  • Page 1 OPERATOR MANUAL '16' Series 2816 Gear Click here to go on INDEX Main Menu contactus@almats.com...

  • Page 2: Series, Model - 2816 4Wd

    Prior to delivery, the tractor was carefully inspected, both at the factory and by your Mahindra dealer, to ensure that it reaches you in optimum condition. To maintain this condition and ensure trouble free performance, it is important that the routine services, as specified in this manual, are carried out at the recommended intervals.

  • Page 3: Diesel Engine

    Off-Road Diesel Engine Emission Control System Warranty Statement MITSUBISHI DIESEL ENGINE MITSUBISHI HEAVY INDUSTRIES, LTD. GENERAL MACHINERY & SPECIAL VEHICLE HEADQUARTERS 16 Series, Model - 2816 4WD...
  • Page 4 Off-Road Diesel Engine Emission Control System Warranty Statement Emission Related System Defect Warranty Manufacturer Statement Mitsubishi Heavy Industries, ltd. (MHI) will give a warranty condition, required by the U.S. Environmental Protection Agency(EPA) and the California Air Resource Board(CARB) to Original Equipment Manufacturers (OEMs) for small off-road engines purchased in 1997 and later which are used in U.S.A.
  • Page 5 30 days. If you have any question regarding your warranty rights and responsibilities, you should contact (Mahindra, USA Inc) at 1-800-561-9256. The emission warranty is a defects warranty. Defects are judged on normal engine performance.
  • Page 6 Fuel injection system Fuel injection pump • Fuel injectors • Inlet system Intake manifold • Exhaust system Exhaust manifold • Turbocharger system Turbocharger (if equipped) • Miscellaneous items used in above systems Cylinder Head Gasket • Valve Stem Seal • Length of Coverage MHI warrants to the initial owner and each subsequent purchaser that the warranted parts shall be free from defects in materials and workmanship which cause the failure...
  • Page 7 which are not original OEMs parts or because of abuse, neglect or improper maintenance as set forth in the OEMs engine warranty policy. OEMs is not liable to cover failures of warranted parts caused by the use of add-on, non-original, or modified parts.
  • Page 8 INTRODUCTION INTRODUCTION This instruction manual contains information on the operation, lubrication and maintenance of your tractor. The information contained is compre- hensive and essential, and is designed to assist you, even if un- experienced, in utilizing your tractor. How well your tractor continues to give satisfactory performance de- pends greatly upon the manner in which it is operated.

  • Page 9: Serial Number Locations

    SERIAL NUMBERS SERIAL NUMBERS Write your machine Model Number and Serial Numbers of major com- ponents on the lines provided. If needed, give these numbers to your dealer when you need parts or information for your machine. 1. TRACTOR MODEL NUMBER________________________________ 2.

  • Page 10: Table Of Contents

    GENERAL TABLE OF CONTENTS Safety/Decals ....................1-19 Specifications ..................... 20-24 Instruments/Controls .................. 25-41 Operating Instructions ................42-61 Field Operation ................... 62-75 Tires/Wheels/Spacing/Ballast ..............71-86 Lubrication/Filters/Fluids................87-113 Maintenance/Adjustments ..............114-120 Electrical System..................121-128 Storage ....................129-130 16 Series, Model - 2816 4WD...

  • Page 11: Safety/Decals

    SAFETY/DECALS_______________________________________________________ SAFETY PRECAUTIONS REMEMBER: “SAFETY” IS ONLY A WORD UNTIL IT IS PUT INTO PRACTICE Improper handling of the tractor could cause an accident. Prior to the operation of the tractor, be sure to read this Manual carefully and have a thorough understanding of all of the contents.
  • Page 12 SAFETY/DECALS_______________________________________________________ 3. Cover the PTO shaft with a 7. Hydraulic oil or fuel escaping under pressure can penetrate guard when not using. the skin, causing serious injury. Before disconnecting oil or fuel 4. Be sure to engage the brake and lower any attachment or lines, be sure to relieve all implement before pressure.
  • Page 13 SAFETY/DECALS_______________________________________________________ 9. Before starting any work on c) If diluted sulphuric acid has electrical equipment or work that gotten on the skin of clothing: may cause you to touch the Wash away the diluted electrical part accidentally, first sulphuric acid completely with a disconnect the battery cables.
  • Page 14 SAFETY/DECALS_______________________________________________________ C. OPERATION OF THE TRACTOR Before driving the tractor, follow these rules: C-1. Before starting and Driving the Tractor Operate the tractor only when seated properly in operator’s seat and keep a firm grip on the steering wheel at all times.
  • Page 15 SAFETY/DECALS_______________________________________________________ Slow down when operating the When starting the engine in an tractor on rough round. enclosed area or building, ensure proper ventilation by opening the doors and/or windows to prevent carbon monoxide inhalation. Mount the extension exhaust pipe on the tractor which has a cabin.
  • Page 16 SAFETY/DECALS_______________________________________________________ C-3. Travelling on Roads and C-4. Steering and Turning the Streets Tractor For travelling on roads and Slow down your tractor and streets, be sure to lock both disengage the differential lock brake pedals together before before going into a turn, being driving to prevent either brake careful to prevent any from acting independently.
  • Page 17 SAFETY/DECALS_______________________________________________________ When operating the tractor on Avoid operating the tractor on an extreme slope that appears either a steep slope or flat hazardous, when forced to ground, be sure not to suddenly steer, brake, clutch or operate operate on such slope, use attachments.
  • Page 18 SAFETY/DECALS_______________________________________________________ DECALS IMPORTANT: Install new decals if the old decals are destroyed, lost, painted over or can not be read. When parts are replaced that have decals, make sure you install a new decal with each new part. NOTE: New decals are available from your Dealer. WARNING EXPLOSION AND INJURY CAN RESULT FROM USE...
  • Page 19 SAFETY/DECALS_______________________________________________________ WARNING ROTATING MACHINE PARTS STAY CLEAR, KEEP SHIELDS INSTALLED TO HELP PROTECT FROM CLOTHING ENTANGLEMENT AND INJURY. 321-3710 16 Series, Model - 2816 4WD...
  • Page 20 SAFETY/DECALS_______________________________________________________ ROLL OVER PROTECTIVE STRUCTURE (ROPS) Foldable ROPS Frame When improperly operated, this tractor can roll over or upset. Use of the ROPS and seat belt minimize the possibility of injury or death if rollover or upset occurs. For low clearance use only, the ROPS can be lowered.
  • Page 21 SAFETY/DECALS_______________________________________________________ Low Clearance Positions For low clearance operation, such as operating in buildings, orchards or vineyards, the ROPS can be lowered and secured in the down position. No rollover protection is provided in the lowered positions and the seat belt should not be fastened. When the low clearance operation is completed, return the ROPS to the secured upright position for all other tractor uses and transport.

  • Page 22: Safety Rules

    SAFETY/DECALS_______________________________________________________ Tractor Roll Over ROPS is a special safety unit. After an accident the ROPS must be replaced so that you will get the same protection as a new ROPS. ROPS, the seat, the seat belts and all the mounting, accessories and wiring inside the operators protective area must be carefully checked after a tractor accident and all parts with damage should be replaced immediately.

  • Page 23: Step

    SAFETY/DECALS_______________________________________________________ Folding the ROPS ROPS BAR (NORMAL OPERATING POSITION) LOCK PIN POSITION PIN LOCK NUT JAM NUT LOCK BOLT To fold the ROPS, put the tractor on level ground, put the range shift lever in the L position, apply the park brake and stop the engine. IMPORTANT: Do not fold the ROPS with a sunshade installed.
  • Page 24 SAFETY/DECALS_______________________________________________________ STEP 5 STEP 8 JAM NUT LOW CLEARANCE LOCK BOLT POSITION PIN POSITIONS Install the position pins. Tighten the jam nut on the lock bolts to a torque of 33 to 40 lb.ft (44 to 54 N.m). STEP 9 STEP 6 ROPS BAR LOCK PIN...
  • Page 25 SAFETY/DECALS_______________________________________________________ Securing the ROPS in the Upright Position ROPS BAR (NORMAL OPERATING POSITION) LOCK PIN POSITION PIN LOCK NUT JAM NUT LOCK BOLT For normal operation, the ROPS must be in the secured upright position Place the tractor on level ground, put the range shift lever in the L position, apply the park brake and stop the engine.
  • Page 26 SAFETY/DECALS_______________________________________________________ STEP 3 STEP 6 ROPS BAR POSITION PIN While holding the ROPS bar, If the position pins cannot be CAREFULLY remove the position installed, CAREFULLY lower the pins. ROPS bar to the horizontal position. STEP 4 STEP 7 TO THE UPRIGHT POSITION ROPS BAR JAM NUT LOCK BOLT...
  • Page 27 SAFETY/DECALS_______________________________________________________ ROPS BAR (NORMAL OPERATING POSITION) LOCK PIN POSITION PIN LOCK NUT JAM NUT LOCK BOLT STEP 9 STEP 10 TO THE UPRIGHT POSITION POSITION PIN ROPS BAR ROPS BAR CAREFULLY move the ROPS Install the position pins. Align the holes of the position pins and bar to the upright position.
  • Page 28 SAFETY/DECALS_______________________________________________________ STEP 11 STEP 15 For tractors without a sunshade For tractors with a sunshade, and for operators who frequently STEP 12, STEP 13 and STEP 14 fold the ROPS for low clearance must be followed for using the tractor operation, continue to lock bolts.
  • Page 29 SAFETY/DECALS_______________________________________________________ ROPS BAR (NORMAL OPERATING POSITION) LOCK PIN POSITION PIN LOCK NUT JAM NUT LOCK BOLT STEP 18 STEP 17 LOCK PIN LOCK NUT Install the lock nuts. Tighten the Install the lock pins. nuts to a torque of 33 to 40 lb ft (44 to 54 Nm).

  • Page 30: Specifications

    SPECIFICATIONS_______________________________________________________ DIESEL ENGINE General Type ............Three Cylinder, Four Stroke Cycle, Valve in Cylinder Head, Cross Flow Porting Firing Order..................1 — 3— 2 Bore ..............78mm (3.071 inch) Stroke..............92mm (3.622 inch) Piston Displacement ............1318 cm (80.43 Cubic inch) Compression Ratio.................22.0 to 1 Governor Engine Speed Without Load.......

  • Page 31: Cooling System

    SPECIFICATIONS_______________________________________________________ Air Intake System Type ............Dry Type Air Cleaning System Cooling System Type ..........Pressure System, Thermostat Con- trolled Bypass, Impeller Type Pump Radiator ..........Corrugated and Louver Fin Type Thermostat ........Start to Open at Approx. 82°C(180°F) Fully Open at 95°C (203°F) Pressure Cap ...............

  • Page 32: Differential Lock

    SPECIFICATIONS_______________________________________________________ Clutch Type, Diameter Gear Drive ........Dry, Dual Disc, Diaphragm Type, 215 mm (8.46 Inch) Operation ................... Mechanical Mechanical Front Drive (MFD) Front Axle ..........Spiral Bevel Gear Type Differential with Bevel Gear Type Reductions Differential Lock Gear Drive........Controlled by pedal on the RH Step and Mechanically Actuated Steering Type of Steering ..............

  • Page 33: Hydraulic System

    SPECIFICATIONS_______________________________________________________ Hydraulic System Hydraulic Pump Type ..... Front Mounted, Engine Driven, Pres- sure Loading Gear Type Capacity Pump for Three Point Hitch ........29.6 l /min. (7.8GPM) at 2600 EngineRPM Pump for Power Steering .......... 13.4 l /mm.(3.5GPM) at 2600 EngineRPM Maximum System Pressure ..........
  • Page 34 DIMENSIONS_______________________________________________________ OVERALL LENGTH 2920mm 115.0inch (To end of lower link) OVERALL WIDTH 1380mm 54.3inch (To end of tire) HEIGHT 2140mm 84.3inch (To top of rops) WHEELBASE 1650mm 65.0inch GROUND CLEARANCE 330mm 13.0inch T URNING RADIUS 2400mm 94.5inch (With brake assistance) WEIGHT 1050kg 2315lbs...

  • Page 35: Instruments/Controls

    INSTRUMENTS /CONTROLS ______________________________________________ INSTRUMENTS AND INDICATORS 1. TACHOMETER AND HOURMETER – The tachometer shows the engine speed in revolutions per minute (RPM). A symbol on the face indicates the correct Power Takeoff (PTO) operating speed. The hourmeter shows the hours and tenths of hours that the engine has operated at an average RPM.
  • Page 36 INSTRUMENTS /CONTROLS ______________________________________________ 2. ENGINE COOLANT TEMPERATURE GAUGE – The gauge indicates the coolant temperature when the starter key switch is in the ON posi- tion. The gauge has a yellow area, green area and red area: The pointer is in this area when the engine is cool Yellow area before and immediately after starting.
  • Page 37 INSTRUMENTS /CONTROLS ______________________________________________ 5. ENGINE GLOW PLUG INDICATOR – This signal indicates the cor- rect functioning of the glow plug circuit. When the glow plugs have reached the correct temperature for engine starting, the glow plug indicator lamp will be put out. 6.
  • Page 38 INSTRUMENTS /CONTROLS ______________________________________________ OPERATING CONTROLS Control Switches 1. STARTER KEY SWITCH — The starter key switch can be removed with the switch in the OFF position. Four position switch as follows: Engine and all lamps except position– the turn signal and flasher (OFF) lamps are turned off.
  • Page 39 INSTRUMENTS /CONTROLS ______________________________________________ 2. ENGINE SPEED CONTROL LEVER – Move the engine speed control lever to the rear to increase engine speed. Move the engine speed control lever forward to decrease engine speed. 3. LAMP SWITCH – Three position switch as follows: –...
  • Page 40 INSTRUMENTS /CONTROLS ______________________________________________ 6. TURN SIGNAL SWITCH — To indicate that you are going to turn the tractor to the RIGHT, move the turn signal switch up. To indicate that you are going to turn the tractor to the LEFT, move the turn signal switch down.
  • Page 41 INSTRUMENTS /CONTROLS ______________________________________________ Control Levers and Pedals (Gear Drive) 1. ACCELERATOR PEDAL Use this pedal when operating the tractor on the road. Push the pedal down to increase engine speed. NOTE: The engine speed control lever must be set to give the slowest engine speed when the throttle pedal is used.
  • Page 42 INSTRUMENTS /CONTROLS ______________________________________________ 2. BRAKE PEDALS — The brake pedals when locked together, provides braking to both rear wheels for stop- ping the tractor. When the brake pedals are unlocked, the pedals are used for individual braking of the rear wheels to aid in turning the tractor in soft soil conditions.
  • Page 43 INSTRUMENTS /CONTROLS ______________________________________________ (Gear Drive) 4. PARK BRAKE LEVER – The park brake must be on to prevent movement of the tractor during stationary power takeoff work or when the tractor is parked. To en- gage the park brake, lock the brake pedals together, push down on the brake pedals and move the park brake lever downward.
  • Page 44 INSTRUMENTS /CONTROLS ______________________________________________ 5. CLUTCH PEDAL – The clutch must be disengaged when starting the engine, stopping the tractor, storing the tractor and operating the following levers,gear shift lever, range lever, rear PTO lever, MID PTO Lever, MFD lever creep lever. 5-1.
  • Page 45 INSTRUMENTS /CONTROLS ______________________________________________ Control Levers (Gear Drive) 1. GEAR SHIFT LEVER — The gear shift lever is used to shift the transmission gears into reverse or any of the three forward speeds. 16 Series, Model - 2816 4WD...
  • Page 46 INSTRUMENTS /CONTROLS ______________________________________________ 2. RANGE SHIFT LEVER — Move the range shift lever forward to place the transmission in L range. Move the lever to the rear- ward to place the trans- mission in M or H range. The center position be- tween M and L or H and M places the transmission in NOTE: Be sure the range...
  • Page 47 INSTRUMENTS /CONTROLS ______________________________________________ (Gear Drive) 5. HITCH CONTROL LEVER – Use this lever to control the position of the hitch. Move the lever forward to lower the hitch to the required depth. Move the lever to the rear to raise the hitch to the required height.
  • Page 48 INSTRUMENTS /CONTROLS ______________________________________________ 6. DRAFT CONTROL LEVER (IF EQUIPPED) – Use draft control with soil engaging implements to main- tain a constant load on the tractor through variable soil conditions. For light load operation, move the lever to the rear. For heavy load opera- tion, move the lever forward.

  • Page 49: Gear Drive

    INSTRUMENTS /CONTROLS ______________________________________________ (Gear Drive) 1. DIFFERENTIAL LOCK PEDAL – Push the pedal down to engage the differential lock. A spring inside the differential lock will push it out of engagement when pedal is released. GEAR DRIVE 16 Series, Model - 2816 4WD...
  • Page 50 INSTRUMENTS /CONTROLS ______________________________________________ NOTE: When engaging the differential lock, push the clutch pedal down or bring speed ratio control pedal to Neutral, to stop the wheels that are rotating, then push the differential lock pedal. Do not operate the differential lock pedal while the wheels are rotating. Do not drive on roads, or at high speed anywhere, with the differential lock engaged.

  • Page 51: Operators Seat

    INSTRUMENTS /CONTROLS ______________________________________________ OPERATORS SEAT The seat can be adjusted in 5 fore/aft positions by the lever located under the RH side of the seat. The seat is adjustable fore and aft by moving a lever. 1. Move the lever upward. 2.

  • Page 52: Operating Instructions

    OPERATING INSTRUCTIONS ____________________________________________ BEFORE STARTING THE ENGINE Before starting your tractor for the first time and before each operating period after that, make these checks: 1. Make sure all persons that operate or do maintenance on the tractor understand that clean fuel is important. 2.
  • Page 53 OPERATING INSTRUCTIONS ____________________________________________ RUN-IN PROCEDURE If run-in instructions for a new engine are not followed, you can cause damage to piston rings and cylinder walls. LOAD Never operate an engine immediately under full load. Allow the engine to warm up before operating it at full load. Run-in the engine carefully as shown in the table.

  • Page 54: Electrical System

    OPERATING INSTRUCTIONS ____________________________________________ NORMAL STARTING PROCEDURE IMPORTANT: It is very important that enough lubricant reaches the engine parts before operating the engine at rated speed. Operate controls only when seated in the operators seat. M137 Engine can start with transmission in gear when neutral or safety start switch is by-passed: 1.
  • Page 55 OPERATING INSTRUCTIONS ____________________________________________ STEP 4 STEP 2 STOP OFF POSITION Put the REAR PTO and MID Put the engine speed control PTO control levers in the OFF lever at the low idle position. (Engine start) slot. STEP 5 STEP 3 HEAT N SLOTS Turn the starter key switch to the...
  • Page 56 OPERATING INSTRUCTIONS ____________________________________________ STEP 8 STEP 6 When the engine starts, check the oil pressure indicator and charge indicator. If the indicators stay on, stop the engine and find out what is wrong. CLUTCH PEDAL Push the clutch pedal down. STEP 7 START Turn key switch to start position...
  • Page 57 OPERATING INSTRUCTIONS ____________________________________________ 3. Do not use the starter motor for more than 10 seconds without stopping. Wait one minute between starts so the starter motor can cool. 4. If the engine stops when operating with a load, immediately start the engine again to prevent overheating caused by stopping the flow of oil for cooling and lubrication.

  • Page 58: Stopping The Engine

    OPERATING INSTRUCTIONS ____________________________________________ STOPPING THE ENGINE IMPORTANT: When stopping the engine after operating under heavy load, run the engine at 1500 RPM for a short period of time. This will allow the engine temperature to decrease gradually. STEP 3 STEP 1 STOP Move the engine speed control Turn the key switch to OFF posi-...
  • Page 59 OPERATING INSTRUCTIONS ____________________________________________ COLD TEMPERATURE OPERATION To start and operate your tractor during cold ambient temperatures, use these procedures : 1. BATTERY – Must have a full charge. 2. FUEL — Must be clean and with no water. See fuel Specifications in this manual.
  • Page 60 OPERATING INSTRUCTIONS ____________________________________________ IMPORTANT: During cold ambient temperatures, never run the engine at low idle speed for long periods of time. During cold ambient temperatures, the engine will not heat to or keep the rated operating temperature at slow engine speeds. Slow engine speeds in cold temperatures can cause damage to the engine.
  • Page 61 OPERATING INSTRUCTIONS ____________________________________________ TOWING When towing a tractor, follow these rules: 1. Never pull the tractor faster than a ground speed of 16 Km/h (10 MPH). 2. Make sure all controls are in the neutral or OFF position. 3. Because of a possible loss of steering and brakes when the tractor engine is not running, use only a rigid towing bar and safety chains to pull the tractor.
  • Page 62 OPERATING INSTRUCTIONS ____________________________________________ GEAR DRIVE TRANSMISSION The gear drive transmission has a three forward and one reverse gear section and a three-speed range section. This arrangement gives 9 forward and 3 reverse speeds. Transmission Operation 1. The tractor is equipped with dual clutch. The tractor movement stops by pressing the clutch pedal halfway.
  • Page 63 OPERATING INSTRUCTIONS ____________________________________________ DIFFERENTIAL LOCK DIFFERENTIAL LOCK PEDAL GEAR DRIVE RIGHT SIDE of the transmission Your tractor has a differential lock that will make both rear wheels turn at the same speed. The differential lock prevents loss of power when one wheel does not have traction but the other wheel does have traction.

  • Page 64: Rear Pto

    OPERATING INSTRUCTIONS ____________________________________________ POWER TAKEOFF (PTO) PTO driven machinery can cause serious injury or death, usually due to wrapped clothing. When required by the job to be in the drive shaft area, stay clear of rotating parts. Before working on the drive shaft, or servicing or clearing the driven machine, where applicable on this tractor, put the PTO clutch lever in the DISENGAGE position, the PTO lever in the NEUTRAL or OFF, and STOP the engine...
  • Page 65 OPERATING INSTRUCTIONS ____________________________________________ Mid PTO (OPTION) The Mid PTO has a 25.4 mm (1 inch) diameter 15 spline output shaft. ENGAGE THE MID PTO AS FOLLOWS: MID PTO SHAFT 1. Push the clutch pedal fully. 2. Move the Mid PTO control lever forward.
  • Page 66 OPERATING INSTRUCTIONS ____________________________________________ DUAL CLUTCH The Dual Clutch system permits the operator to stop the tractor motion while maintaining PTO operation. (Live PTO) POSITION 3 TRANSMISSION AND PTO ENGAGED POSITION 2 TRANSMISSION DISENGAGED PTO ENGAGED POSITION 1 PTO AND TRANSMISSION DISENGAGED To operate the Dual Clutch system, use the following procedure.
  • Page 67 OPERATING INSTRUCTIONS ____________________________________________ POWER TAKEOFF GUARDS All tractors have a safety guard for the Rear PTO shaft and a safety cover for the Mid PTO shaft. MID PTO COVER REAR PTO GUARD Whenever a PTO driven machine is in operation, the PTO guard must be in place for most operations to prevent injury to the operator or bystanders.
  • Page 68 OPERATING INSTRUCTIONS ____________________________________________ PTO OPERATING SAFETY For the safe operation of the PTO, follow these safe operating proce- dures. Three Point Hitch Connecting Implements 1. Connect the implement to the hitch. See THREE POINT HITCH SYSTEM in this manual. 2. Connect the implement driveline to the tractor. 3 Check the driveline for correct length and for free telescopic movement by lifting and lowering hitch system.
  • Page 69 OPERATING INSTRUCTIONS ____________________________________________ DRAWBAR Your tractor is equipped with a drawbar. Use the drawbar for connecting all pull-behind implements. DRAWBAR OPERATING POSITION DRAWBAR HITCH CONNECTING PIN HOLE STORAGE PIN HOLE WITHOUT MID PTO IMPLEMENT CONNECTING PIN HOLE The drawbar must be in the storage position when using the three-point hitch.
  • Page 70 OPERATING INSTRUCTIONS ____________________________________________ WARNING LAMPS LAMP SWITCH TURN SIGNAL FLASHER SWITCH CONTROL BUTTON The lamp switch has three positions. Turn the switch clockwise to illuminate the headlamp, rear red lamp, and instrument panel lamps. Push the flasher control button down to operate the amber warning lamps.
  • Page 71 OPERATING INSTRUCTIONS ____________________________________________ REAR WORK LAMP (IF EQUIPPED) The rear work lamp is turned on by the switch on the lamp. The starter key switch must be in the ON position before the work lamp can be turned on. IMPORTANT: Do not turn on the rear work lamp while travelling on pub - lic roads.

  • Page 72: Field Operation

    FIELD OPERATION ____________________________________________________ CONNECTING IMPLEMENT TO DRAWBAR The correct connection of the implement to the drawbar will prevent stress on both the tractor and the implement. To assure proper tractor operation and optimum implement performance, the implement must be connected to the drawbar correctly. 1.
  • Page 73 FIELD OPERATION ____________________________________________________ SAFETY CHAIN When towing equipment on a highway, use a safety chain as an auxiliary connection between the tractor and the towed equipment. The safety chain must have a rating greater than the gross load of the towed equipment.
  • Page 74 FIELD OPERATION ____________________________________________________ THREE POINT HITCH SYSTEM The three point hitch system gives position control and draft control (If equipped) of implements. This tractor is equipped with a category I hitch. The three-point hitch dimensions are shown in the following table. Cat I Implement Identification Implement...
  • Page 75 FIELD OPERATION ____________________________________________________ HITCH SYSTEM ADJUSTMENTS The upper and lower links must be adjusted correctly so the im- plement can work at the needed depth and the links are free to UPPER move up and down with the LINK shape of the ground. LIFT LINKS STABILIZERS...

  • Page 76: Upper Link

    FIELD OPERATION ____________________________________________________ Upper Link The length A of the upper link can be adjusted from 470 to 750 mm (18.5 to 29.5 inches). UPPER LINK Turn the turnbuckle clockwise to TURNBUCKLE shorten the link or counterclockwise to lengthen the link. LOCK NUT TURNBUCKLE HOOK...
  • Page 77 FIELD OPERATION ____________________________________________________ HITCH OPERATION Connecting Implement to Hitch To connect an implement to the hitch, use the following procedure: NOTE: Be sure the tractor and implement are on level ground. 1. Put the drawbar in the storage position. 2. Slowly move the tractor backwards to the implement. 3.
  • Page 78 FIELD OPERATION ____________________________________________________ Hitch Control Lever HITCH CONTROL LEVER RAISE LOWER STOP STOP The hitch control lever is used to raise or lower the implement mounted to the three point hitch. To raise the hitch, move the lever to the rear. To lower the hitch, move the lever forward.
  • Page 79 FIELD OPERATION ____________________________________________________ Draft Control Lever (If Equipped) Draft control can be used to DRAFT CONTROL LEVER automatically lift and lower an implement to maintain a constant LIGHT load through variable soil condi- tions. The amount of draft can be adjusted for the implement being used.
  • Page 80 FIELD OPERATION ____________________________________________________ Operating with Draft Control (IF EQUIPPED) For example, the draft control adjustment for a moldboard plow is as follows: 1. Set the upper link at the 560 mm (22-inches) length, pin to pin. 2. Place the draft control lever at the center of its operating range. 3.
  • Page 81 FIELD OPERATION ____________________________________________________ Hitch Lowering Speed Adjustment To adjust the hitch lowering speed, use the following procedure: 1. Move the hitch control lever for- STEP 1 ward to lower the implements. 2. Turn the hydraulic flow control FAST knob to adjust the lowering SLOW speed.

  • Page 82: Remote Hydraulic Control Valve

    FIELD OPERATION ____________________________________________________ REMOTE HYDRAULIC CONTROL VALVE (IF EQUIPPED) A double acting remote hydraulic control valve with a “float position”, is available from your Dealer or Factory Installed. If equipped, the control lever is located on the right side. REMOTE HYDRAULIC CONTROL LEVER Connect the implement hoses to the remote hydraulic couplers so that the implement lowers when the control lever is pushed forward and...
  • Page 83 FIELD OPERATION ____________________________________________________ REMOTE HYDRAULICS OPERATION (IF EQUIPPED) REMOTE HYDRAULIC CONTROL LEVER FLOAT POSITION Float Operation To operate the remote hydraulics in a float condition, move the control lever fully forward to the detent position. The lever will not return to neutral automatically when in the float position.

  • Page 84: Hydraulic Block

    FIELD OPERATION ____________________________________________________ HYDRAULIC BLOCK A hydraulic block is located on the right side of the tractor. This block can provide an external hydraulic circuit for loader use or other applications. See your dealer. SHUT-OFF PLATE HYDRAULIC BLOCK IMPORTANT: Never park a tractor with an implement in the raised position.
  • Page 85 FIELD OPERATION ____________________________________________________ Adding Fluid after Connecting Cylinders and Hoses Operate the engine at a moderate idle speed. Set the stroke stop at the yoke end of the cylinder rod to provide maximum stroke. Then operate the cylinder in both directions about ten times, by moving the control lever up and down.
  • Page 86 MEMO ______________________________________________________________ 16 Series, Model - 2816 4WD...

  • Page 87: Tires/Wheels/Spacing/Ballast

    TIRES/WHEELS/SPACING/BALLAST _______________________________________ TIRE AND RIM EQUIPMENT Tire Inflation Specifications For normal tractor operation use the inflation pressure shown in the tire and wheel chart. The inflation pressure are based on cold inflation pressure recommendations by Tire and Rim Association Inc. For maximum tractor performance always adjust the tire pressure, within the minimum/maximum range, to conform with the actual load on the tires.
  • Page 88 TIRES/WHEELS/SPACING/BALLAST _______________________________________ A tire can explode during inflation and cause serious injury or death. Never increase air pressure beyond 35 PSI to seat the bead on the rim. Replace a tire if it has a defect. Replace a wheel rim which has cracks, wear or severe rust.
  • Page 89 TIRES/WHEELS/SPACING/BALLAST _______________________________________ Check Air Pressure Tire Pressure Check Interval ..Every 50 hours of operation or weekly. Check the condition of the tires and rims for wear or damage. Keep the tires inflated to the recommended pressures. See Tire and Wheel Specifications in this manual for recommended inflation pressures for each tire size.
  • Page 90 TIRES/WHEELS/SPACING/BALLAST _______________________________________ WHEEL MOUNTING TORQUES Front Wheel Disc to Axle Hub Bolts ....... 118 to 132 Nm (87 to 98 Ib ft) Rear Wheel Disc to Axle Hub Bolts ....... 118 to 132 Nm (87 to 98 lb ft) Rear Wheel Rim to Wheel Disc Nuts ......
  • Page 91 TIRES/WHEELS/SPACING/BALLAST _______________________________________ FRONT WHEEL ADJUSTMENT 87 tO 98 LB FT (118 to 132 Nm) The front wheels are tightened with six bolts for MFD to the axle hubs. Torques for wheel bolts and tie rod end nuts as follows: BOLTS AND NUTS POSITIONS TORQUE Front wheel disc 118 to 132 Nm (87 to 98 LB FT)
  • Page 92 TIRES/WHEELS/SPACING/BALLAST _______________________________________ Toe-in Adjustment TO CHECK THE TOE-IN, USE THE FOLLOWING PROCEDURE: 1. Put the tractor on level ground and the wheels in the straight ahead position. 2. Place chalk marks at points A on the centerlines of both front tires at the same height as the centerline of the hub cap.
  • Page 93 TIRES/WHEELS/SPACING/BALLAST _______________________________________ TO ADJUST THE TOE-IN, USE THE FOLLOWING PROCEDURE: 1. Loosen the lock nuts at both TIE-ROD turnbuckle ends to allow the tie TURNBUCKLE rod turnbuckle to turn freely. 2. Turn the turnbuckle to shorten or lengthen the tie rod length. 3.
  • Page 94 TIRES/WHEELS/SPACING/BALLAST _______________________________________ TIRE SIZE COMBINATIONS — MFD Your MFD Tractor must use front and rear tire combinations that are correctly matched. The use of recommended tire combinations will give maximum tractor performance, extended tire life and reduced wear on drive train components. IMPORTANT: The tire size combinations shown below are specified to provide matched ground speeds of the front and rear tires.
  • Page 95 TIRES/WHEELS/SPACING/BALLAST _______________________________________ TRACTOR BALLAST Ballast for your tractor includes front end weights, rear wheel weights and liquid ballast in the rear tires. Front end weights improve the steering characteristic when heavy hitch loads cause a movement of tractor weight from the front to the rear wheels. Rear wheel weights and adding liquid to the rear tires increase traction by putting weight on the driving wheels.
  • Page 96 TIRES/WHEELS/SPACING/BALLAST _______________________________________ NOTE: When you have too much ballast installed on the tractor, you will see the clear shape of the tire tread in the ground which is an indication of no slippage. With too little ballast, the tire tread marks will not show because of the tire slippage.

  • Page 97: Lubrication/Filters/Fluids

    LUBRICATION/FILTERS/FLUIDS ___________________________________________ HOOD To do maintenance work on the engine lubrication system, cooling system, fuel system and air induction system, you must lift the tractor hood. STEP 3 STEP 1 RUBBER LATCH R.H. SIDE COVER Unlock the rubber latches on top Pull the hood latch to release the of each side cover to release the hood.

  • Page 98: Lubrication Table

    LUBRICATION/FILTERS/FLUIDS ___________________________________________ Lubrication Table Grade (SAE No.) Ambient Recommendation Application Kind of Oil Classifi- Description Temperature Oil Brand Single Multi cation Use high 5W-20 Grade Disel Oil -20-0 10W* 10W-30 (-4-32 (For 15 W 40 oil) 15W-40 Engine Oil Citgo-Citgard 500 15W40 -10-10 Exxon-XD3Extra 15W40 (14-50...
  • Page 99 LUBRICATION/FILTERS/FLUIDS ___________________________________________ SERVICE HOUR INTERVAL Service your tractor at the intervals and locations given on the Lubrication and Service Chart. When you service your tractor, use only high quality lubricants. Engine Hourmeter RPM x 1000 ENGINE HOURMETER The engine hourmeter shows the amount of actual hours of the tractor has operated at an average RPM.
  • Page 100 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Service After First 50 Hours 1. Engine Oil Drain all the oil from the crankcase while the engine is warm and refill with new oil to the upper Notch (full) on the engine oil dipstick. See Engine Oil Change in this manual. 2.
  • Page 101 LUBRICATION/FILTERS/FLUIDS ___________________________________________ SYSTEM CAPACITIES METRIC MPERIAL U.S. SYSTEM MEASURE MEASURE MEASURE Engine Oil no filter change 3.9 QTS 3.7 Litres 3.2 QTS with filter change 4.4 QTS 4.2 Litres 3.7 QTS Fuel tank 7.9 Gallons 30 Litres 6.6 Gallons Coolant engine and radiator 7.1 QTS 6.7 Litres...
  • Page 102 LUBRICATION/FILTERS/FLUIDS ___________________________________________ FREQUENCY IN HOURS SERVICE POINT Engine Oil Level Front Axle Tie Rod Front Axle Pivot Pin Power Steering Cylinder End Brake Pedal Boss Transmission Oil Level Radiator Coolant Level Fuel Filter Cup Air Cleaner Fan Belt Tension Grill and Radiator Area Tire Pressure Fuel Tank Water Drain Plug Engine Oil...
  • Page 103 LUBRICATION/FILTERS/FLUIDS ______________________________________________________________________________________________________________________________ 100 HRS 1000 HRS 10 HRS Fluid 100 HRS 10 HRS Levels Filters Radiator and Coolant - Drain, Coolant Recovery Reservoir Engine Oil - Change Air Cleaner-Clean Engine Oil - Drain - Check Flush and Fill 10 HRS 200 HRS Engine Oil Filter - Change Engine Oil - Check...
  • Page 104 LUBRICATION/FILTERS/FLUIDS ___________________________________________________________________________________ FRONT AXLE 10 HRS 10 HRS USE NLGI No.2 MULTIPURROSE LITHIUM EP GREASE. Tie Rod End - Grease Front Axle Pivot Pin - Grease 10 HRS M F D Power Steering Piston End - Grease 200 HRS MFD Lubricant - Check 200 HRS 200 HRS 200 HRS...
  • Page 105 LUBRICATION/FILTERS/FLUIDS ___________________________________________ ENGINE LUBRICATION Service Specifications Oil Level Check Interval ................ Daily. Oil Change Interval ......... Every 100 hours (See NOTE) Oil Type ..........See Lubrication Table in this manual. Oil Capacity — Without Filter Change ....3.7 Litre (3.9 QT) With Filter Change ......
  • Page 106 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Engine Oil Change To change the engine oil, put the tractor on level ground and stop the engine. Change the engine oil as follows: NOTE: For best results change the oil while the engine is still warm. OIL FILL CAP DRAIN PLUG 1.

  • Page 107: Engine Oil Filter

    LUBRICATION/FILTERS/FLUIDS ___________________________________________ Engine Oil Filter Change Interval..........Every 200 hours (See NOTE) NOTE: Change the engine oil filter after the first 50 hours of operation and then use the regular change interval. IMPORTANT: Change the oil filter at the recommended time interval. Your Dealer has approved genuine ENGINE OIL FILTER filters.
  • Page 108 LUBRICATION/FILTERS/FLUIDS ___________________________________________ COOLING SYSTEM Service Specifications Coolant Change Interval......Every 1000 hours or once each year whichever occurs first Capacity of System Engine and Radiator ......6.7 Litres (7.1 QTS) Coolant Bottle ......... 0.4 Litres (0.4 QTS) Thermostat..........82 C to 95 C (180 F to 203 Radiator Cap Pressure ..........
  • Page 109 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Coolant Solutions Your tractor cooling system is equipped with an ethylene glycol coolant solution that has a high boiling point. IMPORTANT: Change the coolant solution at the change interval recommended in this manual (See Lubrication and service Chart). The heat generated by the diesel engine causes a natural change in the inhibitors in the coolant which results in loss of corrosion protection.

  • Page 110: Cleaning The Cooling System

    LUBRICATION/FILTERS/FLUIDS ___________________________________________ Cleaning The Cooling System IMPORTANT: NEVER PUT COOLANT IN A HOT ENGINE: THE ENGINE BLOCK OR CYLINDER HEADS CAN GET CRACKS BECAUSE OF THE DIF- FERENCE IN TEMPERATURE BETWEEN THE METAL AND THE COOLANT. COOLANT RESERVE COOLANT DRAIN PLUG BOTTLE FULL OPEN...
  • Page 111 LUBRICATION/FILTERS/FLUIDS ___________________________________________ FUEL SYSTEM Service Specifications Fuel Filter Cup Service Interval .......... Every 10 Hours Fuel Filter Element Change ........ Replace when loss of power or misfiring occurs This type filter cannot be cleaned. Change the filter when the engine is misfiring or a loss of power is evident, It is necessary to remove the air from the system after each replacement.
  • Page 112 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Diesel Fuel Specifications Use a good grade of Number Two Diesel Fuel in your Diesel Engine. Do not use other types or grades of fuel. The use of other fuels will result in loss of engine power and high fuel consumption. NOTE: When the temperature is very cold, the use of a mixture of Number one and Number Two Diesel Fuel is permitted for a short period of time.

  • Page 113: Fuel Filter Element Replacement

    LUBRICATION/FILTERS/FLUIDS ___________________________________________ Fuel Filter Element Replacement To replace the filter element, use following procedure: STEP 1 STEP 4 FUEL SHUT-OFF VALVE CLOSE FILTER ELEMENT Close the fuel shut-off valve. Install new filter element. Assem- ble filter cup and retaining nut to STEP 2 filter body.
  • Page 114 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Fuel System Air Removal AIR MUST BE REMOVED FROM THE FUEL SYSTEM. AIR CAN ENTER THE FUEL SYSTEM WHEN: 1. An engine stopped from lack of fuel. 2. The fuel filter has been replaced or the filter cup has been cleaned. 3.
  • Page 115 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Fuel Injection Pump and Nozzle Check NOZZLE INJECTION PUMP The fuel injection pump and nozzles are precision units and must be serviced only by your dealer. The injection pump is correctly set and sealed at the factory and should not require an adjustment.
  • Page 116 LUBRICATION/FILTERS/FLUIDS ___________________________________________ AIR INDUCTION SYSTEM The air induction system components require service at different inter- vals according to local operating conditions. Service Specifications Dump Valve ........... Clean daily or every 10 hours Filter Element Clean Element ............When necessary Replace Element ........ After 10 cleanings or yearly System Inspection ..
  • Page 117 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Air Filter Element Removal Avoid over servicing the air filter element. The filter element should be removed for cleaning only when restriction causes a power loss. STEP 1 STEP 4 ELEMENT Stop the engine. When servicing the air filter element, loosen the wing bolt and remove element by pulling it STEP 2...
  • Page 118 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Element Cleaning Use clean, dry compressed air up and down the pleats on the clean side (inside) of the element. Continue this until the element is clean. NOTE: 1. The paper element must be handled with care. Do not hit the element against a hard surface.
  • Page 119 LUBRICATION/FILTERS/FLUIDS ___________________________________________ TRANSMISSION & HYDRAULIC LUBRICATION Service Specifications Oil Level Check Interval ..............Daily Oil Change Interval ............Every 200 hours. Oil Capacity – Hydrostatic Drive ......22 Litres (23.2 Quarts). Oil Type – Hydrostatic Drive ..Refer Lubrication Table page 88 Hydraulic System Check ......Yearly inspect for leaks, cracks and abrasion.
  • Page 120 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Transmission Oil Change Oil Change Interval ............Every 200 hours To change the transmission oil, use DRAIN PLUGS the following procedure: 1. Put the tractor on level ground, apply the park brake and stop the engine. Move the range shift lever to L position.
  • Page 121 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Hydraulic Filter (Hydrostatic Drive) Change Interval ..........Every 200 hours (See NOTE) NOTE: Replace the hydraulic filter after the first 50 hours of operation and every 200 hours of operation thereafter. Your Dealer has ap- proved genuine filters. Do not use other type filters.
  • Page 122 LUBRICATION/FILTERS/FLUIDS ___________________________________________ FRONT AXLE LUBRICATION (MFD) Service Specifications Oil Change Interval ........Every 200 hours (See NOTE) Oil Capacity .............. 4.0 Litres (4.2 Quarts) Oil Type ............SAE 85W-140 Gear Lubricant NOTE: Change the oil after the first 50 hours of operation and then every 200 hours of operation.
  • Page 123 LUBRICATION/FILTERS/FLUIDS ___________________________________________ Front Axle Oil Change 1. To change the front axle oil, put the tractor on level ground. Put the range lever in L, engage the park brake and stop the engine. FILL HOLE DIFFERENTIAL DRAIN PLUG 2. Remove the fill cap located on the axle housing, the differential drain plug located in the bottom of the housing and the gear case...

  • Page 124: Maintenance/Adjustments

    MAINTENANCE/ADJUSTMENTS___________________________________________ COOLING SYSTEM Grille Screens and Radiator Area Grille Screens and Radiator Area Service Interval ....Every 50 hours or more frequently if required. To clean the radiator screen, put the tractor on level ground, apply the park brake and stop the engine. STEP 1 STEP 3 Clean the radiator screen and the...

  • Page 125: Fan Belt Adjustment

    MAINTENANCE/ADJUSTMENTS___________________________________________ Fan Belt Adjustment Fan Belt Tension Check Interval ......Daily or after 10 Hours Adjust the belt tension after the first 50 hours of operation and NOTE: replace when necessary. Measure the fan belt for correct tension. Check to see if the belt deflection is about 13mm (0.5 inch) when pushing the belt with 10 kg (22 lb) load at point PIVOT NUT...
  • Page 126 MAINTENANCE/ADJUSTMENTS___________________________________________ Fan Belt Replacement To replace the fan belt, use following procedure: STEP 3 STEP 1 L.H. SIDE COVER PIVOT NUT Loosen the alternator pivot nut Raise the hood. Remove the LH and push the alternator toward side cover. the engine to remove the belt. STEP 2 ADJUSTING BOLT STEP 4...

  • Page 127: Clutch Pedal Adjustment

    MAINTENANCE/ADJUSTMENTS___________________________________________ CLUTCH PEDAL ADJUSTMENT Service Specifications Clutch Pedal Check and Adjustment Interval ..Every 200 hours of op- eration or yearly Free Pedal Movement ........20 – 30 mm (0.8 – 1.2 inch) Max. Pedal Movement Dual Clutch ........125–130 mm (4.9 – 5.1 inch) Free Movement Adjustment Clutch pedal free movement is very important and must be checked at the recommended intervals.
  • Page 128 MAINTENANCE/ADJUSTMENTS___________________________________________ Maximum Pedal Movement Adjustment The Maximum Pedal Movement is very important and must be checked at the recommended intervals. If there is too little movement, the clutch can disengage. If there is too much movement, the clutch component parts can be damaged. NOTE: Adjust the Maximum Pedal Movement after adjusting the Free Movement.
  • Page 129 MAINTENANCE/ADJUSTMENTS___________________________________________ BRAKE PEDAL ADJUSTMENT Service Specifications Brake Pedal Check and Adjustment Interval ... Every 200 hours or yearly Free Pedal Movement Specification ........25 mm (1 inch) Brake pedal free play is very important and must be checked at the recommended intervals.
  • Page 130 MAINTENANCE/ADJUSTMENTS___________________________________________ RAISE STOP SETTING POSITION If raise stop setting position is incor- rect, the hydraulic pump might be HITCH CONTROL damaged. LEVER Therefore carefully adjust as below. RAISE STOP Max. position by hand Stop position by hydraulic 5 ~ 10 mm (0.2 ~ 0.4 in) 1.

  • Page 131: Electrical System

    ELECTRICAL SYSTEM_________________________________________________ SPECIFICATIONS Electrical System Type of System ........... 12 Volt, Negative Ground Battery ..............EXIED 58-60 12V-540CCA L; 7- W; 7H SAE TAPER Alternator ............12Volt, 50 Ampere Output Voltage Regulator............IC Built in Alternator Starter Motor ......12 Volt, 1.6 kW with Solenoid Switch Head Lamp ..................
  • Page 132 ELECTRICAL SYSTEM_________________________________________________ GENERAL SERVICE INFORMATION Alternator Charging System Follow these general rules to prevent damage to the electrical system: 1. Before working on the electrical system, disconnect the battery cables. 2. Do not make a reverse battery connection. 3. When you use an auxiliary battery for starting, connect positive to positive and negative on the auxiliary battery to the tractor side rail as a ground.
  • Page 133 ELECTRICAL SYSTEM_________________________________________________ Fuses Cartridge type fuses are used for head lamps, rear red lamp, instrument lamps, turn signal and flasher lamps, and rear work lamp (if equipped). The fuses are located in the fuse block, R.H. rear of engine room. If a short circuit occurs, the fuse will burn out and break the circuit, preventing damage to the electrical system.

  • Page 134: Line Fuse

    ELECTRICAL SYSTEM_________________________________________________ Line Fuse If the electrical circuit is accidently grounded or a reverse battery connection is made, the Line fuse located on the LH side of the engine will burn out and break the circuit to prevent the solenoid switch, wiring harness and alternator charg- ing system from being damaged.
  • Page 135 ELECTRICAL SYSTEM_________________________________________________ BATTERY Auxiliary Battery Connections Engine can start with transmission in gear when neutral or safety start switch is by-passed: 1. Do not connect across terminals on starter. 2. Attach a booster battery by connecting the positive terminal of the booster battery to the “positive terminal”...
  • Page 136 ELECTRICAL SYSTEM_________________________________________________ WARNING BATTERIES CONTAIN ACID AND EXPLOSIVE GAS. EXPLOSION CAN RESULT FROM SPARKS, FLAMES, OR WRONG CABLE CON- NECTIONS, TO CONNECT JUMPER CABLES OR CHARGER, SEE MANUAL(S) FOR THE CORRECT PROCEDURE. FAILURE TO FOLLOW THE ABOVE INSTRUCTIONS CAN CAUSE SERIOUS PERSONAL INJURY OR DEATH.
  • Page 137 ELECTRICAL SYSTEM_________________________________________________ When Charging the Battery IMPORTANT: Battery can explode during boosting or charging. Always wear proper eye protection, such as a safety goggles. If the electric circuit inside the battery is broken, charging can generate a spark inside the battery which can cause it to explode. If the battery is discharged, and the reason for discharge is unknown and if the lamps or horn do not indicate some battery voltage, check the battery with a volt meter for an open circuit using following procedure.
  • Page 138 ELECTRICAL SYSTEM_________________________________________________ Head Lamp Adjustment NOTE: To keep maximum ground and road illumination, check and adjust the head lamps from time to time. Tire wear and different tire sizes will change the setting. The head lamps can be adjusted to various positions by adjusting the mounting screws in the rear of the head lamp unit.

  • Page 139: Storage

    STORAGE_____________________________________________________________ STORING THE TRACTOR When your tractor is not to be used for some time, it should be stored in a dry and protected place. Leaving your tractor outdoors, exposed to the elements, will shorten its life. Follow the procedure outlined below when your tractor is placed in storage for periods up to approximately six months.

  • Page 140: Removing From Storage

    IMPORTANT: Keep the doors wide open and move the machine outside of the storage room immediately to avoid danger from exhaust fumes. Do not accelerate the engine rapidly or operate it at high speed immediately after starting. NOTE: Mahindra Tractors 16 Series, Model - 2816 4WD...

This manual is also suitable for:

16 series2816 4wd

Table of Contents
