Reversing switches
BATTERY FITTING
4 AA alkaline batteries are required. They are not supplied.
Install the 4 batteries into the battery compartment ensuring correct polarity is observed.
Charge socket
polarity
CHARGING SOCKET
Rechargeable AA batteries can be substituted for alkaline batteries.
N.B. Take note of the polarity diagram on the rear case when using a charger to charge rechargeable batteries.
SIMULATOR LEAD SOCKET
For optional Simulator lead connection.
T5
Instruction Manual
5th Channel
On/Off Switch
Simulator socket
Battery cover
Press and slide off cover
3
