- Page 1 SEASIDE TV DCT 5000 Wiring Instructions Additional Information Digital Cable Box USER MANUAL...
- Page 2 REPAIRS If you nd the unit in need of repair, contact your cable system operator for repair or CAUTION replacement. RISK OF ELECTRIC SHOCK NOTE TO CATV SYSTEM INSTALLER This reminder is provided to call the CATV system installer’s attention to Article 820-40 of CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
- Page 3 IMPORTANT SAFEGUARDS Read instructions Accessories Ground or polarization All the safety and operating instructions should Do not place this product on an unstable cart, This equipment may be equipped with a polarized be read before the appliance is operated. stand, tripod, bracket, or table. The product may alternating-current line plug (a plug having one blade wider than the other).
- Page 4 Lightning Damage requiring service Safety check For added protection for this equipment during Unplug this equipment from the wall outlet and Upon completion of any service or repairs to this a lightning storm, or when it is left unattended refer servicing to quali ed service personnel under video product, ask the service technician to and unused for long periods of time, unplug it the following conditions:...
-
Page 5: Table Of Contents
CON TENTS Introduction..........2 Audio/Video Connections......14 Front Panel................3 RF Bypass Switch.............15 Rear Panel ................4 Data Features ..........18 Recording Your Connections ...... 7 Data Device Connection ......19 Remote Control ..........8 Troubleshooting.........20 Installing Batteries ............12 Basic Operation ........... 13 Turning Power On and Off.......... 13 Changing Channels............ -
Page 6: Introduction
INTRODUCTION This handbook will introduce you to the basic features of the DCT 5000 and provide several options for integrating it into your current entertainment system. -
Page 7: Front Panel
INTRODUCTION Front Panel The DCT 5000 front panel has 12 keys and an LED display. Use the keys to perform basic functions such as access the electronic program guide, navigate menus, and purchase pay-per-view events. The LED can display the currently selected channel or time of day, depending on your default setting in the electronic program guide. -
Page 8: Rear Panel
INTRODUCTION Rear Panel The DCT 5000 was designed to connect to more than a standard TV. The NOTE rear panel consists of two types of interfaces — audio/video and data. The The rear panel of your DCT 5000 may vary from this table following this drawing describes each connection and its potential use. - Page 9 INTRODUCTION Description TO TV/VCR This coaxial output connector, when operating on channel 3 or 4, is used to connect the DCT 5000 to a TV or VCR. CABLE IN connector provides the incoming signal from your service provider. CABLE IN DATA HS For future use.
- Page 10 INTRODUCTION Description AUDIO OUT R The RCA phono-type connectors are used to deliver audio to a stereo receiver. AUDIO OUT L OUT VIDEO connector is used to deliver video to an external device such as a VCR or TV. OUT VIDEO TV PASS CARD For future use.
-
Page 11: Recording Your Connections
RECORDING YOUR CONNECTIONS CD p layer Before you begin using the DCT 5000, take a moment to look at the back 6V9D P panel and record the connections. You can use your drawing later if it becomes necessary to reconnect your system. -
Page 12: Remote Control
REMOTE CON TROL The DRC 400 provides basic control of the DCT 5000, TV, VCR, and auxiliary devices such as a second TV or VCR. For programming instructions refer to the instructions supplied by your service provider. NOTE The remote control you receive may differ from the Notice that many of the keys on the front panel share the same function as remote control pictured here. - Page 13 REMOTE CON TROL Use this information with a basic electronic program guide. If your program guide is different, refer to the remote control instructions. Description AUX, VCR, Selects a desired device to control. The selected mode will remain active until you press another key. CABLE, OR TV HELP Displays the help screen.
- Page 14 REMOTE CON TROL Description A THEME Functionality is determined from services offered by your service provider. B LIST C CANCEL NUMBER KEYS Use to directly select a channel. TV/VCR BYPASS Use to manually enable the RF bypass function. You must have a cable-ready TV for this function to operate. or A/B Controls the VCR.
- Page 15 Displays the channel number or time of day. There are four indicator lights on the LED screen: œ MSGS. — the DCT 5000 has received messages for you to read à œ ON — the DCT 5000 is powered on Ã...
-
Page 16: Installing Batteries
Slide the battery door closed until it snaps into place. Ã Point the remote control at the DCT 5000, press and then CABLE press . If the DCT 5000 does not turn on, check the orientation POWER of the batteries or replace with new batteries... -
Page 17: Basic Operation
MUTE For best audio quality, use the remote control to set the DCT 5000 to approximately ¾ of maximum volume level and then adjust the audio levels on the external devices. -
Page 18: Audio/Video Connections
Disconnect power from the DCT 5000 before moving it or changing à cable connections. œ Do not place anything on top of the DCT 5000, especially other à home video components. The DCT 5000 requires adequate ventilation and airflow during normal... -
Page 19: Rf Bypass Switch
AUDIO/VIDEO CONNE CTIONS RF Bypass Switch The DCT 5000 may be equipped with the optional RF Bypass switch. When the optional RF bypass switch is activated it routes the cable signal directly to a cable-ready TV, bypassing the DCT 5000. This configuration enables you to view clear analog programming on the direct cable signal should the DCT 5000 be powered off. - Page 20 AUDIO/VIDEO CONNE CTIONS CD player Use these configurations as aides when connecting the DCT 5000 into your 6V9D P home entertainment system. A u dio o u t Your entertainment system may not support all of these connections. A udio...
- Page 21 AUDIO/VIDEO CONNE CTIONS C D player This drawing illustrates an audio/video connection with the TV at the end of 6V9DP the chain. This connection requires two sets of RCA input connectors on A u d io o u t your stereo if you choose to view TV through the stereo system. A udio Your entertainment system may not support all of these connections.
-
Page 22: Data Features
DATA FEATURES The most powerful and exciting features of the DCT 5000 involve the data services supported by this system. The DCT 5000 provides high-speed data services to your TV, such as internet access, IP Telephony, E-Commerce, NOTE and home banking. In addition, the DCT 5000 will interface to external data Do not attempt to connect data devices without devices such as those indicated in the section, “Data Device Connection.”... -
Page 23: Data Device Connection
DATA DEVICE CONNECTION Do not attempt to connect data devices without Your DCT 5000 may be equipped with the interface connections illustrated contacting your service provider. Advanced depending on the services offered by your service provider. Contact your features require proper application and network service provider to determine the applications and functionality supported infrastructure to operate. -
Page 24: Troubleshooting
TROUBLESHOOTING Before calling your service provider, review the troubleshooting guide. This information is to help you quickly solve a problem. If your problem still exists, contact your service provider. Problem Cause Possible Solution 087( 087( No sound Accidentally pressed on the Press on the remote control to restore the volume level. - Page 25 “Installing Batteries.” not work Obstruction between remote and Ensure that nothing is on the DCT 5000 or blocking a clear line cable terminal. of sight between it and the remote control. Remote isn’t set in cable TV mode.
- Page 26 539-6250 Office and Studio: 1318 Grand Lake Road P.O. Box 4558, Reserve Mines, N.S. B1E 1L2...
