Swing-N-Slide PB 8274 Assembly Instructions Manual

Pb 8274 swing-n-slide play sets
Hide thumbs Also See for PB 8274:

Advertisement

Quick Links

Download this manual
Pb 8274
ASSEmbLY INSTRucTIONS
SLIDE SOLD
SEPARATELY
(NE4675L)
No. of children: Up to 10
min. use Zone: 29 ' x 29 '
Set Dim. 17 'L x 12 'W x 10'H
Est. building Time: 7-13 hrs.
ImPORTANT!!
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for. If you are missing
DO NOT RETuRN
anything, please
to the store where purchased. Please call our Customer
Service Department at the number below.
To register your product visit:
http://www.swing-n-slide.com
Other benefits include information on product warranties, assembly plan updates, joining our
mailing list for new products and promotions, receiving our newsletter, and providing feedback on
products.
Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
Visit our web site at: www.swing-n-slide.com or call us at
1-800-888-1232
