REPAIR PARTS

Rail Assembly Parts

2

Installation Parts

2
3
4
7
8
12
1
1
6
5
10
9
11
3
KEY PART
NO. NO.
1 1A995
6
2 41A4813
3 41A3489
4 183B99
5 41A3484
6 83A4
KEY PART
NO. NO.
1 41A4166
2 41A5056-1GM
3 10A20
4 29B137
5 41A2828
6 217A238
7 41A4353
8 41A5047
9 41A5034
10 178B34
11 178B35
12 41A5266-1
41A2770-6
114A1994
33
4
DESCRIPTION
Master link kit
Chain pulley bracket
Complete trolley assembly
One-piece T-rail
Chain and cable assembly
Rail grease
DESCRIPTION
Door Control Button
Single-function remote control
case (no circuit board)
3V2032 Lithium battery
Remote control visor clip
Manual rope & handle assy.
2-Conductor bell wire,
white & white/red
Header bracket w/clevis pin &
fastener
Door bracket w/clevis pin & fastener
Safety sensor kit
(receiving and sending eyes)
with 3' 2-connector bell wire attached
Straight door arm section
Curved door arm section
Safety sensor brackets (2)
NOT SHOWN
Installation hardware bag (includes
hardware listed on page 5).
Owner's manual
5
