lifts right or left side of the seat depending upon which seat is being adjusted. See Figure N9. 3.
Page 104 Always use the engine hatch’s prop rod when working on the engine. This provides added safety while helping to prolong the life of the screw jack and engine hatch. NOTICE Never operate or trailer your boat with the engine hatch in its open position. Doing so could result in damage to the engine hatch, hardware, and/or loss of cushions.
Page 105 Prevent falls overboard. Secure the walk-thru backrest and fill-in cushion and stay inside cockpit while underway. Port Sidewall Storage To prevent personal injury, swim platform must not be occupied and the walk-thru backrest and fill-in cushion must be in place while engines are running.
Page 106 On certain SL models the swim platform lounge is created by extending the swim platform seat. The seat can be lifted up and pulled back in the direction of the stern to create the swim platform lounge. See Figure N19. Figure N16: Watersports Chair &...
Page 107: Exterior Upholstery Care
Falling overboard can cause serious injury or death. Do not sit in platform lounging seats when engine is running. N - 2 EXTERIOR UPHOLSTERY CARE A. Cleaning Vinyl NOTICE Vinyl upholstery should be cleaned and Figure N20: Swim Platform Port Seat maintained in accordance with the manufactur- er’s recommendations and instructions.
Page 108 • Hemisphere Ink Remover ® 5. Tough Mildew Stains: (for ordering information call 800-247-9901) Apply a mixture of one (1) teaspoon am monia, • Vinyl Finish Vinyl Cleaner one-fourth (1/4) cup of hydrogen peroxide, and ® (everyday cleaning & care, call 800-247-9901) three-fourths (3/4) cup of distilled water;...
Page 109 Regular vacuuming and occasional sham- pooing will help it stay attractive and serviceable. Four Winns offers a variety of optional weather covers for protection of the boat and associated equipment. D. Stain Removal Testing Continued exposure can damage the upholstery and seating.
Page 110: Replacement Upholstery
E. Stain Removal Procedures Regular maintenance such as vacuuming, hosing i t o or washing should be performed. Most stains and i t o mildew are easily removed from carpet made with Olefin fiber using common household cleaners. Refer to Table I. Olefin™ fiber is so resistant to chemi cal attack that Clorox™...
Page 111: Weather Covers
Four Winns utilizes acrylic-type material for all its covers. All canvas except mooring covers consist Four Winns is utilizing snaps for the canvas. The snap of 100% acrylic material and is color matched to the sockets are a standard type. When snapping covers boat.
Page 112 Figure O2: Bimini Top Booted throttle operation of boat while having canvas (Custom Bimini Top w/SST Arch Option Shown) deployed. Four Winns recommends booting the canvas before running at or close to maxi- You may choose to run your SL with the bimini top mum speed.
Page 113 C. Camper Canvas (Optional) B. Optional SST Arch w/Custom Bimini Top If you selected the optional stainless steel arch it The camper canvas is an option available on the certain SL models which encloses the cockpit area comes with a custom bimini top. The deployment of the bimini top is similar to the bimini top discussed and allows for overhead space.
Page 114 3. Zip forward windshield connector section to the 7. Partially zip the aft side curtains to the bimini top and bimini side curtains (approximately 6”). Snap bimini top. the edge portion of these curtains to the deck. It 4. Partially zip in the bimini side curtains to the bimini may prove easiest to start snapping the curtains top (approximately 6”).
Page 115 This camper is designed as temporary shel- term storage cover. Contact your Four Winns dealer ter only. It should not be left up unattended for any extended length of time. Violent for further details.
Page 116 Mooring Cover (Optional) NOTICE The front center snap of the cockpit cover An optional mooring cover is available. These covers should be centered on the center windshield are intended for longer term storage and spread over snap on the windshield track. The front center the entire boat.
Page 117: Winter Storage
The boat must be properly protected during winter dry dock storage. A winter storage cover is advisable. Many marine dealers offer shrink-wrap enclosures for outdoor storage. See a Four Winns dealer for informa- tion on the availability of winter storage covers or other alternatives for storage.
Page 118 Re-rinse. If leakage continues, apply a coat of silicone air drying water repellent, such as Scotchguard ™ . See your Four Winns dealer for addition al informa tion on weather covers. Weather Covers - Section O Owner’s Manual Page 115...
Page 119: Fiberglass And Hull
For freshwater use, the boat should be washed thickness. By these procedures Four Winns ensures once or twice a month. When using in a salt water proper com position.
Page 120 Make sure prod uct is formulated for gel coat surfaces. Blistering refers to a condition in which the unpro- Also, consult a Four Winns dealer for their recom- tected gel coat surface below the waterline has mendations. absorbed water and formed bubbles. See Sec tion P5 for additional information.
Page 121: Fiberglass Repairs
If this does wax or compound, and can stain the surface. not work, consult your Four Winns dealer for profes- sional assistance. 2. Use clean pads or cloths to apply a thin coat ing...
Page 122 Your Four Winns dealer or local ship store will have should be primed and painted in accor dance with informa tion on barrier coat prod ucts.
Page 123: Anti-Fouling Paint
When at tem pting to raise the hull, nev er allow one end of the boat to rise first, while let ting Four Winns has found the antifouling paints used to provide good marine growth protec tion in most water,...
Page 124: Woodwork And Composites
Woodwork and Composites Q - 1 HIGH-PRESSURE To clean star board, use a solvent-free, nonabrasive cleaner such as dishwashing soap or Fantastic™. LAMINATE CARE Read the la bel before using any clean ing product. Some table tops, counter tops, cabinets, shelving NOTICE and drawer faces consist of a high pressure laminate material.
Page 125: Acrylic Plastic - (Plexiglass)
Flexiteek can be cleaned with mild dishwashing detergent. Please 2. Using your bare hand, along with plenty of water, contact your Four Winns dealer for further details. feel and remove any dried-on dirt or mud. Flexiteek 3.
Page 126: General Maintenance
General Maintenance 3. Lower boat onto cradle properly or place boat on R - 1 WINTERIZATION trailer (if applicable). Be sure boat is ade quately support ed. The boat should be raised slightly A. Prior to Lifting for Winter Lay-up under the forward supports or trailer tongue to 1.
Page 127 C. Prior to Winter Storage 1. Remove as many cushions as possible. Re move storage lids or hatches. Open as many locker doors, as possible. Open the refrigerator door. Leave these areas open to improve ventilation. 2. Spray the weather covers and the boat uphol stery with Lysol Spray Disinfectant™.
Page 128: General Maintenance Schedule
R - 3 GENERAL MAINTENANCE SCHEDULE * Or as Required General Maintenance - Section R Owner’s Manual Page 125...
Page 129 l i t g l i o i t l l u n i t i v r l i b y t i g i t c i t o i t l (if applicable) e (if applicable) h t i i t n h t i * Or as Required...
Page 130 i r u i a r , s l , s t ) . c l l u l l A s r i i t n i l u & e t i t i p Clean Plexiglass Components * Or as Required General Maintenance - Section R Owner’s Manual Page 127...
Page 131: Trailer Information
The trailer must properly “match” the boat’s weight safety chains, etc., will vary from state to state. and hull design. Four Winns® SL trailers are de- Please contact the motor vehicle depart ment in your signed specifically for the SL models only. Please state for additional information.
Page 132: Trailer Components
Sec tion S-3 Opera tion for additional informa tion on the dealer check the tongue weight before trailering. hitch es. Also, consult your Four Winns dealer for his recom men da tion before purchasing a trailer hitch for your towing vehicle.
Page 133 When extending tongue ensure that the cou pler. Re place ment parts may be ordered brake line and wire harness are not pinched. through a Four Winns dealer. Failure to check could result in damage. The trailer tongue is hinged or removable on our 2.
Page 134 Always remember to swivel jack to the horizontal position before towing the trailer. Damage to the caster and jack may result. Ball Socket The swivel jack provided on the Four Winns ® trailer can be removed from the trailer to allow for main te- nance or repairs.
Page 135 NEUTRAL position. The winch handle may spin when pulling on the winch line. The tires installed on Four Winns® trailers meet the trailer load requirements for each model. Before trailering, make sure the tires are inflated according to the man...
Page 136 Check with your local auto er of the tires on your trailer is Carlisle Tire. Please call 1-800-260-7959 regarding any parts store or ask your Four Winns dealer for assistance. warrant concerns relating to your tires. Consult your dealer for state trailer regulations G.
Page 137 3. Open (to approximately 110°) and close handles bow stop. A bow tie-down is provid ed with the to ratchet. Leave in closed position to main tain ® Four Winns trailer. pressure on strap. 2. Rear Tie-downs: It is very important that the tran-...
Page 138 3. Lower trailer tongue until ball is seated or rests in ball socket. Ensure the ball latch is in the correct position to retain the hitch ball. 4. Close coupler latch by pushing latch down until latch engages properly. The coupler latch should close and secure freely with finger pressure when ball is properly seated in the ball sock et.
Page 139 11. Check for proper tow vehicle-trailer hookup. back suddenly. The tow vehicle and trailer should be level with a positive tongue load. Four Winns® trailers are designed with tongue weights between 5% and 10% of the total weight of the boat, fuel, gear The break-away system is not designed to and trailer.
Page 140 Insert a 5” x 7/16” bolt or screwdriver into the reverse lockout position hole (upper hole on side of actua- ture supplied with your Four Winns® trailer. tor). This will then block movement of the actuator. See Figure S16. Reverse lockout option must only...
Page 141 9. Carry a spare tire for both the trailer and towing cool otherwise loss of trailer brakes could vehicle. On extended trips, carry spare wheel result. Consult with your Four Winns dealer bearings, seals, and races. Be sure and carry regarding a “rugged duty towing package” for the proper tools to complete the repairs.
Page 142 Replace all worn and damaged parts. ALWAYS use the manufacturer’s replacement parts. Re place- H. Wheels ment parts may be ordered through your Four Winns dealer. Some maintenance is required to maintain the finish and retard rusting of painted rims. The wheels should...
Page 143: Brakes
1. Remove oil filling plug from Turbo Lube cap. Add If the brakes need bleeding, consult your Four Winns oil into the Turbo Lube hub. See Figure S18. dealer for assistance. If unavail able, a brake or auto repair facility can perform the repair.
Page 144: Axle Inspection & Repairs
C. Hub Reinstallation The following instructions pertain only to trailers manufactured by Four Winns. To remove the hub to 1. To reinstall hub, reverse the procedures listed inspect the bearings and seals, refer to Figure S19 and the following instructions: above.
Page 145 b. Tighten initially to 15 - 20 ft. lbs. (Apply 20 pounds of pressure to wrench 12” long) using cross tightening se quence. Proceed to finish tightening to 85 ft. lbs. (Applying 85 pounds of pressure to wrench 12” long will yield 85 ft. lbs.
Page 146: Pre-Launch And Underway
Pre-launch and Underway S - 1 LAUNCH AND CRUISE CHECKLIST  Get a current weather report. If the weather will not be favorable, postpone your trip.  If your boat has been out of the water, check to see that all bilge water has drained out. ...
Page 147 S - 2 FUELING C. Pumping Fuel Do not smoke; extinguish all open flames, Follow engine manufacturer’s recommenda- tions for types of fuel and oil. Use of improper STOP all engines and other devices that could products can damage the engine and void the cause sparks, including the bilge blower.
Page 148: Loading Passengers And Gear
gear aboard. Secure all gear firmly so it doesn’t move S - 3 LOADING PASSENGERS or interfere with operation of the boat. Passengers AND GEAR should board the boat one-at-a-time and be seated. Passengers should remain seated during loading of NOTE: All boats under 20 feet in length must have the boat to maintain an even trim.
Page 149: Starting Procedures
3. Activate the bilge blower. Check the blower output. MPORTANT: The presence of the capacity plate does not relieve the boat operator from the responsibility of using common sense or sound judgment. Turbulent waters and adverse weather conditions will reduce the Gasoline vapors can explode resulting injury maximum load capacity rating of the boat.
Page 150 When all your pre-departure checks have been Once the boat has slowed and motor is idling, place the shift in REVERSE. Gradually increasing reverse completed and the engine has warmed up, you will be ready to leave the dock. Take into account the amount power with the throttle will allow you to stop the boat in of wind, tide current, and other forces that may affect a very short distance.
Page 151: Trimming Your Boat
attitude with continued acceleration. This maximum At this point your boat will be plowing through the wa- angle is known as the “hump”. Because visibility, ter with the bow down too far. Trim the lower unit up slightly until the bow comes up. If you trim the lower handling, and performance are reduced, it is advisable to get “over the hump”...
Page 152 Remember that most boats react very slowly to trim This configuration allows the engine to operate tabs. Often boat owners do not give trim tabs time to within the recommended rpm range with a heavy work. Press the trim tab switches for only one second load.
Page 153: Navigation Lights
S - 8 NAVIGATION LIGHTS The present and forecasted weather conditions are of primary consideration, but a threat of possible storms should always be a concern. Observance of the Although night activities are limited, cruising at night following information will help in your safety afloat if can be very pleasurable.
Page 154: Reacting To Emergencies
anchor. Listen for other fog signals while continu- • Watch for swimmers. Swimming areas may not ing to sound the proper fog horn or bell for a boat be marked. Steer clear from the area and always at anchor. remain alert. •...
Page 155 D. Man Overboard F. Fire Most fires are caused by electrical problems or care- Think through and follow these procedures if someone less fueling practices. A fire on board your boat is a in your boat falls overboard. serious emergency. You must work quickly to imple- •...
Page 156: Returning To Shore
the hydraulic fluid reservoir level. Most stern drives • Electrical appliances must be within rated amper- are power assisted and have their own hydraulic age of boat circuits. Observe the boat carefully reservoir and engine mounted drive pump; check the while the electrical system is being energized.
Page 157 ure S6. Each line has a specific purpose. The bow line If the weather looks bad, use spring-lines from the and the stern line secure your boat’s bow and stern. bow and stern to dock amidships of the boat. Tie The two spring lines keep your boat from moving up on the downwind side of the dock.
Page 158 Glossary ABAFT - Toward the rear of a boat. BILGE - The lowest interior area of a hull, used to collect water that has entered. ABEAM - At right angles to the keel of the boat. BILGE PUMP - A pump intended for removal of spray, ABOARD - On the boat.
Page 159 CAPSTAN - A machine that moves a cylindrical DEAD RECKONING - A plot of courses steered and device on a shaft for the purpose of hauling up an distances traveled through the water. anchor. DECK - A permanent covering over a compart ment, CAST OFF - To let go.
Page 160 EVEN KEEL - To be floating evenly without listing to FREEBOARD - The minimum vertical distance from the surface of the water to the gunwale. either side. FREQUENCY - The number of crests passing a fixed EXHAUST SYSTEM - The means by which the hot engine (or generator) exhaust gases are moved from point at a given time.
Page 161 HARDTOP - A permanent cover over the cabin or ISOTHERMS - Isotherms are lines that are similar to cockpit. Isobars except that Isotherms connect all the points that are of equal temperature. HAWSER - A heavy rope or cable used for moor ing JETSAM - Refuse that sinks when discharged or towing.
Page 162 MODEL DESIGNATOR - Model identifier or model POINT - One of 32 points of the compass that is equal name. to 11-1/4 degrees. MOORING - An arrangement for securing a boat PORT - 1. Looking forward, the left side of a boat, to a mooring buoy or pier.
Page 163 SHACKLE - A “U” shaped connector with a pin STRUT - A propeller shaft support that is below or bolt across the open end. the hull. SHAFT - The long, round member that connects SUMP - A pit or well into which water is drained. the engine or transmission to the propeller.
Page 164 WATER LINE - The line of the water on the hull when the vessel is afloat. WATCH - A 4 hour duty period while at sea. WAVES - Waves are periodic disturbances of the sea’s surface, caused by wind, seaquakes, and the gravitational pull of the moon and the sun.
Page 165: Float Plan
Name ________________________________________________ Telephone ______________________________ Description of Boat __________________________ Type _________ Color ____________ Trim ____________ Registration Number ___________________________________________________________________________ Length ___________________ Name __________________________ Make ____________________________ Hull Identification Number ___________________________________________________ ® Four Winns Other Information _____________________________________________________________________________ Persons Aboard: Name Address Telephone _____________________________________________________________________________________________ _____________________________________________________________________________________________...
Page 166: Fuel Log
Fuel Log Fuel Log Owner’s Manual Page 163...
Page 167 Fuel Log Fuel Log Owner’s Manual Page 164...
Page 168 Fuel Log Fuel Log Owner’s Manual Page 165...
Page 169: Service Log
Service Log Service Log Owner’s Manual Page 166...
Page 170 Service Log Service Log Owner’s Manual Page 167...
Page 171 Service Log Service Log Owner’s Manual Page 168...
Page 172: Service Information
Service Information & & Service Information Owner’s Manual Page 169...
Page 173 SL Locator Drawing (Note: Representative Location Only - availability and locations of equipment may vary depending on model and/or optional equipment installed. Locations and availability is subject to change without notice). Locator Drawing Owner’s Manual Page 170...
Page 175 ® ®...

Four winns SL Series Owner's Manual

Quick Links

Related Manuals for Four winns SL Series

Summary of Contents for Four winns SL Series

Table of Contents
