SERVICE MANUAL
CONTENTS
1. OUTLINE OF CIRCUIT DESCRIPTION .....................................3
2. DISASSEMBLY ........................................................................12
3. ELECTRICAL ADJUSTMENT ..................................................17
4. USB STORAGE INFORMATION REGISTRATION ..................22
5. TROUBLESHOOTING GUIDE .................................................23
6. PARTS LIST .............................................................................24
RoHS
This product does not contain any hazardous substances prohibited by the
RoHS Directive.
WARNING
You are requested to use RoHS compliant parts for maintenance or repair.
You are requested to use lead-free solder.
(This product has been manufactured using lead-free solder. Be sure to follow
the warning given on page 2 when carrying out repair work.)
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same of equivalent type recommended by the
manufacturer.
Discard used batteries according to the manufacturer's instruction.
Design and specifications are subject to change without notice.
NOTE: 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N.S.P. : Not available as service parts.
Design and specifications are subject to change without notice.
SG31B/U, U2, U3, EX, EX2, EX3, GX, GX2, GX3, PX, PX2, PX3
FILE NO.
VPC-CG11W
(Product Code : 168 228 02)
VPC-CG11OR
(Product Code : 168 228 06)
VPC-CG11G
(Product Code : 168 228 10)
(U.S.A.) (Canada) (Taiwan)
VPC-CG11EXW
(Product Code : 168 228 03)
VPC-CG11EXOR
(Product Code : 168 228 07)
VPC-CG11EXG
(Product Code : 168 28 11)
(Europe) (U.K.) (South America)
(China) (Australia) (Hong Kong)
(Russia) (Middle East) (Africa)
(General) (Korea) (Taiwan)
VPC-CG11GXW
(Product Code : 168 228 04)
VPC-CG11GXOR
(Product Code : 168 228 08)
VPC-CG11GXG
(Product Code : 168 228 12)
(South America) (China) (Australia)
(Hong Kong) (General) (Korea) (Taiwan)
VPC-CG11PXW
(Product Code : 168 228 13)
VPC-CG11PXOR
(Product Code : 168 228 14)
VPC-CG11PXG
(Product Code : 168 228 15)
(General)
REFERENCE No.SM5310786
Advertisement
Chapters
Table of Contents
Related Manuals for Sanyo VPC-CG11W
Summary of Contents for Sanyo VPC-CG11W
-
Page 1: Table Of Contents
FILE NO. SERVICE MANUAL VPC-CG11W (Product Code : 168 228 02) VPC-CG11OR (Product Code : 168 228 06) VPC-CG11G (Product Code : 168 228 10) (U.S.A.) (Canada) (Taiwan) VPC-CG11EXW (Product Code : 168 228 03) VPC-CG11EXOR (Product Code : 168 228 07) - Page 2 WARNING Do not use solder containing lead. Note: This product has been manufactured using lead-free If replacing existing solder containing lead with lead-free solder in order to help preserve the environment. solder in the soldered parts of products that have been manufactured up until now, remove all of the existing solder Because of this, be sure to use lead-free solder when at those parts before applying the lead-free solder.
-
Page 3: Outline Of Circuit Description
1. OUTLINE OF CIRCUIT DESCRIPTION 1-1. CMOS CIRCUIT DESCRIPTION 1. IC Configuration The CMOS peripheral circuit block basically consists of the following ICs. IC911 (MT9J001I12STCV) CMOS imager CDS, AGC, ADC built-in H driver, V driver, serial communication circuit built-in 2. IC911 (CMOS) [Structure] The electric charges which are generated when each pixel is optically converted are in turn converted into signal voltages... - Page 4 1-2. CP1 and VF1 CIRCUIT DESCRIPTION 1. Circuit Description 2. Outline of Operation 1-1. Digital clamp When the shutter opens, the reset signals (ASIC and CPU) The optical black section of the extracts averaged values from and the serial signals (“take a picture” commands) from the the subsequent data to make the black level of the output 8-bit microprocessor are input and operation starts.
- Page 5 4. Lens drive block 5. Video Clip Recording and Playback 4-1. Focus drive 5-1. Recording The 16-bit serial data signals (LENS_SDI) and (LENS_SCLK The signal from the camera block is input to IC101 (ASIC). and LENS_EN) which are output from the ASIC (IC101) are The data that is input to the ASIC is input to SDRAM, and used to drive (FOCUS A +, FOCUS A -, FOCUS B + and FO- converts this data to encoded MPEG4 data, after which it is...
- Page 6 1-3. PWA POWER CIRCUIT DESCRIPTION 1. Outline 3. Digital 3.25 V Power Output This is the main power circuit, and is comprised of the follow- VDD3 is output. Feedback for the VDD3 is provided to the ing blocks. swiching controller (Pin (F3) of IC501) so that PWM control Switching controller (IC501) can be carried out.
- Page 7 1-4. ST1 STROBE CIRCUIT DESCRIPTION 1. Charging Circuit 2. Light Emission Circuit When UNREG power is supplied to the charge circuit and When FLCTL signal is input from the ASIC, the stroboscope the CHG signal from microprocessor becomes High (3.3 V), emits light.
- Page 8 1-5. SYA CIRCUIT DESCRIPTION 1. Configuration and Functions For the overall configuration of the SYA block, refer to the block diagram. The SYA block centers around a 8-bit microprocessor (IC301), and controls camera system condition (mode). The 8-bit microprocessor handles the following functions. 1.
- Page 9 PLLEN ASIC PLL ON/OFF control HINGE LCD panel rotation detection (L= panel inversion) ZBOOT_COMREQ BOOT output and COMREQ input NOT USED HOTLINE Hot line request from ASIC BAT_TEMP Battery temperature detection Battery OFF detection (L= battery OFF) ZBAT_OFF Serial communication request signal ZSREQ KEY_2ND Key input 2nd SHUTTER (L= input)
- Page 10 3. Power Supply Control The 8-bit microprocessor controls the power supply for the overall system. The following is a description of how the power supply is turned on and off. When the battery is attached, a regulated 3.2 V (power off: 2.4 V) voltage is normally input to the 8-bit microprocessor (IC301) by IC302, so that clock counting and key scan- ning is carried out even when the power switch is turned off, so that the camera can start up again.
- Page 11 MEMO...
-
Page 12: Disassembly
2. DISASSEMBLY 2-1. REMOVAL OF CABINET LEFT, ST1 BOARD AND LCD When assembling, attachment order. 3, 15 NOTE: Discharge a strobe capacitor with the discharge jig (VJ8-0188) for electric shock prevention. - Page 13 1. LCD is opened. 2. Screw 1.7 x 2 3. Cover battery is opened. 4. Screw 1.7 x 3.5 5. Screw 1.7 x 5 6. Screw 1.7 x 5 7. Cabinet top 8. Two screws 1.7 x 3.5 9. Screw 1.7 x 3.5 10.
- Page 14 2-2. REMOVAL OF CP1 BOARD 1. Holder lens 12. Button power 2. Spacer wire 13. Screw 1.7 x 2.5 3. Screw 1.7 x 3.5 14. Spacer SW unit 4. FPC 15. Unit, control 5. Connector 16. Two screws 1.7 x 3 6.
- Page 15 2-3. REMOVAL OF TB1 BOARD, LCD AND VF1 BOARD 1. Cover joint 15. Spacer speaker filter 2. Two screws 1.7 x 3 16. Cover LCD front 3. Spacer LCD FPC (Orenge only) 17. FPC 4. Shield tape MIC 18. LCD 5.
- Page 16 2-4. BOARD LOCATION VF1 board ST1 board TB1 board CP1 board...
-
Page 17: Electrical Adjustment
URL. ± 20 K and luminosity to 900 ± 20 cd/m . Be careful of han- http://www.overseas.sanyo.com/dcamera_service/ dling the lump and its circumference are high temperature Place the DscCalDi.exe file, camapi32.dll file and during use and after power off for a while. - Page 18 3-6. The adjustment item which in necessary in part exchange CCD Black CCD White Lens Lens Point And Point Factory White Point Adjust- Adjust- Language storage Reset Defect Defect Adjust- Cord Setting ment information Setting ment Detect Detect Setting ment Adjustment registration (Infinity)
- Page 19 Adjustment value determination is effectuated using below val- Note: ues. Do not vibrate during the adjustment. The adjustment values fulfill the conditions below, they are If readjusting after it has already been adjusted, wait for 15 determined as within specifications. minutes or more for the unit to cool down first.
- Page 20 3. AWB Adjustment Adjustment value determination is effectuated using the “CHECK”, “CHECK_ND”, “MS”, “MS_M”, “MS_C”, “MS_C2”, “IRIS_PWM1”, “IRIS_PWM2”, “IRIS_PWM3”, “IRIS_PWM4” , “IRIS_PWM5” and “IR_TEMP_AD” values. If CHECK= wc0, wc1, wc2 CHECK_ND= wnc0, wnc1, wnc2 MS= ms1, ms2, MS_M= ms3, ms4, MS_C= ms5, ms6, MS_C2= ms7, ms8, IRIS_PWM1= s1, s2...
- Page 21 3-13. Firmware uploading procedure Preparation: POWER switch: ON 1. Uploading the firmware should be carried out if the version number (COMPL PWB XX-X) on the replacement circuit Setting of pattern box: Color temperature: 3100 ± 20 (K) board is lower than the version of the distributed firmware. Luminance: 900 ±...
-
Page 22: Usb Storage Information Registration
17.) 2. Double-click on the DscCalDi.exe. 3. Click on the Get button in the USB storage window and check the USB storage data. VID: SANYO PID: CG11 Serial: Rev. : 1.00 4. -
Page 23: Troubleshooting Guide
5. TROUBLESHOOTING GUIDE POWER LOSS INOPERTIVE TAKING INOPERATIVE PUSH SHUTTER PUSH THE POWER BUTTON SW FOR A WHILE HIGH IC301-24, 51 IC301-25 CHECK UNIT SW CHECK POWER SW KEY INPUT KEY_POWER INPUT IC501-D6, F6 (PON) IC301-9, 36, 59 CHECK IC101, IC301, CHECK IC302 IC504-4(PON2) (VDD) -
Page 24: Parts List
LOCATION PARTS NO. DESCRIPTION ACCESSORIES PACKING MATERIALS 645 098 8653 BATTERY,RECHARGE,LI-ION 636 130 4047 CARTON INNER-SG31B/EX, 645 098 8615 BATTERY CHARGER EXCEPT VPC-CG11W,VPC-CG11OR, 645 076 0235 CORD,POWER-1.5MK, VPC-CG11G 636 130 4030 CARTON INNER-SG31B/U,INNER CASE, VPC-CG11EXW,VPC-CG11EXOR, VPC-CG11EXG,VPC-CG11PXW, VPC-CG11W,VPC-CG11OR,VPC-CG11G 636 077 8139... - Page 26 LOCATION PARTS NO. DESCRIPTION CABINET & CHASSIS PARTS 1 636 130 5358 COVER BATTERY-SG31B/J, VPC-CG11W,VPC-CG11EXW, VPC-CG11GXW,VPC-CG11PXW 636 130 5389 COVER BATTERY-SG31B/J2, VPC-CG11OR,VPC-CG11EXOR, VPC-CG11GXOR,VPC-CG11PXOR 636 130 5693 COVER BATTERY-SG31B/J3, VPC-CG11G,VPC-CG11EXG, VPC-CG11GXG,VPC-CG11PXG 636 131 7733 SPACER COVER BATT-SG31B/J 636 106 8154 COVER BAT INNER-SG212/J...
- Page 27 10 13 Cabinet 1 SG31B PARTS LIST 1...
- Page 28 SCR PAN PCS 1.7X3 411 184 0005 SCR PAN PCS 1.7X2.0 312 060 7906 SPECIAL SCREW-1.7X3.0 411 177 8100 SCR S-TPG PAN PCS 1.7X2.5 411 199 0809 SCR TIN 1.7X3, EXCEPT VPC-CG11W,VPC-CG11EXW, VPC-CG11GXW,VPC-CG11PXW 411 199 0908 SCR TIN 1.7X3, VPC-CG11W,VPC-CG11EXW, VPC-CG11GXW,VPC-CG11PXW...
- Page 29 Cabinet 2 SG31B PARTS LIST 2...
- Page 30 ELECTRICAL PARTS Note: 1. Materials of Capacitors and Resistors are abbreviated as follows ; Resistors Capacitors MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor AL-SOLID Aluminum Solid Capacitor NP-ELECT...
- Page 31 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION C1206 303 338 0309 CERAMIC 0.1U K 10V C9009 303 380 6601 CERAMIC 0.22U K 6.3V C1207 303 338 0309 CERAMIC 0.1U K 10V C9011 303 381 8109 CERAMIC 1U K 6.3V C1208 303 338 0309 CERAMIC...
- Page 32 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION R9704 301 262 1904 MT-GLAZE 6.8K DC 1/16W R1519 301 263 9602 MT-GLAZE 91 DD 1/16W R9705 301 257 4101 MT-GLAZE 100K DC 1/16W R1529 301 277 5409 MT-GLAZE 75 DD 1/16W R9706 301 257 4101 MT-GLAZE 100K DC 1/16W...
- Page 33 LOCATION PARTS NO. DESCRIPTION COMPL PWB,ST-1 636 130 0490 (SEMICONDUCTORS) Q5402 406 021 5107 TR TIG032TS-S-TL-E (INTEGRATED CIRCUIT) IC541 409 684 3800 IC BD4218NUV (DIODES) D5401 307 247 4007 DIODE RR255M-400 D5402 407 265 1900 DIODE RE0208DA-TR-E D5404 407 261 2802 DIODE RB521S-30FJ (TRANSFORMER) T5403...
-
Page 34: Circuit Diagrams & Printed Wiring Boards
CIRCUIT DIAGRAMS & PRINTED WIRING BOARDS TABLE OF CONTENTS OVERALL WIRING & BLOCK DIAGRAMS Page OVERALL WIRING .............................C3 OVERALL CIRCUIT ............................C4 IMAGE SENSOR CIRCUIT ..........................C5 LENS CIRCUIT ..............................C5 MAIN CIRCUIT ..............................C6 SYSTEM CONTROL CIRCUIT ......................... C7 STROBE CIRCUIT .............................C7 POWER CIRCUIT...............................C8 CIRCUIT DIAGRAMS MAIN CIRCUIT WAVEFORMS ...........................C8... - Page 35 NOTES: 1. All resistance values in "OHMS" unless otherwise noted. (K=1,000 ; M=1,000,000) 2. All capacitance values in "µF" unless otherwise noted. p=pico farad ; n=nano farad ; µ ,u or U=micro farad 3. All inductance values in "µH" unless otherwise noted. µ...
-
Page 36: Overall Wiring & Block Diagrams
OVERALL WIRING & BLOCK DIAGRAMS OVERALL WIRING MIC (R) MIC (L) CN901 CN912 SPEAKER VDDIO VDDIO VDDIO VDDIO WHITE SDIN0 SDIN0 JW178 SDIP0 SDIP0 SDIN1 SDIN1 SDIP1 SDIP1 JW177 SCKIN SCKIN SCKIP SCKIP JW176 SDIN2 SDIN2 BLACK JW651 SDIP2 SDIP2 ZHINGE JW175 SDIN3... -
Page 37: Overall Circuit
OVERALL CIRCUIT LENS UNIT STROBE UNIT CN141 SD CARD CN951 SOCKET CA1 BOARD IC971 IC951 HALL LENS CMOS SENSOR DRIVER IMAGE 12MHz 48.0000MHz TCA BLOCK SENSOR PWA BLOCK POWER MANAGEMENT IC501 SWITCHING POWER CONTROL SHUTTER POWER CONTROL 3inch 96MHz FLCTL CN171 IC121 IC101... -
Page 38: Image Sensor Circuit
IMAGE SENSOR CIRCUIT LENS CIRCUIT ZOOM_PI_E IC101 CMOS_1.8 VDDIO VDDPLL VAA_2.8 VAAPIX VDD_SLVS_TX FOCUS_PI_E SYSTEM ASIC TO DMA IC951 LENS DRIVER CN951 LENS_BLOCK BOOST5V MVCC[12, 34, 56], VDDAMP, RNF ZOOM_PI_AC VDD3 VDDIO VDDPLL VAAPIX VDD_SLVS_TX VDD3 DVDD VDD_SLVS ZOOM_PI ZOOM_PI_E FOCUS_PI_AC SHUTTER CMOS_SHUTTER... -
Page 39: Main Circuit
MAIN CIRCUIT XOUT X1102 CMOS_SCL 48.000MHz CMOS_SDA ADCK 27MHz CN901 IC111 BOARD BtoB SDIN[0:3], SDIP[0:3], SCKIP, SCKIN CLOCK GEN 74.175824MHz CMOS_[SHUTTER, FLASH] HINGE BOARD SHUTTER+ BACKUP_BAT LENS_[SCLK,EN] LENS_[SDI, SDO] IC951 CN105 BOARD STATE_[F,Z] LCDEN,LCDCK,LCDSD LENS BtoW [ZOOM, FOCUS]_PI_E LMCL K DRIVER LCDD[0:7] CLK12M... -
Page 40: System Control Circuit
SYSTEM CONTROL CIRCUIT STROBE CIRCUIT BOOST 5V CHARGING CIRCUIT ZCHGDONE VDD2 ZCHGDONE AL3.2V TO DMA BACKUP3.2V C5401 T5403 D5402 VDD3 ST_CHG CN542 ST_CHG F5004 VDD1 BAT_TEMP POWER FILTER OSCILLATION RECTIFIER BAT_TEMP C5412 TO BATTERY IC302 TRANSFORMER CIRCUIT BLOCK RESET BATTERY VSS1 BACKUP CN541... -
Page 41: Power Circuit
CIRCUIT DIAGRAMS MAIN CIRCUIT WAVEFORMS POWER CIRCUIT TEST POINT TEST POINT L5301 WAVEFORM WAVEFORM BOOST5V TO DMA, SYA, TCA STEP UP CIRCUIT Q5013 LOCATION LOCATION VDD5 TO DMB IC503, L5005 VAA2.8 REG. IC101 IC101 PAON2 TO DMA, CAA L5002 STEP UP DOWN PIN AE12 PIN AB23 VDD3... -
Page 42: Cp1 Board (Dma) Main
CP1 BOARD (DMA) MAIN D1-22800/SG31B-U VOLTAGE: VIEW MODE, LCD ON VDD1.8 VDD3 DSA12 R8 IO4 SA12 DQS3 R9 IO5 DQS3 R10 IO13 R11 DQ0 VSSd ZDSCS R12 NC VDD1.8 ZRAS T1 NC /RAS C1063 0.1;B C1051 0.1;B DSA2 ZCAS C1057 T2 SA2 /CAS 0.1;B... - Page 43 CP1 BOARD (DMA) MAIN [UPPER-LEFT] D1-22800/SG31B-U VOLTAGE: VIEW MODE, LCD ON VDD3 VDD1.8 C1063 0.1;B C1051 0.1;B C1057 0.1;B C1064 0.1;B C1052 0.1;B C1058 C1065 0.1;B C1053 0.1;B 0.1;B C1054 0.1;B C1066 0.1;B VDD1.2 AC11 AC12 AC19 AC18 AA16 AA15 AC10 AA10 P11 VDD12...
- Page 44 CP1 BOARD (DMA) MAIN [UPPER-RIGHT] VDD1.8 DSA12 R8 IO4 SA12 DQS3 R9 IO5 DQS3 R10 IO13 R11 DQ0 VSSd ZDSCS R12 NC ZRAS T1 NC /RAS DSA2 ZCAS T2 SA2 /CAS ONENAND_CLK ZDSWE T3 CLKo ONENAND_AVD DQM3 T4 AVDBo DQM3 DQ24 T5 IO1 DQ24...
- Page 45 EV3XA AE2 VSS ZDWE ZUSBDET A3 VSS ZCAS QEV3XA------N ZAVJACK B3 VSS ZRAS ZCARD C3 VSS DBA1 PLLEN AC3 VSS ZDCS ONENAND_RESET TO SYA AD3 VSS CP1 BOARD (DMA) MAIN [LOWER-LEFT] DA10 13.0X13.0 AE3 VSS T6 VSS U6 VSS K7 VSS H=1.34 IRISPWM L7 VSS...
- Page 46 ZDSWE ZDWE ZCAS ZCAS VDD3 ZRAS ZRAS DSBA1 DBA1 ZDSCS ZDCS DSA10 CN141 DA10 CP1 BOARD (DMA) MAIN [LOWER-RIGHT] DSA0 DATA3 R1401 DSA1 100;1/16J SDCMD C1401 COMMAND DSA2 0.1;B DSA3 DQ15 DQ15 SDCLK CLOCK RB141 DQ14 DQ14 SDDAT3 DQ13 DQ13 SDDAT0 DATA0 DQ12...
-
Page 47: Cp1 Board (Dmb) Hdmi
CP1 BOARD (DMB) HDMI VDD1.8 TO PWA, DMA VDD3 D2-22800/SG31B-U HDMI_SCL HDMI_SDA C1907 CN191 TMDS SHLD2 C1908 L1901 TMDS DATA2+ VPB [0] VDDA(SHR)(1V8) 0.1;B DLP2ADN900HL4 VPB [1] VDDA(SHR)(1V8) TMDS DATA2- VPB [2] VSSA TMDS SHLD1 TX2+ VPB [3] TMDS DATA1+ TX2- VPB [4] TMDS DATA1-... -
Page 48: Cp1 Board (Tca) Lens
CP1 BOARD (TCA) LENS F1-22800/SG31B-U TO PWA, DMA, DMB, CAA VDD3 VDD3 TO PWA, SYA, DMA BOOST5V CN951 VDD3 ZOOM_A- ZOOM_A- ZOOM_B+ ZOOM_B+ ZOOM_A+ ZOOM_A+ ZOOM_B- ZOOM_B- R9507 5.1;1/10F DRIVE+ DRIVE+ R9506 DRIVE- 5.1;1/10F DRIVE- HALL_IN+ HALL_IN+ DRIVE- HALL_OUT- HALL_OUT- D6 SO3 OUT5B DRIVE+... -
Page 49: Cp1 Board (Sya) System Control
CP1 BOARD (SYA) SYSTEM CONTROL BOOST5V TO DMA, TCA, PWA BOOST5V UNREGSY TO PWA Y1-22800/SG31B-U TO PWA, TCA VOLTAGE: VIEW MODE, LCD ON AL3.2V AL3.2V R3009 TH_POWER BAT_TEMP 22K;1/16D BACKUP3.2V HOTLINE SW3.2V ZBKUPCTL ZSREQ R3004 ZBOOT_COMREQ 0;1/16Z PLLEN SDDET TO DMA RB313 HDMI_HPD TO DMB... -
Page 50: Cp1 Board (Pwa) Power
CP1 BOARD (PWA) POWER UNREG UNREG TO DMA VDD5 TO DMB Q5014 R5056 2SK3541 R5057 27K;1/16J 1K;1/16J F5003 F5002 2A32V 2A32V UNREG_A UNREGSY TO SYA F47K2R0C3LFND F47K2R0C3LFND 1608 1608 1AV4L2KN6R8NG LQH3NPN6R8NM0L LCDAN L5007 6.8;N H=1.5 3.0X3.0 UP03397 Q5008 R5002 C5072 0;1/16Z R5075 15K;1/16D... -
Page 51: Cp1 Board (Caa) Sensor Power
CP1 BOARD (CAA) SENSOR POWER CN901 VDDIO VDDIO VDDIO C2-22800/SG31B-U SDIN0 SDIN0 SDIP0 SDIP0 SDIN1 SDIN1 SDIP1 SDIP1 SCKIN SCKIN SCKIP SCKIP REG. REG. SDIN2 SDIN2 IC901 IC903 SDIP2 XC6221B082G TK70628HCL-G SDIP2 QXC6221B082GP VOUT VCONT VDD3 CMOS1.8 VDD_SLVS_TX PAON2 SDIN3 SDIN3 PAON1 SDIP3... -
Page 52: Ca1 Board Image Sensor
CA1 BOARD IMAGE SENSOR CN912 C1-22800/SG31B-U VDDIO VOLTAGE: VIEW MODE, LCD ON VDDIO VDDIO SDIN0 SDIN0 SDIP0 SDIP0 SDIN1 SDIN1 SDIP1 SDIP1 SCKIN SCKIN SCKIP SCKIP R9132 0;1/16Z SDIN2 SDIN2 1608 SDIP2 SDIP2 SDIN3 SDIN3 R9149 0;1/16Z A_GND SDIP3 SDIP3 1608 AGND VAA2.8... -
Page 53: St1 Board Strobe
ST1 BOARD STROBE CN542 TO BATTERY STROBE UNIT CN541 1AV4L17B0620G T5403 RE0208DA JW541 AWG30 TTRN-0530H-018-T D5402 BROWN F5004 2.0X1.25 STROBE 2A32V CHARGE ORANGE BAT+ IC541 JW543 AWG30 BAT+ BD4218NUV QBD4218NUV--P TRIG BAT+ C5410 BAT+ WHITE PGND 0.018;350B 3216 R5436 BAT+ IGBT_OUT 1K;1/16J C5431... -
Page 54: Vf1 Board Lcd Connector, Mic & Speaker
VF1 BOARD LCD CONNECTOR, MIC & SPEAKER JW177 AWG32/AWG30 CN171 LCDRESET GREST TO CP1 (DMA) SHDB CN105 SCEN LCDEN JW178 AWG32/AWG30 LCDCK LCDSD RB172 TO SPEAKER BLA2ABD471SN4D WHITE LCDD7 DIN7 LCDD6 DIN6 JW176 AWG32/AWG30 LCDD5 DIN5 LCDD4 RB173 DIN4 LCDAN LCDAN BLA2ABD471SN4D TO TB1 JW652... -
Page 55: Lcd Circuit Waveforms
PRINTED WIRING BOARDS (P.W.B.) LCD CIRCUIT WAVEFORMS CA1 P.W.B. (SIDE A) TEST POINT TEST POINT WAVEFORM WAVEFORM LOCATION LOCATION CN171 CN171 PIN 14 PIN 9 DCLK DIN4 1V/div 1V/div 40ns/div 40ns/div CN171 CN171 PIN 13 PIN 8 DIN0 DIN5 1V/div 1V/div 40ns/div 40ns/div... - Page 56 CP1 P.W.B. (SIDE A) CP1 P.W.B. (SIDE B) CN110 L1304 VA301 VA302 L1303 CB301 C1301 C1302 Q1301 VA306 C1303 R3007 VA305 IC301 C3014 CL316 CB302 Q3002 C3004 VA304 R3008 C3013 C3016 Q3003 RB306 Q3001 R1921 C1911 R1934 D1901 R3005 VA303 C1912 CL150 CL519...
-
Page 57: St1 P.w.b. (Side A & B)
ST1 P.W.B. (SIDE A) ST1 P.W.B. (SIDE B) CL561 CL543 R5424 CL560 R5436 R5433 JW544 CL541 R5432 C5434 SG315-ST1 R5422 JW543 J2800AA C5401 CL542 CL557 CL551 CL554 CL562 SIDE-A SG315-ST1 CL552 CL553 C5410 J2800AA CL556 CL555 CN541 SIDE-B CN542 VF1 P.W.B. (SIDE B) VF1 P.W.B. - Page 58 SANYO Electric Co., Ltd. Osaka, Japan Aug./’09...
