Battery Status Lcd; Mode Change Switch; Failsafe - Planet 2.4GHZ DIGITALREMOTE CONTROL SYSTEM Instruction Manual

rock-solid r/c
WARNING!
Do not fly at 100 metres distance or greater. At distances of greater than 50 metres, it will become difficult to see
your model and at 100 metres it will be very difficult to see accurately and therefore to control safely.
We strongly recommend you fly no further away than 50 metres.
WARNING!
Planet 5 has been tested with many types of models and operated at ranges significantly greater than that
recommended. However, 2.4GHz equipemnt is affected by terrain, weather and obstacles to a significantly
greater degree than is conventional lower frequency R/C equipment. Therefore, do not be tempted to exceed
these specifications
Do not exceed the distances specified!

BATTERY STATUS LCD

This display provides a digital readout of Transmitter voltage. Stop flying and replace the batteries when voltage
display falls to 4.4V.
WARNING!
Failure to stop flying immediately when the display reads 4.4V or less may lead to loss of control!

MODE CHANGE SWITCH

Located at the bottom left of the main PCB is the mode change switch which facilitates conversion between
throttle left (Mode 1) layout and throttle right (Mode 2) layout.
Throttle right
Throttle left

FAILSAFE

If the transmitter signal is lost, the built-in failsafe operates and immediately drives the throttle to zero/no power
setting and the other controls are sent to their centre position.
WARNING!
This will result in your aircraft descending uncontrollably and immediately in whatever attitude is determined
by the dynamics and speed of your model at the time!
This failsafe setting is designed to prevent the model from flying away (and thereby posing a threat to the safety
of third parties).
8
