INSTALLING THE THERMOSTAT

DISASSEMBLY

There are two release slots located on the bottom of the thermostat. Gently push the flat blade
of a small screwdriver into one slot at a time and pry upward until the catch disengages.
Carefully swing the thermostat upward and away from the subbase. (Figure 1)

THERMOSTAT LOCATION

The 44-800 should be installed in a location that
represents the ambient space temperature. Do not
install the thermostat in an area where drafts are
present, near the floor, behind doors or on an external
wall. Avoid placing the thermostat in areas where the
air movement is limited, affected by direct sunlight or
other areas not typical of the temperature in the space.

MOUNTING THE SUBBASE

When mounting the 44-800 subbase, be aware that
drafts may travel down wall cavities and enter the back
of the thermostat through the control wire hole in
8
FIGURE 1
