FOR SERVICE TECHNICIAN ONLY - DO NOT REMOVE OR DESTROY
Replace the heater if it is electrically open.
Replace both the thermal cut-off and high limit
thermostat (inlet thermistor/high limit thermostat
assembly on Amana models) if either the thermal
cut-off or the high limit thermostat is electrically
open.
High Limit Thermostat
Thermal
Cut-Off
Thermal Fuse
Electric Dryer
High Limit Thermostat
Flame
Sensor
Thermal Fuse
Gas Dryer
Figure 10. Thermal Components, viewed
from front.
5. If no open circuit is detected, remove the P14
(P4 on Amana models) connector, then measure
the resistance between P14-3 (P4-3 on Amana
models) (red wire) and P14-6 (P4-6 on Amana
models) (red wire) at the connector. See figure 16,
page 22, for connector location; and Accessing &
Removing the Electronic Assemblies, page 21.
Heater
Element
machine control electronics.
the outlet thermistor.
GAS DRYER:
1. Unplug dryer or disconnect power.
2. Remove the toe panel to access the thermal
components.
3. Perform TEST #4b, page 17. If the thermal
fuse is OK, go to step 4.
4. Perform TEST #4c, page 17. If the thermal
cut-off is OK, go to step 5.
5. Locate the high limit thermostat. See figure
10. Measure the continuity through it by
connecting the meter probes on the red wire
and black wire terminals.
Outlet
Thermistor
limit thermostat and the thermal cut-off.
6. Perform TEST #4d, page 18. If this is OK,
Thermal Cut-Off
replace the machine control electronics.
Heat will not shut off:
1. Unplug dryer or disconnect power.
2. Access the machine control electronics. See
figure 16, page 22, for connector location; and
Accessing & Removing the Electronic Assemblies,
page 21.
ALL DRYERS: Remove the P14 (P4 on Amana
electric models) connector, then measure the
resistance between P14-3 (P4-3 on Amana
electric models) (red wire) and P14-6 (P4-6
on Amana electric models) (red wire) at the
connector.
machine control electronics.
Outlet
Thermistor
replace the outlet thermistor.
PAGE 15
If 5–15 k are measured, replace the
If the resistance is less than 1 k , replace
If there is an open circuit, replace the high
Otherwise, go to step 6.
If 5–15 k are measured, replace the
If the resistance is greater than 20 k ,
