Summary of Contents for Dukane AS3
-
Page 1: Quick Start Guide
Education. Presentation. Inspiration. AS3 ––AirSlate3 Quick Start Guide English Version Document:09110.10.19.09 Revision 01... -
Page 2: Mac Users
• Documents including “User Guide,” “Macro Key Manager User Guide,” and the Warranty Card. PC USERS There is a PC CD with the AS3 but the latest software is posted on the Dukane web site. For downloads and information on the AirSlate3, visit: www.dukcorp.com/av... -
Page 3: The R&Tte Directive
The R&TTE Directive We, the manufacturer hereby declare that this equipment, model RCK- T07 is in compliance with the essential requirements and other relevant provisions of Directive 1995/5/EC. FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Rf Exposure Warning
● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/ TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could... -
Page 5: Package Contents
Congratulation on purchasing a Dukane AirSlate3 Wireless Tablet The AS3 is a wireless slate operating at 2.4 Ghz. It is easy to operate. Just install the latest drivers from the Dukane, AS3 web site at www.dukcorp.com/av. Vista Users can operate the slate without the driver but will have only the basic mouse control and not the hot key, volume control and Macro Key functions. -
Page 6: Hardware Features
2. Hardware features Tablet: Front side Pen slot Page up/ Page down power button Volume adjustment circle Macro key area Active area Back side Binding button Dongle storage Battery storage... -
Page 7: How To Change Battery
Receiver Dongle (for the USB Port) ▪ Binding button ▪ LED How to change battery... - Page 8 How to change pen tip 3. LCD Window Icons Power on: Press the power button for 3 seconds, this icon will appear. Battery Indicator : There are four levels on the battery indicator. Active: Tablet is active. the pen is on or near the active surface. The table will go into power-saving mode if the pen is off for more than 3 seconds, this icon will then disappear.
-
Page 9: Installation
The interaction between the pen and the tablet: ● Blanking: Pen is near the active area. ● Still: Pen tip is on the active area. Volume adjustment indicator : you can use the pen in the volume adjustment circle to adjust the computer volume. ●... -
Page 10: Operation
Connect to the USB port on an active computer to the USB port on top of the slate. A blue LED located below the pen holder will become visible during the charging. DUKANE CORP AV SERVICE DEPT 2900 Dukane Drive St Charles , Il 60174 800-676-2487 / 630-762-4032 www.dukcorp.com/av... -
Page 11: Specifications
6. Specifications Solution Wireless 2.4G RF Dimension 278*282*20mm active area 7.84”*5.92” Resolution 2000lpi Report rate 120 rpst Pen pressure 1024 levels Macro key 16( top of active area) Hot key Page up / page down LCD type TN LCD LCD size 17.7*40.9mm battery status –...
