SERVICE MANUAL
Dual Camera
Contents
1. OUTLINE OF CIRCUIT DESCRIPTION ............................... 3
2. DISASSEMBLY ................................................................... 10
3. ELECTRICAL ADJUSTMENT ............................................. 15
5. PARTS LIST ........................................................................ 22
RoHS
•This product does not contain any hazardous substances prohibited by the RoHS
Directive.
WARNING
•You are requested to use RoHS compliant parts for maintenance or repair.
•You are requested to use lead-free solder.
(This product has been manufactured using lead-free solder. Be sure to follow the
warning given on page 2 when carrying out repair work.)
CAUTION : Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
Discard used batteries according to the manufacturer's instructions.
NOTE : 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N. S. P. : Not available as service parts.
Design and specification are subject to change without notice.
SG41J/U, U2, U3, EX, EX2, EX3, GX, GX2, GX3, PX, PX2, PX3, TA, TA2, TA3 (R)
FILE NO.
VPC-CG88BK
VPC-CG88R
VPC-CG88GD
(Product Code : 168 285 01)
(Product Code : 168 285 05)
(Product Code : 168 285 09)
(U.S.A.) (Canada) (Taiwan)
(General) (South America)
VPC-CG88EXBK
VPC-CG88EXR
VPC-CG88EXGD
(Product Code : 168 285 02)
(Product Code : 168 285 06)
(Product Code : 168 285 10)
(Europe) (U.K.) (Russia)
(Middle East) (Africa)
(General) (Korea) (Taiwan)
VPC-CG88GXBK
VPC-CG88GXR
VPC-CG88GXGD
(Product Code : 168 285 03)
(Product Code : 168 285 07)
(Product Code : 168 285 11)
(China) (Hong Kong)
(General) (Korea)
VPC-CG88PXBK
VPC-CG88PXR
VPC-CG88PXGD
(Product Code : 168 285 04)
(Product Code : 168 285 08)
(Product Code : 168 285 12)
(General) (Korea) (Taiwan)
(South America)
VPC-CG88TABK
VPC-CG88TAR
VPC-CG88TAGD
(Product Code : 168 285 13)
(Product Code : 168 285 14)
(Product Code : 168 285 15)
(Southeast Asia) (Australia)
(General)
REFERENCE No. SM5310827

Advertisement

Table of Contents
loading

Related Manuals for Sanyo VPC-CG88BK

Summary of Contents for Sanyo VPC-CG88BK

  • Page 1: Table Of Contents

    FILE NO. SERVICE MANUAL VPC-CG88BK Dual Camera VPC-CG88R VPC-CG88GD (Product Code : 168 285 01) (Product Code : 168 285 05) (Product Code : 168 285 09) (U.S.A.) (Canada) (Taiwan) (General) (South America) VPC-CG88EXBK VPC-CG88EXR VPC-CG88EXGD (Product Code : 168 285 02)
  • Page 2 PRODUCT SAFETY NOTICE The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of special significance to product safety. Should any component designated by a symbol need to be replaced, use only the part designated in the Parts List.

  • Page 3: Outline Of Circuit Description

    1. OUTLINE OF CIRCUIT DESCRIPTION 1-1. CMOS CIRCUIT DESCRIPTION 1. IC Configuration The CMOS peripheral circuit block basically consists of the following ICs. IC911 (MT9F001I12STCV) CMOS imager CDS, AGC, ADC built-in H driver, V driver, serial communication circuit built-in 2. IC911 (CMOS) [Structure] The electric charges which are generated when each pixel is optically converted are in turn converted into signal voltages...
  • Page 4 1-2. CP1 and VF1 CIRCUIT DESCRIPTION 1. Circuit Description 2. Outline of Operation 1-1. Digital clamp When the shutter opens, the shutter signal is input and opera- The optical black section extracts averaged values from the tion starts. When the TG/SG drives the image sensor, picture subsequent data to make the black level of the sensor output data is converted internally into a small-amplitude actuating data uniform for each line.
  • Page 5 4. Lens drive block 4-1. Focus drive The 16-bit serial data signals (LENS_SDI) and (LENS_SCLK and LENS_EN) which are output from the ASIC (IC101) are used to drive (FOCUS A +, FOCUS A -, FOCUS B + and FO- CUS B -) by the motor driver IC (IC951), and are then used to microstep-drive the stepping motor for focusing operation.
  • Page 6 5. Power Sequencer Description For the overall configuration of the power sequenser, refer to the block diagram. This circuit block consists primarily of the power sequencer block inside the ASIC. The power sequencer have functions for receiving user operations which signify that the camera has been turned on and power ON/OFF function.
  • Page 7 6. Receiving user operations showing that the camera has been turned on When the battery is installed, the 3.2V power supply which is output from IC501 is constantly being input to the power sequencer of the ASIC, and it monitors user operations that generate a P-ON request (such as POWER key input and panel opening). 7.
  • Page 8 1-3. PWA POWER CIRCUIT DESCRIPTION 1. Outline 3. VAA 2.8 Power Output This is the main power circuit, and is comprised of the follow- VAA 2.8 (2.8 V) is output. Feedback for the VAA 2.8 is pro- ing blocks. vided to the switching controller (Pin (G3) of IC501) so that Switching controller (IC501) PWM control can be carried out.
  • Page 9 1-4. ST1 STROBE CIRCUIT DESCRIPTION 1. Charging Circuit 2. Light Emission Circuit When UNREG power is supplied to the charge circuit and the When FLCTL signal is input from the ASIC, the stroboscope CHG signal from microprocessor becomes High (3.3 V), the emits light.

  • Page 10: Disassembly

    2. DISASSEMBLY 2-1. REMOVAL OF CABINET LEFT, CABINET MIDDLE, CABINET FRONT, ST1 BOARD AND LENS When assembling, attachment order. 3, 15 NOTE: Discharge a strobe capacitor with the discharge jig (VJ8-0188) for electric shock prevention.
  • Page 11 1. LCD is opened. 48. Spacer CA1 CN 2. Screw 1.7 x 2 49. FPC 3. Cover battery is opened. 50. Spacer CP1 lens 4. Screw 1.7 x 3.5 51. FPC 5. Screw 1.7 x 5 52. Lens 6. Screw 1.7 x 5 53.
  • Page 12 2-2. REMOVAL OF CP1 BOARD 1. Holder lens 12. Button power 2. Spacer wire 13. Screw 1.7 x 2.5 3. Screw 1.7 x 3.5 14. Spacer SW unit 4. FPC 15. Unit, control 5. Connector 16. Spacer lens right 6. CP1 board 17.
  • Page 13 2-3. REMOVAL OF TB1 BOARD, LCD AND VF1 BOARD 1. Cover joint 15. Adhesive magnet 2. Two screws 1.7 x 3 16. Assy, cover LCD FR SV 3. Shield tape MIC 17. FPC 4. Assy, cover LCD back SV 18. LCD 5.
  • Page 14 2-4. BOARD LOCATION VF1 board ST1 board TB1 board CP1 board...

  • Page 15: Electrical Adjustment

    Download the calibration software and the firmware 1. System requirements from the following URL. Windows 2000 or XP or Vista http://www.overseas.sanyo.com/dcamera service/ IBM R -compatible PC with pentium processor Place the DscCalDi.exe file, camapi32.dll file and USB port QrCodeInfo.dll file together into a folder of your 40 MB RAM choice.
  • Page 16 3-6. The adjustment item which in necessary in part exchange CMOS Black CMOS Lens Lens Point And White Point Factory Adjust- Adjust- White Point Language storage Reset Defect Adjust- Cord Defect Detect Setting ment ment information Setting Detect Setting ment Adjustment registration (Infinity)
  • Page 17 2. Lens Adjustment (1m) Dsc Calibration Copy Infinity calibration : AF_TEMP_AD_I: 497 PZ_BR: 5 AF_BR: 4 AF_I_WIDE: -7 AF_I_MID1: -9 AF_I_MID2: -2 AF_I_TELE: 10 IRIS_GAIN: 83 IRIS_OFFSET: 151 Camera 0.5 cm Siemens star chart Preparation: POWER switch: ON Adjustment value determination is effectuated using below Adjustment condition: values.
  • Page 18 Adjustment value determination Dsc Calibration AF_TEMP_AD: ATAD ATAD: adjustment value of focus temperature A/D (250<=ATAD<=893) Copy AF_WIDE: ZW AWB Results: ZW: adjustment value of focus at zoom position wide (–60<=ZW<=35) WB=256,434,474 AF_MID1: ZM1 CHECK=128,127,124 WB_ND=254,438,485 ZM1: adjustment value of focus at zoom position middle1 CHECK_ND=128,128,124 (–90<=ZM1<=20) IR_TEMP_AD=444...
  • Page 19 s1>s2>s3>s4>s5>s6>s7>s8>s9>s10 3-9. Factory Code Setting 250<=itad<=893 1. Check the "Factory Code" display within the Setting group. Adjustment values other than the above are irrelevant. 2. For U.S.A., Canada and NTSC general area If "FC_SANYO_U" does not appear, click on the " "...
  • Page 20 3-13. Firmware uploading procedure 1. Uploading the firmware should be carried out if the version number (COMPL PWB XX-X) on the replacement circuit board is lower than the version of the distributed firmware. For XX-X, enter the name of the circuit board containing the firmware.

  • Page 21: Usb Storage Information Registration

    15.) 2. Double-click on the DscCalDi.exe. 3. Click on the Get button in the USB storage window and check the USB storage data. VID: SANYO PID: CG88 Serial: Rev. : 1.00 4.

  • Page 22: Parts List

    LOCATION PARTS NO. DESCRIPTION ACCESSORIES PACKING MATERIALS 645 102 5180 BATTERY,RECHARGE,LI-ION 636 138 7309 CARTON INNER-SG41J/EX, 645 102 1823 BATTERY CHARGER EXCEPT VPC-CG88BK,VPC-CG88R, 645 076 0235 CORD,POWER-1.5MK, VPC-CG88GD VPC-CG88EXBK,VPC-CG88EXR, 636 138 7293 CARTON INNER-SG41J/U,VPC-CG88BK, VPC-CG88EXGD,VPC-CG88TABK, VPC-CG88R,VPC-CG88GD VPC-CG88TAR,VPC-CG88TAGD 636 133 7373...
  • Page 24 LOCATION PARTS NO. DESCRIPTION CABINET & CHASSIS PARTS 1 636 138 8276 COVER BATTERY-SG41J/U, VPC-CG88BK,VPC-CG88EXBK,VPC-CG88GXBK, VPC-CG88PXBK,VPC-CG88TABK 636 138 7965 COVER BATTERY-SG41J/U2,VPC-CG88R, VPC-CG88EXR,VPC-CG88GXR,VPC-CG88PXR, VPC-CG88TAR 636 138 7972 COVER BATTERY-SG41J/U3,VPC-CG88GD, VPC-CG88EXGD,VPC-CG88GXGD, VPC-CG88PXGD,VPC-CG88TAGD 636 131 7733 SPACER COVER BATT-SG31B/J 636 106 8154 COVER BAT INNER-SG212/J...
  • Page 25 10 13 Cabinet 1 SG41J PARTS LIST 1...
  • Page 26 BUTTON POWER-SG315/J 636 126 5980 SPACER WIRE-SG315/J 636 122 5083 HOLDER JOINT-SG315/J 636 125 8289 LABEL CAUTION-SG217/U 636 122 4871 COVER JOINT BASE-SG315/J, VPC-CG88BK,VPC-CG88EXBK,VPC-CG88GXBK, VPC-CG88PXBK,VPC-CG88TABK 636 127 4159 COVER JOINT BASE-SG315/UB, VPC-CG88R,VPC-CG88EXR,VPC-CG88GXR, VPC-CG88PXR,VPC-CG88TAR 636 131 3285 COVER JOINT BASE-SG315EXC, VPC-CG88GD,VPC-CG88EXGD,...
  • Page 27 Cabinet 2 SG41J PARTS LIST 2...
  • Page 28 ELECTRICAL PARTS Note: 1. Materials of Capacitors and Resistors are abbreviated as follows ; Resistors Capacitors MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor AL-SOLID Aluminum Solid Capacitor NP-ELECT...
  • Page 29 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION C1051 303 338 0309 CERAMIC 0.1U K 10V C9004 303 381 8109 CERAMIC 1U K 6.3V C1052 303 338 0309 CERAMIC 0.1U K 10V C9006 403 473 7604 CERAMIC 10U M 6.3V C1053 303 338 0309 CERAMIC...
  • Page 30 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION R1031 301 224 9009 MT-GLAZE 10K JA 1/16W R9706 301 257 4101 MT-GLAZE 100K DC 1/16W R1032 301 224 9009 MT-GLAZE 10K JA 1/16W R9707 301 257 4101 MT-GLAZE 100K DC 1/16W R1034 301 224 9405 MT-GLAZE 1.0M JA 1/16W...
  • Page 31 LOCATION PARTS NO. DESCRIPTION COMPL PWB,ST-1 636 138 3349 (SEMICONDUCTOR) Q5402 406 021 5107 TR TIG032TS-S-TL-E (INTEGRATED CIRCUIT) IC541 409 701 3301 IC BD4221NUX (DIODES) D5402 407 265 1900 DIODE RE0208DA-TR-E D5403 407 267 2004 DIODE MA27D290G (TRANSFORMER) T5401 645 097 3864 TRANS,STEP UP (CAPACITORS) C5401...

  • Page 32: Circuit Diagrams & Printed Wiring Boards

    CIRCUIT DIAGRAMS & PRINTED WIRING BOARDS TABLE OF CONTENTS OVERALL WIRING & BLOCK DIAGRAMS Page OVERALL WIRING .............................C3 OVERALL CIRCUIT ............................C4 IMAGE SENSOR CIRCUIT ..........................C5 LENS CIRCUIT ..............................C5 MAIN CIRCUIT ..............................C6 STROBE CIRCUIT ............................C7 POWER CIRCUIT...............................C7 CIRCUIT DIAGRAMS CP1 BOARD (DMA) MAIN ..........................
  • Page 33 NOTES: 1. All resistance values in "OHMS" unless otherwise noted. (K=1,000 ; M=1,000,000) 2. All capacitance values in "µF" unless otherwise noted. p=pico farad ; n=nano farad ; µ ,u or U=micro farad 3. All inductance values in "µH" unless otherwise noted. µ...

  • Page 34: Overall Wiring & Block Diagrams

    OVERALL WIRING & BLOCK DIAGRAMS OVERALL WIRING MIC(R) MIC(L) CN912 CN901 SPEAKER VAA2.8 VAA2.8 VAA2.8 VAA2.8 AGND AGND WHITE AGND AGND JW178 JW177 JW176 BLACK JW651 TGVD TGVD ZHINGE JW175 RESET_N RESET_N ZHINGE JW652 SWITCH UNIT VDD_SLVS_TX VDD_SLVS_TX VDDIO VDDIO BLACK VDDIO VDDIO...

  • Page 35: Overall Circuit

    OVERALL CIRCUIT LENS UNIT STROBE UNIT CN141 SD CARD CN951 SOCKET CA1 BOARD CP1 BOARD TCA BLOCK ST1 BOARD IC971 IC951 PWA BLOCK IRIS LENS IC911 CONTROL DRIVER 32.768KHz 14M CMOS 12MHz IMAGE 48.00000MHz SENSOR POWER MANAGEMENT LCDCA, LCDAN (TO CN105) IC501 SWITCHING POWER CONTROL...

  • Page 36: Image Sensor Circuit

    IMAGE SENSOR CIRCUIT LENS CIRCUIT CP1 (CAA) CP1 (DMA) IC101 IC951 CMOS1.8 VDDIO VDDPLL VAA2.8 VAAPIX VDD_SLVS_TX LENS DRIVER CN951 SYSTEM ASIC 13,40,6,24,30 LENS_BLOCK MVCC12,MVCC34,MVCC5, BOOST5.3V ZOOM_PI_AC VDDAMP67,RNF7 VDD3 TO PWA TO PWA 26,23 ZOOM_PI RNF6,SENSE6 VDDIO VDDPLL VAAPIX VDD_SLVS_TX ZOOM_PI_E VDD_SLVS ZOOM_PI_E...

  • Page 37: Main Circuit

    MAIN CIRCUIT CMOS_SDA X1102 48.00000MHz CMOS_SCL ADCK,RESET_N,TGVD 27MHz CN901 IC111 BtoB BOARD CMOS_DATA,CLOCK LVDS 74.175824MHz CLOCK GEN BOARD BACKUP_BAT (TO PWA BLOCK) LCDCA, LCDAN (TCA BLOCK) (TO PWA BLOCK) SHUTTER+ HINGE IC951 LENS_SCLK,LENS_EN,LENS_SDI CN105 LCDEN,LCDCK,LCDSD LENS CLK12M BtoW LMCLK DRIVER STATE_F,STATE_Z LCDD[0:7] BOARD...

  • Page 38: Strobe Circuit

    STROBE CIRCUIT POWER CIRCUIT POCO CHARGING CIRCUIT BSRST CN542 CLKO CLK32K TO DMA C5401 T5401 D5402 TO DMA, TCA TO BATTERY I2C_SDA F5004 POWER FILTER OSCILLATION RECTIFIER C5412 I2C_SCL CN541 TO DMA BLOCK TRANSFORMER CIRCUIT IC501 5:17 BAT+ VOUT1 L5301 SWITCHING BOOST5.3V STEP UP...

  • Page 39: Circuit Diagrams

    CIRCUIT DIAGRAMS CP1 BOARD (DMA) MAIN VDD3 *IC121 D1-28500/SG41J-U M29W640GT60ZA6E QXXAGB077---N VOLTAGE: VIEW MODE, LCD ON *R1210 R1201 0;1/16Z 10;1/16J VDD1.8 ZCS0 ZFRD DA12 DQS3 ZDCS ZRAS ZCAS ONENAND_RESET ZDSWE ZFWR AL3.2V DQM3 R1005 A_VDD3 0;1/16Z DQ24 VDD3 VDD3 C1007 VDD1.8 VDD1.1 R1121...
  • Page 40 CP1 BOARD (DMA) MAIN [UPPER-LEFT] D1-28500/SG41J-U VOLTAGE: VIEW MODE, LCD ON AL3.2V R1005 A_VDD3 0;1/16Z VDD3 C1007 VDD1.8 VDD1.1 R1121 1.2K;1/16D C1063 0.1;B C1051 0.1;B C1057 0.1;B C1064 0.1;B C1052 0.1;B C1058 C1053 0.1;B VDD3 0.1;B C1066 0.1;B C1067 0.1;B ZMRST ZMRST XOUT...
  • Page 41 CP1 BOARD (DMA) MAIN [UPPER-RIGHT] VDD3 *IC121 M29W640GT60ZA6E QXXAGB077---N *R1210 R1201 0;1/16Z 10;1/16J ZCS0 VDD1.8 ZFRD DA12 R8 IO4 SA12 DQS3 R9 IO5 DQS3 R10 IO13 R11 DQ0 VSSd DQ10 ZDCS R12 NC VPPWP ZRAS T1 NC /RAS ZCAS DQ11 T2 SA2 /CAS ONENAND_RESET...
  • Page 42 LMCLK GPIOA[19] AVREFP LCDHD LCDHD GPIOA[20] AVREFM LCDVD LCDVD ONENAND_RESET R1004 GPIOA[21] 51;1/16D VDD3 ZCS0 VDD3 ZDSWE MREG MREG ZFRD ZDWE SYSTEM ASIC ZDCS AGND ZFWR ZDCS CP1 BOARD (DMA) MAIN [LOWER-LEFT] ZCAS MICL MICL ZCAS ZRAS MGNDL ZRAS MICR MICR DVREF1 MGNDR...
  • Page 43 AVREFP AVREFM R1004 VDD1.8 51;1/16D ZDSWE Q1401 ZDWE UP0431300 SYSTEM ASIC ZDCS ZDCS CP1 BOARD (DMA) MAIN [LOWER-RIGHT] ZCAS ZCAS ZRAS ZRAS SDDET VDD3 DVREF1 R1029 DVREF0 0;1/16Z SW3.2V DSRON VDD3 DQSB3 DQSB2 DQSB1 DQSB0 DQS3 DQS3 DQS2 DQS2 CN141 DQS1 DQS1 DQS0...

  • Page 44: Cp1 Board (Tca) Lens

    CP1 BOARD (TCA) LENS CN951 VDD3 VDD3 VDD3 ZOOM_A- ZOOM_A- BOOST5.3V ZOOM_B+ ZOOM_B+ TO PWA ZOOM_A+ ZOOM_A+ ZOOM_B- ZOOM_B- VDD3 R9507 6.8;1/10F DRIVE+ DRIVE+ R9506 DRIVE- 6.8;1/10F DRIVE- HALL_IN+ HALL_IN+ VDD3 HALL_OUT- HALL_OUT- FOCUS_A+ ZOOM_B- HALL_OUT+ HALL_OUT+ OUT1A OUT4B C9503 HALL_IN- HALL_IN- Q9701...

  • Page 45: Cp1 Board (Pwa) Power

    CP1 BOARD (PWA) POWER F5001 1608 L5001 UNREG UNREGSY 2.5A32V FBMH1608HL300 P1-28500/SG41J-U VOLTAGE: VIEW MODE, LCD ON (USE BATTERY) 1AV4L2WT2R1MG L5031 2.1;M VDD1.1 H=2.0 L5061 2.2;M VDD1.8 H=1.5 3.0X3.0 R5098 1AV4L2YH2R2MG 0;1/16Z 2125 CMOS1.8 10;B 6.3 C5031 BACKUP_BAT TO DMA 1AV4L26B5890G L5071 LCDAN...

  • Page 46: Cp1 Board (Caa) Sensor Power

    CP1 BOARD (CAA) SENSOR POWER CN901 VAA2.8 VAA2.8 VAA2.8 2125 10;B AGND C9016 AGND C2-28500/SG41J-U IC901 IC903 XC6221B082G TK70628HCL-G QXC6221B082GP QTK70628HC-GG VOUT VCONT CMOS1.8 VDDSLVS_TX PAON2 VDD3 PAON1 VDDPLL VOUT TGVD TGVD RESET_N TO DMA RESET_N C6002 1608 10;B VDD_SLVS_TX VDDSLVS_TX IC902 10;B...

  • Page 47: Ca1 Board Image Sensor

    CA1 BOARD IMAGE SENSOR C1-28500/SG41J-U VOLTAGE: VIEW MODE, LCD ON CN912 VAA2.8 VDDIO VAA2.8 R9132 AGND 0;1/16Z VAA2.8 AGND 1608 1608 VAAPIX 0;1/16Z R9149 R9148 0;1/16Z SDIP3 SLVS3P VDDPLL TGVD TGVD SDIN3 1608 SLVS3N RESET_N RESET_N SDIP2 SLVS2P FLASH SDIN2 SLVS2N SHUTTER SCKIP...

  • Page 48: St1 Board Strobe

    ST1 BOARD STROBE CN542 TO BATTERY S1-28500/SG41J-U CN541 VOLTAGE: STROBE AFTER CHARGE N.C. BAT+ BAT+ BAT+ STROBE UNIT BAT+ BAT+ BAT+ T5401 BAT+ TTRN-0530H-018-T AWG30 1AV4L17B0620G JW541 BAT+ BAT+ BROWN F5004 BAT+ D5402 2.0X1.25 RE0208DA 2A32V BAT+ F47K2R0C3LFND LITTELFUSE BAT+ JW543 AWG30 BAT+...

  • Page 49: Tb1 Board Hinge

    TB1 BOARD HINGE CIRCUIT WAVEFORMS TEST POINT TEST POINT TEST POINT WAVEFORM WAVEFORM WAVEFORM LOCATION LOCATION LOCATION IC101 CN105 CN105 T1-28500/SG41J-U PIN A3 PIN 1 PIN 7 XOUT LCDD7 LCDD1 1V/div 1V/div 1V/div JW651 AWG32 20ns/div 100ns/div 100ns/div ZHINGE TO VF1 JW175 2.0X1.25 IC101 CN105...

  • Page 50: Vf1 Board Lcd Connector, Mic & Speaker

    VF1 BOARD LCD CONNECTOR, MIC & SPEAKER Z1-28500/SG41J-U CN171 JW177 AWG32/AWG30 LCDRESET GREST TO CP1 (DMA) SHDB CN105 LCDEN SCEN JW178 AWG32/AWG30 LCDCK LCDSD RB172 TO SPEAKER WHITE LCDD7 DIN7 LCDD6 DIN6 JW176 AWG32/AWG30 DIN5 LCDD5 TO TB1 JW652 LCDD4 RB173 DIN4 C1873...

  • Page 51: Printed Wiring Boards (P.w.b.)

    PRINTED WIRING BOARDS (P.W.B.) CP1 P.W.B. (SIDE A) CP1 P.W.B. (SIDE B) TB1 P.W.B. (SIDE A) TB1 P.W.B. (SIDE B) CN110 R1302 L1304 L1303 C1311 C1301 C1314 C1313 VA131 R3018 Q1302 Q3002 Q3006 R1352 Q1401 D1901 R1934 R1901 C1402 C1403 CL251 R1919 IC191...
  • Page 52 VF1 P.W.B. (SIDE A) VF1 P.W.B. (SIDE B) K3400BB SG41J_VF1 SIDE-A RB173 C1711 R1703 R1702 C1705 C1712 C1716 R1875 R1871 C1873 IC185 JW172 JW171 JW173 JW174 R1869 C1855 VA181 CA1 P.W.B. (SIDE A) CA1 P.W.B. (SIDE B) C9143 C9129 C9144 C9101...
  • Page 53 ST1 P.W.B. (SIDE A) ST1 P.W.B. (SIDE B) R5434 IC541 F5004...
  • Page 55 SANYO Electric Co., Ltd. Osaka, Japan Apr./’10...
