Summary of Contents for GPS Insight 3600
-
Page 1: Installation Guide
3600 Installation Guide Light/Medium/Heavy Duty • Universal www.gpsinsight.com 866.GPS.4321 support@gpsinsight.com... -
Page 2: Table Of Contents
Table of Contents Getting Started Registration Form......................3 3600 Product Line Unit Overview.........................4 Harness Options for the 3600 Product Line..............5-6 Installation Instructions Light/Medium Duty OBD-II Harness Installation.............7-9 Heavy Duty Harness Installation.................10 Universal Harness Installation................11-12 Optional Window-Mount GPS Antenna Installation Instructions......13 Verifying Successful Installation...................14 Creating Tamper Evidence..................15... -
Page 3: Registration Form
Registration Form Fill out the enclosed registration form before completing installation. Record the following information: • Vehicle Identification Number (VIN) • License Plate • Year • Make • Model • Unit’ s Serial Number (10 digits) 1300915003 Installation Tip: Metal walls and tall buildings may interfere with the reception from GPS satellites and the cellular network. -
Page 4: 3600 Product Line
3600 Product Line Unit Overview Note: All 3600 units are shipped with a knock-out panel covering the sensor/serial ports. In order to access those ports, you must use an X-ACTO knife to slice off 2 of the 3 tabs in order to remove the knock-out panel. -
Page 5: Harness Options For The 3600 Product Line
Harness Options for the 3600 Product Line Prior to installation, you must select and order the appropriate harness for your vehicle type. Please refer to the list below to verify harness compatibility for each of the 3600 series devices: 3600 (Diagnostic Capable Hardware) • Light/Medium Duty OBD-II Harness... - Page 6 Harness Options for the 3600 Product Line There are 3 different harness options for Heavy Duty vehicle installations: 6-pin Harness, 9-pin Harness, and 9-pin “D” Harness. Page 6 www.gpsinsight.com 866.GPS.4321 support@gpsinsight.com...
-
Page 7: Light/Medium Duty Obd-Ii Harness Installation
Light/Medium Duty OBD-II Harness Installation Select an Adapter that most resembles the shape of the OBD-II port of the vehicle. Use these guidelines to match an adapter to the vehicle it is most likely to fit (each adapter is stamped with a number). Ford, GM (1), (6), or (8) Honda, Lexus, Toyota, Chrysler (2) Toyota*, Chrysler* (2a) - Page 8 Light/Medium Duty OBD-II Harness Installation Core Connector Assembly 1. Snap the selected plastic adapter to the back of the Core Connector. 2. Attach the Core Connector to the OBD-II Replacement Connector. Data Port Connection 1. Connect the Harness Connector to the Data Port. Page 8 www.gpsinsight.com 866.GPS.4321...
- Page 9 Light/Medium Duty OBD-II Harness Installation Connecting to the OBD-II Port 1. With the vehicle’ s engine OFF , remove the vehicle’ s OBD-II port. • The OBD-II Connector may be hidden behind a hush panel. • To remove the connector, you may need to remove screws or depress the clips. 2. Connect the Bypass Connector to the vehicle’ s OBD-II port that was previously removed. 3.
-
Page 10: Heavy Duty Harness Installation
Heavy Duty Harness Installation Connecting to the Diagnostic Link Connector (DLC) Port 1. With the vehicle’ s engine OFF , unscrew the DLC port from its position under the dashboard*. In most cases, the DLC port is located under the dashboard on the left side of the steering wheel, facing toward the floorboard. -
Page 11: Universal Harness Installation
Universal Harness Installation Connecting to Ground and Power Black Wire - Ground • With the vehicle’ s engine OFF , attach the Black Wire directly to a chassis ground point or to a ground line (chassis ground) by splicing directly to a ground lead or by using a wire tap (recommended). - Page 12 4) Start the engine and confirm that the voltage of the same wire is 13.1 VDC or higher 5) Turn the vehicle’ s engine OFF and confirm that the voltage of the same wire is 0 VDC Switched Power Constant Power (Battery) Red Wire Green Wire Yellow Wire 3600 Unit Ground Page 12 www.gpsinsight.com 866.GPS.4321 support@gpsinsight.com...
-
Page 13: Optional Window-Mount Gps Antenna Installation Instructions
Optional Window-Mount GPS Antenna Installation To Install 1. Units are shipped with a knock-out panel covering the sensor/serial ports. First, use an X-ACTO knife to slice off 2 of the 3 tabs in order to remove the knock-out panel. 2. Use enclosed alcohol preparation pad to clean the inside windshield where the antenna is to be placed. -
Page 14: Verifying Successful Installation
Verifying Successful Installation 1. Start the vehicle’ s engine. All lights (Red, Yellow, and Green) on the device should turn on solid for 15 seconds and then begin blinking rapidly (twice a second). 2. The device is operating normally when the rapid blinking ceases and the Green and Yellow lights begin to blink in a slow pattern (ON for 5 seconds and OFF for 1 second). -
Page 15: Creating Tamper Evidence
Creating Tamper Evidence Once the vehicle harness is plugged in, slide the zip ties through the two slots provided on the harness connector. Once the zip ties are in place, tighten and remove the excess plastic. If possible, position the zip ties so that the “DO NOT REMOVE” message is showing. -
Page 16: Completing Installation
Completing Installation Before securing the device under the dashboard, make sure that you have recorded the VIN, hardware serial number, and odometer reading on the registration form. Also verify that you have checked the light indicators. vehicle registration form Time of Install______________________________Date __________________________ Serial # (10 digit number usually located on back of device) Vehicle Label____________________________________________________________... -
Page 17: Securing The Device
Securing the Device Use zip ties to fasten the hardware securely to a stable bracket or wire bundle under the dash. IMPORTANT: The device must be installed high in the dashboard area and secured with the top of the unit facing the sky (the side of the unit with the manufacturer logo). Also verify that the device is not covered by metal and check that the green LED is blinking in a slow pattern, which verifies that the unit is getting GPS data (as explained on page 13). -
Page 18: Troubleshooting Light Indicators
Appendix: Troubleshooting Light Indicators Issue: Red light continues to blink rapidly Solution: - Verify that the unit is not surrounded by metal. - Contact Customer Care to confirm network coverage availability and the SIM is active. Issue: Yellow light continues to blink rapidly Solution: - Contact Customer Care to verify engine computer compatibility. -
Page 19: Frequently Asked Questions
A: No. Q: When installing the 3600 device, are fuses involved or can the device be “wired hot”? A: We recommend splicing the 3600 harness to fused leads, though the device can be “wired hot” since there is an internal re-settable fuse. An in line fuse is not necessary, however if one is used, it should be at least 5 amps. -
Page 20: Customer Support
24/7/365 GPS Insight offers Customer Support Please contact us today if you have any additional questions about this product. 1.866.477.4321 Toll Free: support@gpsinsight.com Email: www.gpsinsight.com Web: www.gpsinsight.com 866.GPS.4321 support@gpsinsight.com...
