Swing-N-Slide PB 8274 Assembly Instructions Manual

Slide sold separately
Hide thumbs Also See for PB 8274:

Advertisement

Quick Links

LA 6314_Cumberland-OSB_- 11/21/11 9:08 AM Page 1
Pb 8274

ASSEmbLY INSTRucTIONS

SLIDE SOLD
SEPARATELY
(NE4675L)
No. of children: Up to 10
min. use Zone: 28 ' x 29 '
Set Dim. 16 'L x 12 'W x 10'H
Est. building Time: 7-13 hrs.
ImPORTANT!!
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for. If you are missing
DO NOT RETuRN
anything, please
to the store where purchased. Please call our Customer
Service Department at the number below.
To register your product visit:
http://www.swing-n-slide.com
Other benefits include information on product warranties, assembly plan updates, joining our mailing
list for new products and promotions, and providing feedback on products.
Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
Visit our web site at: www.swing-n-slide.com or call us at
1-800-888-1232

Advertisement

loading
Need help?

Need help?

Do you have a question about the PB 8274 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Swing-N-Slide PB 8274

  • Page 1: Assembly Instructions

    Other benefits include information on product warranties, assembly plan updates, joining our mailing list for new products and promotions, and providing feedback on products. Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232...
  • Page 2 LA 6314_Cumberland-OSB_- 11/21/11 9:08 AM Page 2 Safety Checklist for Swing-N-Slide Play Sets and ccessories Observing the following statements and warnings reduces the likelihood of serious or fatal injury Installation Safety – Have You: Consulted the assembly instructions supplied with your particular model? Noted this accessory is to be used only on Swing•N•Slide approved designs? (Do not alter its design or add/remove components.)
  • Page 3 Swing-N-Slide® will repair, or at its discretion, replace any part within the stated warranty period which is defective in workmanship or materials. This decision is subject to verification of the defect upon delivery of the defective part to Swing-N-Slide® at 1212 Barberry Drive, Janesville, Wisconsin, 53545.
  • Page 4 LA 6314_Cumberland-OSB_- 11/21/11 9:08 AM Page 4 TOOLS REQUIRE ELEcTRIc DRILL 1/2'' & 7/16" SOcKET & WRENcH HAmmER WRENcH TAPE mEASuRE SAFETY GLASSES & DuST mASK PHILLIPS bIT cARPENTER'S SQuARE 1/8" DRILL bIT (5) 1/2'' Pan Head (68) 2" Lag Screw (4) 3/4'' Pan Head Screws Screws...
  • Page 5 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 5 (8) Shelf-Loc (6) Wrap-Loc (2) 3X3 TO 4X4 (1) LH Split Beam bracket Shelf-Loc (1) RH Split Beam bracket (4) Step Brackets (4) Step Brackets (3) 13-7/8'' Ladder Rungs (Right) (Left) (6) 5-1/4'' Swing Hangers (3) 23-1/4'' Monkey Bar (2) EZ Frame Brackets (2) Boomerang Bracket...
  • Page 6 115 lbs. THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 2-10 YEARS For Home / Residential Use ONLY 1212 Barberry Drive Janesville, WI 53545 1-800-888-1232 www.swing-n-slide.com (8) Climbing Rocks (1) Name Plate (2) Play Handle with Hardware...
  • Page 7 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 7 ssembly Instructions Pb 8274 board List (1) 3’’ x 5-1/2’’ x 94’’ SWING BEAM (1) [PF 3489] 1/2’’ x 6’’ x 8-1/4’’ DORMER RH C (8) [PF 3998] 2’’ x 3’’ x 78’’...
  • Page 8 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 8 ssembly Instructions How to select the correct fastener Use these 2 pictorial guides to help select the correct fastener(s) for the lumber attachment you are making. Each diagram will highlight the correct number of fasteners to use, and where to attach them.
  • Page 9 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 9 ssembly Instructions Understanding how the Bracket System Works Example of a Shelf-Loc bracket connection. Shelf-Loc Bracket cORREcT! WRONG! brackets ''clipped'' Wrap-Loc brackets NOT interlocked! Example of a Shelf-Loc bracket connection. Look for ''TOP'' stamp on bracket for correct orientation.
  • Page 10 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 10 ssembly Instructions Look for ‘’TOP’’ stamp on brackets while installing. Busque la marca ‘’TOP’’ sobre las abrazaderas cuando realice la instalación. Fig. 1 DO NOT uSE LAG ScREWS HERE Fig. 1a Use Lag Screws Only Where Brackets Attach (18) 2-1/2'' Wood...
  • Page 11 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 11 ssembly Instructions Tip: Flex brackets to make installation of 2'' x 4'' easier Fig. 2 FLuSH 2-1/2'' Wood Approx. 1/4'' Screws per joint 1-1/4'' Lag 2-1/2'' Wood Screws 81'' per joint 2'' Lag NOTE: Upper screws are (2) 1-1/4'' Lag Screws, Lower screws are (3) 2'' Lag Screws.
  • Page 12 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 12 ssembly Instructions Look for ‘’TOP’’ stamp on brackets while installing. Busque la marca ‘’TOP’’ sobre las abrazaderas cuando realice la instalación. DO NOT uSE LAG ScREWS HERE Fig. 3 Use Lag Screws Only Where Brackets Attach 2'' Lag screws per bracket...
  • Page 13 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 13 ssembly Instructions Tip: Flex brackets to Tip: Flex brackets to make installation of 2'' x 4'' easier make installation of 4'' x 4'' easier Fig. 4 Approx. 1/4'' Approx. 1/4'' 2-1/2'' Wood 2'' Lag Screws Screws 1-1/4'' Lag per bracket...
  • Page 14 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 14 ssembly Instructions Tip: Flex brackets to make installation of Fig. 5 2'' x 4'' easier 2-1/2'' Wood Screws per joint Approx. 1/4'' 1-1/4'' Lag 81'' 2-1/2'' Wood Screws 81'' per joint 2'' Lag Frame 2 NOTE: Upper screws are (2) 1-1/4'' Lag Screws, Lower screws are (3) 2'' Lag Screws.
  • Page 15 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 15 ssembly Instructions Tip: Flex brackets to make installation of 2'' x 4'' easier Fig. 6 2-1/2'' Wood Screws per joint Approx. 1/4'' 1-1/4'' Lag 2'' Lag (2) 1-1/4'' lag screws NOTE: Upper screws are (2) 1-1/4'' Lag Screws, (3) 2'' lag screws Lower screws are (3) 2'' Lag Screws.
  • Page 16 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 16 ssembly Instructions Fig. 7 Fig. 7a 3/4'' Offset 2-1/2'' Wood Screws per joint 2-1/2'' Wood Screws per joint 50-3/4'' 1-1/4'' Wood Screws uNDER DEcK VIEW Deck Supports: ttach (2) deck boards and under deck support board as shown in (Fig. 7). ttach under deck slide support board and barrier support board as shown in (Fig.
  • Page 17 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 17 ssembly Instructions Fig. 8 2-1/2'' Wood Screws per joint NOTE: There should be approximately a 1/2'' Gap between deck boards. Deck Boards: ttach deck boards, spaced evenly, as shown in (Fig. 8). 2-1/2'' Wood Screw...
  • Page 18 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 18 ssembly Instructions Fig. 9 3/8'' Hole Locations Swing Beam ssembly 1-1/2'' 1. Identify your 3'' x 5-1/2'' x 94'' Swing Beam by A-Frame locating the board with the holes pre-drilled. 6-1/2'' 2. For proper alignment of swings, only place Swing Hangers in 3/8’’...
  • Page 19 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 19 ssembly Instructions Hammer Fig. 10 3/8'' hole T-nut t-nut cORREcT! Bottom Beam Clamp (4) 1-1/4'' screws Use Screwdriver to aid in tightening Swing Hanger 1-1/4'' Wood Screw Swing Hanger ssembly 1. Tap T-nut into 3/8’’ hole as shown in Step 1. 2.
  • Page 20 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 20 ssembly Instructions Fig. 11 3-1/2'' FACE -Frame ssembly (8) 2-1/2’’ Wood Screws 1. Layout 3'' x 3-1/2’’s and 2'' x 4'' as shown in (Fig. 11). lign EZ Frame Bracket with face of 3'' x 3-1/2''s.
  • Page 21 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 21 ssembly Instructions Fig. 12 T-Nut 5/16'' Washer 2-1/2'' screws 5-1/2'' Hex Head Bolt 5-1/2'' Hex Head Bolt 2-1/2'' Wood Screw -Frame ssembly cont. lign EZ-Frame Bracket with Hex Head Bolts on Swing Beam as shown in (Fig. 12). ttach -Frame beam to Swing Beam using (2) Washers and (2) T-Nuts and (2) Wood Screws as shown in (Fig.
  • Page 22 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 22 ssembly Instructions Fig. 13 -Frame ssembly cont. 1. Position Split-Brackets on 4'' x 4'' x 47-1/2'' as shown in (Fig. 13). 2. With the help of others, lift -Frame and Swing Beam ssembly and center onto unit as shown in (Fig.
  • Page 23 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 23 ssembly Instructions Fig. 14 NOTE: There should be approximately a 1-1/2'' Gap between barrier boards. Fig. 14a Use 2-1/2'' screws to 2-1/2'' Wood secure to 1'' x 4'' to 4'' x 4'' Screws per joint 3/4'' OFFSET 1-1/4'' Wood...
  • Page 24 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 24 ssembly Instructions Fig. 15 NOTE: There should be approximately a 1'' Gap between barrier boards. (5) [PF 3471] 1'' x 4'' x 33'' 1-1/4'' Wood Screws per joint Fig. 15a [PF 3482] 1'' x 4'' x 8-5/8'' Window Top (Flush With Barrier Boards)
  • Page 25 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 25 ssembly Instructions Fig. 16 2-1/2'' Wood Screws Fig. 16a 3/4'' Pan Head Screw Barrier Supports ttach Barrier Board as shown in (Fig. 16). ttach ‘L’ Bracket as shown in (Fig. 16a). 3/4'' Pan Head Screw 2-1/2'' Wood Screw...
  • Page 26 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 26 ssembly Instructions Fig. 17a Fig. 17b Fig. 17 2-1/2'' 2-1/2'' Wood 12'' Screws per joint 13-7/8'' (2) [PF 3474] 1'' x 4'' x 15-1/2'' Rung 12'' 1-1/4'' Lag Screws per Rung 1-1/2'' Wood Screws 12-1/2'' Body of Rung Must...
  • Page 27 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 27 ssembly Instructions Fig. 18 Fig. 18a 1-1/4'' Lag Screws [PF 3933] 2'' x 4'' x 36'' FLUSH per bracket 1-1/4'' Lag Screws per bracket 23-1/4'' Monkey 23-1/4'' Bars FLUSH FLUSH [PF 3933] 2'' x 4'' x 36'' 10-1/4'' AL RAS Fig.
  • Page 28 LA 6314_Cumberland-OSB_- 11/21/11 9:09 AM Page 28 ssembly Instructions Fig. 19a 3'' OFFSET Fig. 19 1-1/4'' Lag screws per bracket 1-1/4'' Lag Screws per bracket FLUSH FLUSH Pre-Drill Fig. 19b FLUSH 77-5/8" 14" 16" 51" 3" 24-3/4" 8" Diameter 1-1/4'' Lag screw Monkey Bar ssembly Cont.
  • Page 29 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 29 ssembly Instructions Fig. 20 Fig. 20b Fig. 20c Fig. 20a Ring ttachment ttach (4) Quick Links to (4) Eye Straps oriented as shown in (Fig. 20) and (Fig. 20a). ttach (2) Iron Man Rings and (2) Iron Man Triangle to Quick Links as shown in (Fig. 20b). 3.
  • Page 30 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 30 ssembly Instructions Fig. 21 Fig. 21a FLUSH (16) [PF 3528] 1'' x 4'' x 24'' Note: Holes for climbing rocks should be centered on horizontal boards. 20" 3" 1" Rock Wall ssembly 1. ssemble Rock Wall as shown in (Fig. 21). 2-1/2'' Wood Screw 2.
  • Page 31 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 31 ssembly Instructions Fig. 22 Fig. 22a 17" 2-1/2'' Wood Screws per joint 2-1/2'' Wood Screws per joint Fig. 22b 2-1/2'' Wood Screw uNDER DEcK VIEW Rock Wall ttach ttach Rock Wall Support Board as shown in (Fig. 22). ttach Rock Wall to tower as shown in (Fig.
  • Page 32 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 32 ssembly Instructions Fig. 23 FLUSH 1-1/4'' screws Use Guides On Plate To Align Triangle Brace 46" 2-1/2'' screws Fig. 23a per joint Note: Make certain top surface is flush with A- Frame point. 2-1/2'' Wood Screw 1-1/4'' Wood Screw Roof Support...
  • Page 33 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 33 ssembly Instructions Fig. 24 1-1/2'' Wood Screws per joint Fig. 24a Fig. 24b 1-1/4'' Wood Screw 1-1/2'' Wood Screw Roof ssembly. ttach (4) Roof Slat as shown in (Fig. 24). Note: Start at the top of the roof and work down. ttach remaining Roof Slats as shown in (Fig.
  • Page 34 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 34 ssembly Instructions Fig. 25 Fig. 25a Note: Attach second Cleat with identical measurements as the first. 1-1/4'' Wood Screws 1-1/4'' Wood along bottom Screws per board Fig.25b 1-1/4'' Wood Screw [PF 3491] 1/2'' x 6'' x 15'' [PF 3492] 1/2'' x 6'' x 11-1/2'' ttach Dormer [PF 3493] 1/2'' x 6'' x 8-1/4''...
  • Page 35 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 35 ssembly Instructions Fig. 26 1/2'' Pan Head screws 3/8'' 2-1/2'' Wood Screws per board 3/4'' 1/2'' Pan Head screw Fig. 26a ttach Window and Roof ttach Dormer Window Frame as shown in (Fig. 26). 2.
  • Page 36 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 36 ssembly Instructions Fig. 27 1'' Truss Screw included with slide SLIDE SOLD SEPARATELY Fig. 27a 1-1/4'' Wood Screws per joint Surfacing Material 2'' Above Grade 2'' Below SLIDE STAKE Grade [PF 3419] 2'' x 4'' x 17-1/4'' 1-1/4'' Wood Screw Slide Installation.
  • Page 37 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 37 ssembly Instructions Fig. 28 (2) [PF 3483] 1'' x 4'' x 15-1/4'' Shutter 1-1/4'' Wood Screws per board [PF 3484] 1'' x 2'' x 10'' Window Sill 1-1/4'' Wood Screw Install Shutters and Window Sill 1.
  • Page 38: Name Plate

    LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 38 ssembly Instructions Name Plate Fig. 29 1/2'' Pan Head Screw THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 2-10 YEARS ID T G: For Home / Residential Use ONLY 1. Secure your product ID tag onto easy to read location of any post using (2) 1/2'' Pan Head Screws as shown 1212 Barberry Drive Janesville, WI 53545...
  • Page 39 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 39 ssembly Instructions Swing Seats Fig. 31a Fig. 31 NEVER hang a swing seat by a partial link of chain! Remove and discard partial links. Fig. 31b Fig. 31c Swing Seat ssembly. 1. Hold the swing seat vertically and insert uncoated chains through the channels on the bottom of the swing seat. Note: coat hanger may be used to help pull chain through the swing seat.
  • Page 40 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 40 ssembly Instructions RingTrap Assembly Fig. 32b Fig. 32 Fig. 32a Fig. 32c Fig. 32d Ring-Trap ssembly: 1. ttach chains to Quick Links as shown in (Fig. 32). 2. ttach Quick Links to Ring-Trap as shown in (Fig. 32a). 3.
  • Page 41 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 41 ssembly Instructions...
  • Page 42 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 42 ssembly Instructions...
  • Page 43 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 43 ssembly Instructions...
  • Page 44 LA 6314_Cumberland-OSB_- 11/21/11 9:10 AM Page 44 Questions???... Call our Customer Service Department at 1-800-888-1232 © PlayCore Inc. 2012 Printed In USA LA 6314...
