• Amplifier is in protection mode • Contact your local Harman Kardon service center, which you can due to internal problems locate by visiting our Web site at www.harmankardon.com No sound from surround or •...
Page 4
AMPLIFIER SECTION BIAS ADJUSTMENT Measurement condition . No input signal or volume position is minimum. Standard value. ± . Ideal current = 48mA ( ± . Ideal DC Voltage = 21.12mV ( CUP11517X (MAIN PCB) CN63 CN61 CN62 CN65 CN64 VR63 VR65 VR64...
PIN ASSIGNMENT (TOP VIEW) Top view No. 5606-3/13...
Page 11
BLOCK DIAGRAM VFD DRIVER IC PIN FUNCTION (LC75725E) : IC74 Pin No. Function Handling when unused 1, 13 Driver block power supply connection. (Both pins must be connected.) — — Logic block power supply connection. Provide a voltage between 4.5 and 5.5 V. —...
Page 12
AUDIO DSP (CS493263 - CLG : IC79) PIN No. Pin Name Function 1,12,23 +VD1 Digital Power supply. Normally +2.5v 2,13,24 DGND Digital Ground AUD3 SPDIF transmitter output/Digital audio output(N.C) Host write strobe pin(connected to GND with an external resistor) Host parallel output enable pin(pulled up with an external resistor) CS_DA SPI Serial data input pin CS_CK...
Page 18
A/D CONVERTER IC PIN FUNCTION (AK5380VT) : IC77 PIN/FUNCTION Pin Name Description AINR Rch Analog Input Pin AINL Lch Analog Input Pin NC Pin No internal bonding. VCOM Common Voltage Output Pin Normally connected to AGND with a 0.1µF ceramic capacitor in parallel with an electrolytic capacitor less than 2.2µF.
Page 19
n Block Diagram DZFL1 AK4356 Audio LOUT1+ DATT LOUT1- MCLK MCKO DZFR1 LRCK Controller LRCK ROUT1+ DATT BICK ROUT1- BICK DZFL2 LOUT2+ DATT Control LOUT2- CCLK Register DZFR2 CDTI ROUT2+ DATT ROUT2- DZFL3 LRCK LOUT3+ DATT LOUT3- BICK DZFR3 SDTI1 SDOUT1 ROUT3+ SDTI2...
Page 25
DIR IC PIN FUNCTION (AK4114VQ) : IC75 PIN/FUNCTION Pin Name Function IPS0 Input Channel Select 0 Pin in Parallel Mode Receiver Channel 4 Pin in Serial Mode (Internal biased pin) No Connect NC(AVSS) No internal bonding. This pin should be connected to AVSS. DIF0 Audio Data Interface Format 0 Pin in Parallel Mode Receiver Channel 5 Pin in Serial Mode (Internal biased pin)
Page 26
PIN/FUNCTION (Continued) Pin Name Function Power-Down Mode Pin When “L”, the AK4114 is powered-down and reset. Master Clock Operation Mode 0 Pin in Parallel Mode CDTO Control Data Output Pin in Serial Mode, IIC= “L”. CAD1 Chip Address 1 Pin in Serial Mode, IIC= “H”. Master Clock Operation Mode 1 Pin in Parallel Mode CDTI Control Data Input Pin in Serial Mode, IIC= “L”.
PIN ASSIGNMENT (74HCU04AFN : IC71,72 ) LOGIC SYMBOL (10) (11) (13) (12) TRUTH TABLE...
Page 30
DISASSEMBLY 1) REMOVAL OF TOP COVER 2) REMOVAL OF FRONT PANEL 3) PRINCIPAL PARTS LOACTION TUNER MODULE INPUT PCB TRANS FORMER MAIN PCB FRONT PCB...
