Carton Inventory

Your garage door opener is packaged in two cartons
which contain the motor unit and all parts illustrated
below. Accessories will depend on the model
Door Control Button
with (2) 6ABx1-1/2" screws
Light Lens (1)
Cable
Pulley Bracket
Safety Sensor
Bracket (2)
INSTALLATION HARDWARE
Hex Screw 5/16"-18x7/8" (4)
Lag Screw 5/16"-9x1-5/8" (2)
Lag Screw 5/16"-18x1-7/8" (2)
Clevis Pin 5/16"x2-3/4" (1)
Clevis Pin 5/16"x1-1/4" (1)
Clevis Pin 5/16"x1" (1)
Nut 5/16"-18 (4)
Lock Washer 5/16" (4)
Self-Threading Screw 1/4"-14x5/8" (2)
SECURITY
Single-Function Remote Control (1)
2-Conductor Bell Wire
White & White/Red
Trolley
(2) Safety Reversing Sensors
(1 Sending Eye and 1 Receiving Eye)
with
2-Conductor White & White/Black Bell Wire
attached
purchased. If anything is missing, carefully check the
packing material. Parts may be stuck in the foam.
Hardware for installation is also listed below.
Remote Control
Visor Clip
Chain
& Cable
Door Bracket
One-Piece
T-rail
Header Bracket
Insulated Staples (30)
Ring Fastener (3)
Dry Wall Anchors (2)
Rope
Handle
Rail Grease
Carriage Bolt 1/4"-20x1/2" (2)
Wing Nut 1/4"-20 (2)
5
Sprocket Cover
Styrofoam
Curved Door
Arm Section
Safety Labels
and
Literature
Straight Door
Arm Section
