Dukane AirSlate AS2 User Manual

Dual-color Status LED
1. Lights red momentarily when tablet is turned "on." No
light when battery is dead.
2. Remains red or turns red when batteries are low.
3. Blinks blue when tablet is linked via Bluetooth to the PC
and pen is in storage slot or away from the tablet.
4. Lights blue when pen is in proximity to tablet.
5. Lights "off" when pen contacts active area.
USB Cable
attachment port
Off/On Switch
Wireless Pen with
One AAA Battery
1. Battery Installation . . . .
2. Installation for PC's with Windows XP, Service Pack 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3. Operating the software, (Inking and annotation). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. Using Multiple Slates (up to 7) with same PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5. Adjusting the Slate . . .
6. Troubleshooting Tips . .
7. Installation for Windows 2000 XP, Service Pack 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8. How to Unpair the Slate and PC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
9. Specifications . . . . . . .
Appendix A, How to identify Windows version and service pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Appendix B, Pen Tip Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
AirSlate
Disconnect Button To Use when Changing PC's
If there is difficulty detecting one or more slates, discon-
nect the slate from the PC by holding in the silver button
for 5 full seconds.
Contents
Product AS2
Fast Start User's Guide
USB Bluetooth Adapter
(Dongle) for Computer
Page
1
15
18
28
